- Page 1 Heat Design Models 400T SLIM / 450T / 500T / 1250T / 1600T / 2000T Please read the instructions carefully before installation and keep for future reference. Please Note: This product is for a well-insulated dwelling.
-
Page 2: Table Of Contents
Table of Contents Important Electrical safety Technical Specifications / Appliance Dimensions Components Operating Instructions Maintenance Warranty... -
Page 3: Important Electrical Safety
Important Electrical safety Read all instructions fully before using this electric fire. This electric fire is for INDOOR USE ONLY. If installing the appliance into an existing Chimney the chimney MUST be blocked off / capped. Do not locate the fire below or in front of a fixed socket outlet. Warning DO NOT COVER the fan heater air inlet / outlet as it could cause possible fire. - Page 4 Do not use the appliance in small areas where there are persons are incapable of leaving the area on their own, unless there is constant supervision. This appliance is supplied with a 13Amp 3 pin moulded plug. The fire must only be connected to a 220/240V ac supply 50/60 Hz.
-
Page 5: Technical Specifications / Appliance Dimensions
2 Technical Specifications Trance Trance Trance Trance Trance Trance Models 400Slim 500 MK2 1250 1600 2000 Maximum heat output 1500W 1500W 1500W 1500W 1500W 1500W Minimum heat output 750W 750W 750W 750W 750W 750W Heat Output per model Voltage supply 220 / 240V 50/60Hz Power usage for LED lighting / per model Trance... -
Page 6: Components
Components Before unpacking the fire inspect the carton for any damage, either caused by transport / water etc. If in doubt contact your local retailer, and do not use the appliance. IMPORTANT Keep any plastic packaging and small parts away from young children as they will pose a danger. -
Page 7: Operating Instructions
Operating Instructions Manual Operation Rocker Switch Push the rocker switch to I. Standby button Press the standby button once to turn the fire on (wait 15 seconds for the fire to come on).To turn the fire off press the button again. Heater Button Press the heater button once and the heater will turn on to half heat (750w). - Page 8 Remote Operation Turning on/off the appliance Turn the Rocker switch to turn on the appliance. Press to turn on or turn off the electric fire. Timer Press button for timer setting, OFF - 60min-120min-180min-240min-300min- 360min-420min-480min. Electric heating control Press button to turn on or turn off the electric heater. Press the button once for half power (750 W) —...
- Page 9 4. Down light effect button to select the down light color. Press 5. Flame effect Press button for select flame color. 6. Front LED pulsing lights Press button for turn on or turn off the Front LED. 7. Fuel bed effect Press button for select the Fuel bed color.
- Page 10 SPARE PARTS LISTS & CODES ICONIC Trance ICONIC Trance Component Component 400T Slim 400T Slim Frame with glass FRG400T Fan Heater FH400T Flame effect glass FEG400T PCB control board PCB-Trance Fuel bed Led FBL400T Power supply PS-Trance Fuel bed board FBD400T Speaker SP-ICONIC...
- Page 11 ICONIC Trance ICONIC Trance Component Component 450T 450T Front part FP-450T Fan Heater FH-450T Flame effect glass FEG-450T PCB control board PCB-Trance Fuel bed Led FBL-450T Power supply PS-Trance Fuel bed board FBB-450T Speaker SP-ICONIC LCD Screen display-17 LCD-17 Power supply for Screen display PSSD-Trance Sides glass SG-450T...
- Page 12 ICONIC Trance ICONIC Trance Component Component 500 MK2 500 MK2 Door glass DG-500MK2 Fan Heater FH-500 Flame effect Glass FEG-500MK2 PCB control board PCB-Trance Door Door-500MK2 Power supply PW-Trance Fuel bed Led FBL-500MK2 Speaker SP-ICONIC Fuel bed board FBB-50MK2 Power supply for Screen display PSSD-Trance LCD Screen display-19 LCD-19...
- Page 13 ICONIC Trance ICONIC Trance Component Component 1250T 1250T Front glass FG-1250 Fan Heater FH-1250 Flame effect glass FEG-1250T PCB control board PCB-Trance Front glass Fixing part FGFP-1250 Power supply PW-Trance Fuel bed Led FBL-1250 Speaker SP-ICONIC Fuel bed board FBB-1250 Power supply for Screen display PSSD-Trance LCD Screen display-27...
- Page 14 ICONIC Trance ICONIC Trance Component Component 1600T 1600T Front glass FG-1600 Fan Heater FH-ICONIC Flame effect glass FEG-1600T PCB control board PCB-Trance Front glass Fixing part FGFP-1600 Power supply PW-Trance Fuel bed Led FBL-1600 Speaker SP-ICONIC Fuel bed board FBB-1600 Power supply for Screen display PSSD-Trance LCD Screen display-21.5...
- Page 15 ICONIC Trance ICONIC Component Component 2000T Trance 2000T Front glass FG-2000 Fan Heater FH-ICONIC Flame effect glass FEG-2000T PCB control board PCB-Trance Front glass Fixing part FGFP-2000 Power supply PW-Trance Fuel bed Led FBL-2000 Speaker SP-ICONIC Fuel bed board FBB-2000 Power supply for Screen display PSSD-Trance LCD Screen display-27...
-
Page 16: Maintenance
Maintenance Always isolate the power from the mains and ensure the fire has cooled down before any cleaning or maintenance is undertaken. Cleaning the appliance Carefully clean the air inlet and heater area with a cloth or vacuum on a regular basis. It is important that these areas are kept free from dust / pet hairs etc. -
Page 17: Warranty
/ accidently damage caused by transit / improper installation / serial numbers missing or modified. Heat Design shall not be liable for any consequential loss or damage whatsoever arising from or in connection with this electric fire. Service calls and installation errors are not covered under manufacturer warranty. A call out charge will apply. - Page 18 Heat Design Unit 60, Hawthorn Road, Western Industrial Estate, Naas Road Dublin 12. Email Info@heatdesign.ie Rev 1 – 11/30/2023...
