Summary of Contents for Amacam AM-DC07
- Page 1 AM-DC07 User Manual support@amacam.net Ver 3.0 www.amacam.net...
- Page 2 In the Box 1 x Camera AM-DC07 1 x Camera Mount 1 x Power Cable with GPS 2 x Adhesive Pad 2 x Screen Mount Film 1 x Pry Tool 1 x Lens Cloth 1 x User Manual 1 x USB Card Reader & Adapter...
-
Page 3: Installation
Installation 1. Attach the camera onto the mount. 2. Select an ideal location (A or B) on the windscreen near the rear-view mirror. 3. Remove the protective film from the adhesive pad and firmly affix the mount onto the windscreen. 4. -
Page 4: Screen Overview
Shortcut Keys All the following shortcut keys are applicable in Recording Mode Mute/Unmute the microphone Short Press Switch screen between front and rear views Long Press Pause recording Short Press Long Press Power On/Off Take a snapshot Short Press DOWN Lock/Unlock the current video clip Long Press Screen Overview... -
Page 5: Menu Settings
Time Current time HH/MM/SS Date Current date YYYY/MM/DD Audio is being recorded Menu Settings Short press OK to pause recording then long press UP Enter Menu UP/DOWN to navigate press；OK to confirm；Long press Down to Set parameters switch video and setup menu Exit Menu Long press UP to go back to Recording Mode Menu Details... - Page 6 Note Bitrate 1440P 30FPS 1080P30FPS Super Fine 16Mbps 10Mbps Fine 12Mbps 8Mbps Infrared Guide 1.IR mode “Auto” means the camera automatically turns on/off infrared night vision. Its working principle is, by presetting the threshold value of luminance to sense the changes of luminance through the front lens: (a) If ambient luminance is less than the threshold value in any moment.
- Page 7 Video: (A is main lens,B is secondary lens) Photo: (A is main lens,B is secondary lens) View Camera Recordings There are two options for viewing the recorded video footage. 1. Connect the camera directly to a computer using a suitable USB data cable. Press the DOWN button on the camera simultaneously as the data cable connects.
-
Page 8: Firmware Upgrade
Search for “GXPlayer” at the Apple Store. Then download and install the software. To view the recorded videos, select “Open File” in the player and select the SD card then press “OK” The video files will load up into the player. Please see the picture below. -
Page 9: Specifications
Specifications Main Processor NT96675 Image Sensor Front: GK4653 4-megapixel CMOS Rear: GK2053 2-megapixel CMOS Lens Front: 140° view angle; 6-layer glasses; 1 infrared filter Rear: 130° view angle. with 8pcs infrared LED LCD screen 1.5’’ TFT LCD G-sensor Built-in; 3-axis; sensitivity 3-level adjustable System Language English Français Españ... -
Page 10: Troubleshooting
If the camera has not been used for a long time it may take longer to boot up due to the initial conditioning of the super capacitor. This is normal and not a fault. The camera does not have a built-in battery. support@amacam.net www.amacam.net...
