PRODUCT OVERVIEW

Le stick (press for L3)
1.
2. View button
3. Home button
4. Menu button
5. Function buttons
6. Turbo button
7. Directional pad (D-pad)
8. Right stick (press for R3)
9. Status LED
10. Right bumper and trigger
11. Le bumper and trigger
12. USB connector (for data only)
Mode switch (located on back of controller)
13.
USB Wireless Adapter (ships inside the
14.
Controller battery compartment).
15. USB data cable
02
3
2 4
1
6
7
8
9
10
12
13
5
11
14
15
