PRO™ SERIES HIGH RATE SAND FILTERS
Basic safety precautions should always be followed, including the following: Failure to follow instructions can cause severe
injury and/or death.
This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for one of the
following signal words and be alert to the potential for personal injury.
WARNING
warns about hazards that could cause serious personal injury, death or major property damage and if
ignored presents a potential hazard.
CAUTION
warns about hazards that will or can cause minor or moderate personal injury and/or property damage
and if ignored presents a potential hazard. It can also make consumers aware of actions that are unpredictable and unsafe.
The NOTICE label indicates special instructions that are important but not related to hazards.
Use only High Rate Sand No. 20 Silica Sand (.45mm - .55mm)
HAYWARD POOL PRODUCTS, INC.
620 Division Street
OWNER'S MANUAL
INSTALLATION, OPERATION & PARTS
MODELS S210SV, S244SV
SAVE THIS INSTRUCTION MANUAL
Elizabeth, NJ 07207
WWW.HAYWARDPOOL.COM
Tel: 908-351-5400
IS210SV
Rev B
Advertisement
Table of Contents
Related Manuals for Hayward Pool Products PRO S210SV
Summary of Contents for Hayward Pool Products PRO S210SV
- Page 1 The NOTICE label indicates special instructions that are important but not related to hazards. SAVE THIS INSTRUCTION MANUAL Use only High Rate Sand No. 20 Silica Sand (.45mm - .55mm) HAYWARD POOL PRODUCTS, INC. 620 Division Street Elizabeth, NJ 07207 Tel: 908-351-5400 WWW.HAYWARDPOOL.COM...
- Page 2 Page 2 of 8 MODEL S210SV, S244SV IS210SV Rev B - WARNING - Read and follow all instructions in this owner’s manual and on the equipment. Failure to follow instructions can cause severe injury and/or death. WARNING – Suction Entrapment Hazard. Suction in suction outlets and/or suction outlet covers which are, damaged, broken, cracked, missing, or unsecured can cause severe injury and/or death due to the following entrapment hazards: Hair Entrapment- Hair can become entangled in suction outlet cover.
-
Page 3: How It Works
MODEL S210SV, S244SV IS210SV Rev B Page 3 of 8 WARNING – Electrical Ground motor before connecting to electrical power supply. Failure to ground pump motor can cause serious or fatal electrical shock hazard. – WARNING Do NOT ground to a gas supply line. WARNING –... - Page 4 No returns may be made directly to the factory without the that all connections have been made and are secure. expressed authorization of Hayward Pool Products, Inc. IMPORTANT: To prevent unnecessary strain on piping system and valving, always shut off pump before PLEASE REALIZE: switching Filter Control Valve positions.
-
Page 5: Specifications
MODEL S210SV, S244SV IS210SV Rev B Page 5 of 8 SPECIFICATIONS EFFECTIVE MAXIMUM REQUIRED CLEARANCE MEDIA REQUIRED FILTRATION WORKING MODEL SIDE ABOVE TYPE AMOUNT AREA PRESSURE NUMBER INCH INCH FILTER SAND** S210SV 3.45 0.45-0.55mm S244SV 3.45 0.45-0.55mm **Also known as No. 20 Silica Sand. TABLE 1 PARTS Models S210SV, S244SV... -
Page 6: Product Registration
MODEL S210SV, S244SV IS210SV Rev B Page 6 of 8 MAXIMUM RECOMMENDED SYSTEM FLOW RATE BY PIPE SIZE Pipe Size Flow rate Pipe Size Flow rate Pipe Size Flow rate [mm] GPM [Liter/Min] [mm] GPM [Liter/Min] [mm] GPM [Liter/Min] 1” 1 ½”... - Page 7 Hayward Pool Products, Inc. To original purchasers of this equipment, Hayward Pool Products, Inc. warrants its vacuum release systems to be free from defects in materials and workmanship for a period of ONE (1) year from the date of purchase.
- Page 8 MODEL S210SV, S244SV IS210SV Rev B Page 8 of 8 THIS PAGE LEFT BLANK WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
