- Page 1 Manuale di uso, manutenzione ed installazione Use, maintenance and installation manual Italiano English 81320188 31.07.2023...
-
Page 3: Table Of Contents
Table of Contents 1. Particulars ....................6 ................6 ECLARATION OF CONFORMITY 1.1.1 DINET Declaration of conformity ............... 7 ....................7 OCUMENTATION ......................8 ESCRIPTION ....................... 8 ODELS 1.4.1 DIWIFI and DINET ..................8 1.4.2 DIWIFI/IP ....................8 DIWIFI DIWIFI/IP TECHNICAL SPECIFICATIONS AND STANDARDS .......................... - Page 4 DIWIFI/IP - T ..............25 ERMINAL CONNECTION DIWIFI/IP - C ........26 ONNECTION TO ILANCIAI TERMINALS 3.5.1 EV22, D70 connection ................26 3.5.2 D430 connection ..................27 3.5.3 DILINK - ENERGY connection ..............28 DIWIFI – C ..........28 ONNECTION TO THE WIFI NETWORK 3.6.1 General information about the network ............
- Page 5 ..............41 CALE CONNECTION TO A REPEATER ......... 42 ONNECTION OF A SCALE WITH SLAVE TERMINALS ........ 43 ONNECTION OF A DUPLEX SLAVE TERMINAL TO SCALES PC ............45 ONNECTION BETWEEN A SCALE AND A 5.4.1 Archive transfer between Scale and PC ............ 46 6.
-
Page 6: Particulars
1. Particulars Declaration of conformity N° diwifi_rev.B SOCIETÀ COOPERATIVA BILANCIAI A.R.L. Via S. Ferrari, 16 41011 Campogalliano - MODENA Hereby declare under our responsibility that products DIWIFI DIWIFI/IP described in this declaration conform to the following directives. Conformity is demonstrated by compliance with the following... -
Page 7: Dinet Declaration Of Conformity
1.1.1 DINET Declaration of conformity Consult the dialogic series operation manual (D400-410-450-800, SELF/ECO800). Documentation The documentation required for using and installing the devices is the following: Manual Programma “Digi Device Discovery” http://www.digi.com/support/getasset?fn=40002265&tp=5... -
Page 8: Description
Description The modules described in this manual concern the wireless or wired (Ethernet) connection of weighing terminals manufactured by Coop Bilanciai. The weight data item and other accessory information are transmitted in the digital mode. The data item is picked up by the bus of the CPU or by an RS232 serial output. -
Page 9: Diwifi And Diwifi/Ip Technical Specifications And Standards For Use
______________________________________ DINET DIWIFI DIWIFI and DIWIFI/IP technical specifications and standards for use 1.5.1 DIWIFI Optional open board. Power supply: +5V /300mA (picked up by the DIALOGIC bus) Serial interface: TTL 0-5V on the DIALOGIC bus Antenna: dipole on positionable, reverse SMA connector. -
Page 10: Channels - Frequencies - Power
______________________________________ DINET DIWIFI 1.5.4 Channels - Frequencies - Power Channel Low - channel center - high frequency [GHz] MAX power [dBm=mW] [N°] 2,401 - 2,412 - 2,423 2,406 - 2,417 - 2,428 2,411 - 2,422 - 2,433 2,416 - 2,427 - 2,438... -
Page 11: Use In European Union Countries
______________________________________ DINET DIWIFI 1.5.5 Use in European Union countries The DIWIFI is a Class 1 device, as established by European Community Decision 2000/299/EC (Classification of radio equipment - Board band data transmission systems - Subclass 22). As such, they can be freely sold, used and installed in European Union countries (and in all countries that comply with the 1999/5/EC directive). -
Page 12: Limitations To Use In Other Countries
______________________________________ DINET DIWIFI 1.5.7 Limitations to use in other countries By and large, the device can be used without limitations in the majority of countries throughout the world. However, the user is responsible for checking to find out whether there are any limitations. -
Page 13: Diwifi - Overall Dimensions
______________________________________ DINET DIWIFI 1.5.8 DIWIFI - Overall dimensions Figure 1 - DIWIFI assembled on D400, D410 Figure 2 - DIWIFI assembled on D800... -
Page 14: Diwifi/Ip - Overall Dimensions Of Table Model
______________________________________ DINET DIWIFI 1.5.9 DIWIFI/IP - Overall dimensions of table model Figure 3 - DIWIFI table model. Side and top view... -
Page 15: Diwifi/Ip - Overall Dimensions Of Table Mode And Drilling Template Of Wall-Mounted Model
______________________________________ DINET DIWIFI 1.5.10 DIWIFI/IP - Overall dimensions of table mode and drilling template of wall-mounted model Figure 4 - DIWIFI wall-mounted model. Front and side view DINET Technical specifications Optional open board. Power supply: +5V /300mA (picked up by the DIALOGIC bus) -
Page 16: Delivery And Installation
______________________________________ DINET DIWIFI 2. Delivery and installation DIWIFI and DINET The board should be housed in a vacant slot of the terminal. Refer to the manual of the specific weighing instrument when installing the optional boards. Proceed as shown in the following diagram. -
Page 17: Diwifi/Ip
______________________________________ DINET DIWIFI DIWIFI/IP The holder can be assembled either on a table or on a wall. However, the antenna should always be set in a vertically polarized position. Generally speaking, it is advisable to install the radio device as high as possible, with antennas in line-of-sight with the access point. -
Page 18: Wall Assembly
______________________________________ DINET DIWIFI 2.2.2 Wall assembly The board is installed in the casing by means of the fixing holes on the bottom plate furthest from the antenna’s edge. The antenna must be inserted into the core hitch and fixed to this in order to ensure IP65 protection. -
Page 19: Range
______________________________________ DINET DIWIFI Range Generally speaking, the range of the radio link is influenced by many different factors, such as: visible antennas or obstructions (ferrous materials, reinforced concrete, large glazed surfaces with metal frames) nearby interference or electromagnetic fields (motors, CRT monitors, microwave ovens, welding equipment) ... -
Page 20: Hardware Customizing And Connections
______________________________________ DINET DIWIFI 3. Hardware customizing and connections DIWIFI - View of plate at rear of terminal ANT. = Reverse SMA connector for dipole antenna LINK = connection to the Access Point DATA = data in transit RESET = button that resets to the default configuration Figure 7 - DIWIFI board closing plate 3.1.1... -
Page 21: Green Coloured Data Led
______________________________________ DINET DIWIFI The orange coloured LINK Led that remains on with an unbroken light means that an Access Point (now called AP) has been found correctly and that a link has been established with the network. If the Led goes out for 1 second every 5 it means that the DIWIFI has connected to an ad hoc network (an abnormal situation that is an alternative to recommended connection to an AP). -
Page 22: Diwifi/Ip - View Of Table/Wall Assembly
______________________________________ DINET DIWIFI DIWIFI/IP – View of table/wall assembly J2 – PIN1 LINK DATA RESET J1 – PIN1 ANT. = Reverse SMA connector for dipole antenna with closing core hitch LINK = connection to the Access Point DATA = data in transit... -
Page 23: Diwifi - Jumpers
______________________________________ DINET DIWIFI DIWIFI - Jumpers KEY: JP1, JP2, JP3 = see table of power supplies JP4 = OFF normal operation = ON momentarily causes hardware reset JP5 = OFF normal operation = ON diagnostics (reserved operating mode) JP6 = 1-2 ON for DIWIFI/IP (RX from terminal) = 2-3 ON for DIWIFI (RX from bus) Figure 9 –... -
Page 24: Dinet - Jumpers
______________________________________ DINET DIWIFI 3.3.1 DINET - Jumpers The jumpers on the DINET correspond to those on the DIWIFI and have the same meanings. With reference to Figure 9 – on page 23, position: JP1=JP2=JP3=OFF JP4=JP5=OFF JP6=2-3 ON... -
Page 25: Diwifi/Ip - Terminal Connection
______________________________________ DINET DIWIFI DIWIFI/IP - Terminal connection As mentioned in paragraph 2.2.2 on page 18, in the wall-mounted version the connection cable must be inserted into the core hitch and connected to the terminals, bearing the following table in mind. -
Page 26: Diwifi/Ip - Connection To Bilanciai Terminals
______________________________________ DINET DIWIFI DIWIFI/IP - Connection to Bilanciai terminals 3.5.1 EV22, D70 connection Once the wall or table configuration has been chosen, connect the serial link in the following ways. Key: 1 = Wall-mounted power transformer J1,J2 = DIWIFI/IP terminals COM = COM1 or COM2 (9-pin male connector) Figure 10 –... -
Page 27: D430 Connection
______________________________________ DINET DIWIFI 3.5.2 D430 connection Key: 1 - Input core hitch 2 - Screen of ground cable in core hitch COM1 - Preferential RS232 connection COM2 - Alternative RS232 connection J18 - Powering terminal on pin 5 (+5 Vdc) Figure 11 –... -
Page 28: Dilink - Energy Connection
______________________________________ DINET DIWIFI 3.5.3 DILINK - ENERGY connection This connection is described in the manual dedicated to the system with ENERGY solar panels. DIWIFI – Connection to the wifi network 3.6.1 General information about the network The wifi network must have an Access Point (AP). -
Page 29: Dinet - Connection To The Ethernet
______________________________________ DINET DIWIFI DINET – Connection to the Ethernet 3.7.1 Particulars A DHCP server must be available in the network. It is only required for the initial programming phase. The network administrator must provide the IP addresses of the scales or terminals to be added to the network. -
Page 30: Green Coloured Data Led
______________________________________ DINET DIWIFI 3.7.4 Green coloured DATA Led The flashing green DATA led indicates that there is traffic in the network. 3 consecutive blinks on powering or after a reset indicate a correct restart. 3.7.5 Reset button The RESET button restarts the link or sets the board to the default configuration (also consult par.6.2 on page 48). -
Page 31: Customizing Of Software Parameters
______________________________________ DINET DIWIFI 4. Customizing of software parameters To customize the parameters of the DIWIFI/DINET boards, these latter must be reached by means of an AP using the Digi Device Discovery program or by means of a common browser if the IP number is known. -
Page 32: Access To The Board
______________________________________ DINET DIWIFI Attention An error indication will be displayed if the device appears with an IP number that does not belong to its sub-network. This means that the DIWIFI/DINET is on, that it has been able to connect itself, but that it has not received the IP number from the DHCP server. -
Page 33: Login
______________________________________ DINET DIWIFI Login By default, access with: user=admin password=cbadmin A menu will appear on the left-hand side while the main information of the module will appear on the right, in a box. After the device has been programmed, it is advisable to change the admin password (follow the pathway users>admin). -
Page 34: Wireless Security Settings (Only Diwifi)
______________________________________ DINET DIWIFI Enable short preamble: if present in the network, activate this function to speed up the connection speed, otherwise leave it deactivated, as by default. 4.4.3 Wireless Security Settings (only DIWIFI) Enter this section according to the Network Administrator's indications. -
Page 35: Configuration>Serial Ports
______________________________________ DINET DIWIFI Configuration>Serial Ports 4.5.1 Port Profile Settings Select Change profile for other serial link management modes. The recommended modes are: Serial Bridge (default) UDP Sockets The other modes present are not tolerated and remain reserved for future applications. -
Page 36: Serial Bridge Profile / Basic Serial Settings
______________________________________ DINET DIWIFI 4.5.3 Serial Bridge Profile / Basic Serial Settings The parameters of the serial link are entered in this section. These values must match the connected device. For example: Set up com2 if the board has been inserted into a D400, D410, D450. -
Page 37: Udp Sockets Profile / Basic Serial Settings
______________________________________ DINET DIWIFI 4.5.6 UDP Sockets Profile / Basic Serial Settings The same considerations as given for the Serial Bridge profile are also valid in this case. See par 4.5.3 on page 36 4.5.7 UDP Sockets Profile / Advanced Serial Settings Nothing is set by default. -
Page 38: Default Unique Password
______________________________________ DINET DIWIFI Default Unique Password Effective January 1, 2020, the California Consumer Privacy Act SB-327 requires all cellular and Internet connected devices manufactured after that date to have unique default passwords for each device. This requirement increases security and reduces the likelihood of malicious intrusions and attacks. - Page 39 ______________________________________ DINET DIWIFI CARD RESET (unchanged): the operation is carried out by pressing and holding the small button under the card connector for at least 15 seconds. Notes for users and passwords: after resetting to the factory parameters, it is possible to recreate the "admin" user by replacing the "root" user in order to enter the setup as in the old cards.
-
Page 40: Examples
Since the DIWIFI/DINET board is so versatile, it can be used in various different configurations. The DIWIFI/DINET device allows connections to be made both between Bilanciai terminals and between external units like PC PLC, so long as they have an interface towards the network with TCP/IP protocol. -
Page 41: Scale Connection To A Repeater
______________________________________ DINET DIWIFI Scale connection to a repeater Example with specific IP addresses. D800 Scale D410 Slave terminal When programming the terminal, When programming the terminal, access the setup mode and access the setup mode and configure: configure: Main scale ... -
Page 42: Connection Of A Scale With 2 Slave Terminals
______________________________________ DINET DIWIFI Connection of a scale with 2 slave terminals Example with IP broadcast address of the scale and specific IP of the slaves. D800 Scale D410 First slave D410 Second slave terminal terminal Program the terminals in the same way as the previous example Access the board configuration with a browser. -
Page 43: Connection Of A Duplex Slave Terminal To 2 Scales
______________________________________ DINET DIWIFI Connection of a duplex slave terminal to 2 scales Example with IP broadcast addresses only. D800 duplex slave D410 scale A D410 scale B When programming the When programming When programming the terminal, access the setup the terminal, access... - Page 44 ______________________________________ DINET DIWIFI 172.17.6.11 172.17.6.11 Repeat the operation for both scale terminals 172.17.6.12 172.17.6.13 Select transmission after 20 ms. Note:* For the sake of mnemonic convenience, the terminal number has been set as the last number of the IP address in these examples.
-
Page 45: Connection Between A Scale And Apc
______________________________________ DINET DIWIFI Connection between a scale and a PC Example with specific IP addresses. D800 Scale When programming the terminal, With hyperterminal, connect to: access the setup mode and host address=172.17.6.11 configure: port=2101 Extended string, cyclic on com3 connect=TCP/IP (winsock) ... -
Page 46: Archive Transfer Between Scale And Pc
______________________________________ DINET DIWIFI 5.4.1 Archive transfer between Scale and PC Files/archives are not transferred via FTP but via remote commands. Command Response Description &L<CR> Example: Requests the list of files (R) reading only file nome_file_1.ext (RW) reading and writing file LOGO.BMP(RW) -
Page 47: Troubleshooting
______________________________________ DINET DIWIFI 6. Troubleshooting Faults Fault. The DIWIFI device cannot be reached with the browser at the known address. Remedy. If the LINK led is on with a fixed light, the device is connected to an AP. -
Page 48: How To Restore The Factory Configuration Data
______________________________________ DINET DIWIFI How to restore the factory configuration data Attention Only the Manufacturer’s Authorized Technicians may carry out this operation. All previously entered data will be lost and the factory configuration will be restored. Unless it is carried out with precision, incongruous data may be entered during the procedure and could prevent the DIWIFI device from starting up again. -
Page 49: Maintenance
______________________________________ DINET DIWIFI 7. Maintenance Disposal This symbol on the device purchased means that: this electrical or electronic device cannot be disposed of as solid urban waste; it must be disposed of separately; it can be returned to the dealer when a new one is purchased;... - Page 51 SOC. COOP. BILANCIAI CAMPOGALLIANO A.R.L. 41011 Campogalliano (MO) Via Ferrari, 16 tel. +39 (0) 59 893611 – fax +39 (0) 59 527079 home page: http://www.coopbilanciai.it E-mail: cb@coopbilanciai.it servizio post-vendita after sales service service apres-vente Kundendienstservice servicio post-venta serviço pós-venda tel. +39 (0) 59 893612 – fax +39 (0) 59 527294...
