Basic safety precautions should always be followed, including the following: Failure to follow instructions can cause severe
injury and/or death.
This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for one of the
following signal words and be alert to the potential for personal injury.
WARNING
warns about hazards that could cause serious personal injury, death or major property damage and if
ignored presents a potential hazard.
CAUTION
warns about hazards that will or can cause minor or moderate personal injury and/or property damage
and if ignored presents a potential hazard. It can also make consumers aware of actions that are unpredictable and unsafe.
The NOTICE label indicates special instructions that are important but not related to hazards.
Use only High Rate Sand No. 20 Silica Sand (.45mm - .55mm)
HAYWARD POOL PRODUCTS, INC.
620 Division Street
OWNER'S MANUAL
INSTALLATION, OPERATION & PARTS
SAVE THIS INSTRUCTION MANUAL
Elizabeth, NJ 07207
WWW.HAYWARDPOOL.COM
MODELS:
S170TSCPE
S190TSCPE
S190TSCPFT
S190TSCPT
HIGH-RATE SAND
FILTER
Tel: 908-351-5400
IS170TSC
Rev. B
Advertisement
Table of Contents
Related Manuals for Hayward Pool Products Dream Line S170TSCPE
Summary of Contents for Hayward Pool Products Dream Line S170TSCPE
- Page 1 The NOTICE label indicates special instructions that are important but not related to hazards. SAVE THIS INSTRUCTION MANUAL Use only High Rate Sand No. 20 Silica Sand (.45mm - .55mm) HAYWARD POOL PRODUCTS, INC. 620 Division Street Elizabeth, NJ 07207 Tel: 908-351-5400 WWW.HAYWARDPOOL.COM...
- Page 2 Page 2 of 8 IS170TSC Rev B - WARNING - Read and follow all instructions in this owner’s manual and on the equipment. Failure to follow instructions can cause severe injury and/or death. WARNING – Suction Entrapment Hazard. Suction in suction outlets and/or suction outlet covers which are, damaged, broken, cracked, missing, or unsecured can cause severe injury and/or death due to the following entrapment hazards: Hair Entrapment- Hair can become entangled in suction outlet cover.
- Page 3 Page 3 of 8 IS170TSC Rev B WARNING – To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical connections. WARNING – Failure to bond pump to pool structure will increase risk for electrocution and could result in injury or death. To reduce the risk of electric shock, see installation instructions and consult a professional electrician on how to bond pump.
- Page 4 Page 4 of 8 IS170TSC Rev B INITIAL START-UP OF FILTER RINSE—After backwashing, with pump off, set valve to 1. Be sure correct amount of filter sand media is in tank and RINSE. Start pump and operate for about 1/2 to 1 minute. that all connections have been made and are secure.
- Page 5 Page 5 of 8 IS170TSC Rev B SPECIFICATIONS EFFECTIVE MAXIMUM REQUIRED CLEARANCE MEDIA REQUIRED MODEL DESIGN FILTRATION WORKING SIDE ABOVE TYPE AMOUNT FLOW RATE AREA PRESSURE INCH INCH FILTER SAND** S170TSCP 0.14 3.45 0.45-0.55 mm S190TSCP 0.17 3.45 0.45-0.55 mm **Also known as No.
- Page 6 Page 6 of 8 IS170TSC Rev B MAXIMUM RECOMMENDED SYSTEM FLOW RATE BY PIPE SIZE Pipe Size Flow rate Pipe Size Flow rate Pipe Size Flow rate [mm] GPM [Liter/Min] [mm] GPM [Liter/Min] [mm] GPM [Liter/Min] 1” 1 ½” 2 ½” [32] [75] [50]...
- Page 7 Hayward Pool Products, Inc. To original purchasers of this equipment, Hayward Pool Products, Inc. warrants its vacuum release systems to be free from defects in materials and workmanship for a period of ONE (1) year from the date of purchase.
- Page 8 Page 8 of 8 IS170TSC Rev B THIS PAGE LEFT BLANK WWW.HAYWARDPOOL.COM USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
