- Page 1 Heat Design Models: 750 / 1000 / 1250 / 1600 / 2000 Please read the instructions carefully before installation and keep for future reference. Please Note: This product is for a well insulated dwelling.
-
Page 2: Table Of Contents
Table of Contents Important Electrical safety Technical Specifications / Appliance Dimensions Components Operating Instructions Maintenance Warranty... -
Page 3: Important Electrical Safety
Important Electrical safety Read all instructions fully before using this electric fire. This electric fire is for INDOOR USE ONLY. Do not locate the fire below or in front of a fixed socket outlet. Warning DO NOT COVER the fan heater air inlet / outlet as it could cause possible fire. Note the warning symbol on the fire. - Page 4 Do not use the appliance in small areas where there are persons are uncappable of leaving the area on their own, unless there is constant supervision. This appliance is supplied with a 13Amp 3 pin moulded plug. The fire must only be connected to a 220/240V ac supply 50/60 Hz.
-
Page 5: Technical Specifications / Appliance Dimensions
Technical Specifications Heat Output per model Models 1000 1250 1600 2000 Maximum heat output 1500 W 1500W 1500 W 1500W 1500W Minimum heat output 750 W 750W 750 W 750W 750W Voltage supply 220 / 240V 50/60Hz Power usage for LED lighting / per model Models 1000 1250... -
Page 6: Components
Components Before unpacking the fire inspect the carton for any damage, either caused by transport / water etc. If in doubt contact your local retailer, and do not use the appliance. IMPORTANT Keep any plastic packaging and small parts away from young children as they will pose a danger. -
Page 7: Operating Instructions
Operating Instructions Pairing the remote to the appliance To pair the remote to the appliance, first turn on the main switch to put the fire in the standby mode. Press and hold the 2 buttons indicated for 5 seconds, then release and press button on the remote to complete the pairing process. - Page 8 Main Power Switch Push the main power switch to I, the main power indicator light will illuminate. Manual Switch Pressing the manual switch button turns the fire on and off. Heater Button Press the heater button once and the heater will turn on to half heat (750w). Press the heater button a second time and the heater increases to full heat (1500w).
- Page 9 Remote Operation Please Note This is a thermostatic remote control. The remote control should always be in the same room as the electric fire with the screen facing up. Please do not cover the temperature sensor. Do not leave the remote control next to the fire or a warm area such as a window, this will relay false information to the fire and prevent the fire from turning on and off the heat.
- Page 10 1. Turning on/off the appliance Turn the Rocker switch to turn on the appliance. Press to turn on or turn off the electric fire. If the screen displays, please press to unlock the keypad. 2. Temperature setting Press the for setting temperature from. Press the SET button or stop using the remote for 3 seconds and it will automatically save the desired temperature.
- Page 11 6. Down light effect Press button. The icon will flash on the remote. Press the to adjust the light brightness on the down light effect. There are 5 settings, full to no light. Press button to adjust the colours from number 1 to 7 and then press stop operating the remote for 3 seconds and it will automatically save the desired setting selected.
- Page 12 (1).The first screen that appears is the CLOCK setting screen: Press the SET button, SET on the screen and the Hours will blink, Press UP or DOWN button to scroll the hour settings. Press the SET button, the Minutes will blink, Press UP or DOWN button to scroll the minute settings.
- Page 13 (3) The third screen that appears is the Weekly timer schedule ② The setting procedure same as schedule ① . Press the clock button when home screen, ① icon displayed on the screen, the weekly schedule ① will be enabled, press again clock button, ② icon displayed on the...
- Page 14 screen, the weekly schedule ② will be enabled. Press clock button no ① or ② displayed on the screen, the weekly timer schedule will be disabled. (4) Check your weekly timer schedule setting. Press the clock button and hold 3 seconds ， press to check weekly schedule ①...
- Page 15 9 Background Volume Press button to adjust background volume. The three volume settings are mute 10 Resetting the Remote control If the remote control does not operate correctly,please take out the battery for resetting remote to factory setting Open the back cover take out the battery and put in the battery.
-
Page 16: Maintenance
Maintenance Always isolate the power from the mains and ensure the fire has cooled down before any cleaning or maintenance is undertaken. Cleaning the appliance Do not use abrasive cleaners on the appliance. Do not spray liquids directly onto the appliance. When cleaning the glass spray glass cleaner onto a cloth and then clean glass, buff dry with a lint free cloth. -
Page 17: Warranty
/ accidently damage caused by transit / improper installation / serial numbers missing or modified. Heat Design shall not be liable for any consequential loss or damage whatsoever arising from or in connection with this electric fire. Service calls and installation errors are not covered under manufacturer warranty. A call out charge will apply. - Page 18 Heat Design Unit 60, Hawthorn Road, Western Industrial Estate, Naas Road Dublin 12. Email Info@heatdesign.ie Rev 1.3 – 24/12/21...
