Gioteck GC2PS3-11 Operational Manual

Goodbetterbest Limited
Suites 103-107, Devonshire Business Centre, Works Road, Letchworth, SG6 1GJ, United Kingdom
Tel: +44(0) 1462 472390
GC2PS3-11 GC-2
GC-2 Wireless Controller
operational Manual
Feature :
- 8 functional buttons: O, X, △,
- x Triggers L2, R2
- Select / Start Button
- Home Button
- Directional Pad
- 2 x Rumble Motors
- mini joystick buttons, L3, R3
- Mini USB Jack for USB mode and battery charging
- Powered by built-in Li-ion Battery
- Channel LED, Turbo LED
- Turbo feature
- Thumb stick sensitivity
- USB mode and BT(Bluetooth) mode
- In BT mode, it supports tablets with Android 3.2+ and complaint to the SIXAXIS Controller APK.
- In USB mode, it supports tablets with Android 3.2+ and complaint to the SIXAXIS Controller APK
- Connects to PC via USB cable and functions as a USB game controller
A) Connecting the GC2PS3 game pad
To connect the GC2PS3 game pad
1. Plug in the USB cable to GC2PS3 game pad mini USB port, then connect the USB Port #1 on the PS3 Console.
This can be done with PS3 already be turned on.
2. Press the "Home" Button on the GC2PS3 game pad. The GC2PS3 will select the port automatically, and the corresponding
LEDs light.
LED
1
2
3
4
1+4
2+4
3+4
3. Now, you can enjoy the game play with Gioteck wireless game pad in USB mode.
4. Unplug the USB cable, the GC2PS3 will automatically connect to PS3 console by BT mode, and the corresponding LEDs light.
5. The GC2PS3 game pad is properly set up for PS3 connection. Simply press the "Home" button once to link up to PS3
for all subsequent connection.
B) Turbo function
Buttons support turbo feature are O, △,
All turbo buttons are synchronized
All turbo buttons are with the same speed of 8Hz.
To program a button with Turbo function, press [TURBO] and the [button] at the same time. LED flashes in 8Hz
Press again the [TURBO] and the [button] at the same time to cancel the turbo function. LED remains OFF.
Once power off, all buttons returns to default without Turbo function.
C) Thumb stick sensitivity
4 levels settings are available.
Level 1 is normal in 100%
Level 2 is with 75%, moves the thumb stick 1.5 times faster in speed
Level 3 is with 50%, moves the thumb stick 2 times faster in speed
Level 4 is with 25%, moves the thumb stick 4 times faster in speed
To set up the sensitivity, press and hold the [Turbo] button, flick the thumb stick left and right to toggle and advance to
Email: carol@gbbgroup.com
□
, L1, R1
PORT
1
2
3
4
5
6
7
□
, X, L1, L2, R1, R2
