Technical specification
Materials
Valve body:
Shutter, seats and slide guides:
Springs:
Seals:
Adjustment knob:
* Meets the "lead free" requirement of Section 1417 of the
Safe Drinking Water Act (SDWA). This product has a weighted
average lead content of less than 0.25% for its wetted surfaces
contacted with consumable water.
Performance
Suitable fluids:
Setting range:
Factory-setting: limited to 120 ° F (50 ° C)
Tolerance:
Max. working pressure (static): 150 psi (10 bar)
Max. working pressure (dynamic): 75 psi (5 bar)
Max. hot water inlet temperature:
Max. inlet pressure ratio (H/C or C/H) for optimal
performance:
In ASSE 1017 mode
Minimum temperature difference between hot
water inlet and mixed water outlet for stable
operation with balanced supply pressure conditions:
Recommended minimum
difference between
mixed water outlet for optimal performance:
Required minimum
between hot water
water outlet for thermal shut-off function:
In ASSE 1070 mode
Recommended minimum
difference between
mixed water outlet for optimal performance:
Required minimum
between hot water
water outlet for thermal shut-off function:
DZR low-lead* brass
PSU
stainless steel
peroxode-cured EPDM
ABS
water
95–150 ° F (35–65 ° C)
±3 ° F (±2 ° C)
195 °F (90 °C)
2:1
9 °F (5 °C)
temperature
hot water inlet and
18 °F (10 °C)
temperature difference
inlet and mixed
18 °F (10 °C)
temperature
hot water inlet and
27 °F (15 °C)
temperature difference
inlet and mixed
27 °F (15 °C)
Flow coefficient:
Minimum flow rate for stable operation with
balanced supply pressure condictions:
Maximum flow rate for temperature stability:
Mixed outlet temperature gauge:
Dual-scale 32 ° F to 210 ° F (0 °C to 100 °C)
Certifications:
1.
ASSE 1017, CSA B125.3, UPC, IPC, IRC
and NPC for use in accordance with U.S. and
Canadian plumbing codes. Certified and listed by
ICC-ES, File PMG 1357.
2. ASSE 1070/ASME A112.1070/CSA B125.70
and CSA B125.3. Certified and listed by ICC-ES,
PMG File 1358.
3.
NSF/ANSI /CAN 372, Drinking Water System
Components-Lead Content Reduction of Lead in
Drinking Water Act, California Health and Safety
Code 116875 S.3874, Reduction of Lead in Drinking
Water Act, certified by ICC-ES, file PMG-1360.
4. PEX crimp fittings certified to ASTM F 1807.
5. PEX expansion fittings certified to ASTM F 1960.
2
Cv=2.0 (Kv=1.7)
0.5 gpm (2 l/min)
9 gpm (34 l/min)
2" diameter
Accuracy: 1% full-scale
