Nexx XCOM3 User Manual

Motorcycle bluetooth communication system
Hide thumbs Also See for XCOM3:
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S GUIDE
MOTORCYCLE BLUETOOTH
COMMUNICATION SYSTEM
Version 1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XCOM3 and is the answer not in the manual?

Questions and answers

Related Manuals for Nexx XCOM3

Summary of Contents for Nexx XCOM3

  • Page 1 USER’S GUIDE MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM Version 1.0.0...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Sena Motorcycles App and NEXX Device Manager ABOUT THE X-COM 3 1.1 PRODUCT FEATURES 1.2 PACKAGE CONTENTS 1.3 PRODUCT DETAILS INSTALLING THE HEADSET ON YOUR HELMET 2.1 PREPARING THE HELMET FOR INSTALLATION 2.2 INSTALLING THE HEADSET 2.3 INSTALL THE INNER PADDING GETTING STARTED 3.1 LEGEND...
  • Page 3 7.2 LAST-COME, FIRST-SERVED 7.3 TWO-WAY INTERCOM 7.4 MULTI-WAY INTERCOM 7.4.1 Starting a Three-Way Intercom Conference 7.4.2 Starting a Four-Way Intercom Conference 7.4.3 Ending Multi-Way Intercom 7.5 THREE-WAY CONFERENCE PHONE CALL WITH INTERCOM USERS 7.6 GROUP INTERCOM UNIVERSAL INTERCOM 8.1 UNIVERSAL INTERCOM PAIRING 8.2 TWO-WAY UNIVERSAL INTERCOM 8.3 MULTI-WAY UNIVERSAL INTERCOM 8.3.1 Three-Way Universal Intercom...
  • Page 4 11.2.10 Background Volume (Default: Level 5) 11.2.11 Sidetone (Default: Disable) 11.2.12 Voice Prompt (Default: Enable) 11.2.13 RDS AF Setting (Default: Disable) 11.2.14 FM Station Guide (Default: Enable) 11.2.15 Advanced Noise Control™ (Always On) 11.2.16 Region Selection 12 TROUBLESHOOTING 12.1 FACTORY RESET 12.2 FAULT RESET 13 QUICK REFERENCE X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 5: Sena Motorcycles App And Nexx Device Manager

    • Download the Sena Motorcycles App on Google Play Store Store. NEXX Device Manager The NEXX Device Manager allows you to upgrade firmware and configure settings directly from your PC. NEXX Device Manager • Download the NEXX Device Manager at https://oem.sena.com/NEXX/.

  • Page 6: About The X-Com 3

    ABOUT THE X-COM 3 1.1 PRODUCT FEATURES • Audio Multitasking™ • Four-way Intercom • Bluetooth Intercom Up to 1.6 km (1.0 mi) in open terrain • Advanced Noise Control™ • Bluetooth ® 1.2 PACKAGE CONTENTS × 2 Hook and Loop Fasteners X-COM 3 for Speakers Hook and Loop Fastener...

  • Page 7: Product Details

    1.3 PRODUCT DETAILS ① Pinhole Fault Reset Button ② Battery Module ③ Speaker (R) ④ Microphone ⑤ Center Button ⑥ (−) Button ⑦ Speaker (L) ⑧ Bluetooth Intercom Antenna ⑨ Button Module ⑩ (+) Button ⑪ Status & Charging LED ⑫ DC Power Charging &...

  • Page 8: Installing The Headset On Your Helmet

    INSTALLING THE HEADSET ON YOUR HELMET The following NEXX helmets are compatible with the X-COM 3. • Y.100, Y.100 R, X.WST3, X.WED3 2.1 PREPARING THE HELMET FOR INSTALLATION Inner Padding X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...
  • Page 9 Module Cover X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 10: Installing The Headset

    2.2 INSTALLING THE HEADSET Battery Module X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...
  • Page 11 Button Module X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...
  • Page 12 Speakers X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...
  • Page 13 Bluetooth Antenna, Microphone X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 14: Install The Inner Padding

    2.3 INSTALL THE INNER PADDING Inner Padding X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 15: Getting Started

    2.5 hours. Note: • Any 3rd party USB charger can be used with NEXX products if the charger is approved by FCC, CE, IC, or other locally approved agencies. • Using a non-approved charger may cause fire, explosion, leakage, and other hazards which may also reduce the lifetime or performance of the battery.

  • Page 16: Checking The Battery Level

    3.4 CHECKING THE BATTERY LEVEL Instructions are for when powering the headset on or off. Powering On “ Battery level is high/medium/low” Note: When the battery is low while in use, you will hear a voice prompt saying “Low battery.” 3.5 VOLUME ADJUSTMENT You can raise or lower the volume by tapping the (+) Button or the (-) Button.

  • Page 17: Pairing The Headset With Other Bluetooth Devices

    PAIRING THE HEADSET WITH OTHER BLUETOOTH DEVICES When using the headset with other Bluetooth devices for the first time, they will need to be “paired.” This enables them to recognize and communicate with one another whenever they are within range. The headset can pair with multiple Bluetooth devices such as a mobile phone or GPS via Mobile Phone Pairing, Second Mobile Phone Pairing and GPS Pairing.

  • Page 18: Starting With Your Headset Powered Off

    4.1.2 Starting with Your Headset Powered Off 1. While the headset is off, press and hold the Center Button and the (+) Button for 5 Seconds. Blinking HOLD “Phone pairing” 2. Select X-COM 3 in the list of Bluetooth devices detected. X-COM 3 4.1.3 Starting with Your Headset Powered On 1.

  • Page 19: Second Mobile Phone Pairing

    4.2 SECOND MOBILE PHONE PAIRING 1. Press and hold the Center Button for 10 seconds. HOLD “Configuration menu” 2. Double tap the (+) Button. Blinking “ Second mobile phone pairing” 3. Select X-COM 3 in the list of Bluetooth devices detected. X-COM 3 4.3 GPS PAIRING 1.

  • Page 20: Mobile Phone Usage

    5.2 SPEED DIALING 5.2.1 Assigning Speed Dial Presets Speed Dial Presets could be assigned in the settings menu, accessible through the Sena Motorcycles App or the NEXX Device Manager. 5.2.2 Using Speed Dial Presets 1. Enter into the Speed Dial menu.
  • Page 21 3. Call one of your Speed Dial Presets. “ Speed dial (#)” 4. Redial the last number called. “ Last number redial” X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 22: Stereo Music

    STEREO MUSIC 6.1 BLUETOOTH STEREO MUSIC Play/Pause HOLD Track Forward Track Backward HOLD HOLD 6.2 MUSIC SHARING You can start sharing Bluetooth stereo music with one intercom friend during a Two-way Intercom conversation. When you terminate music sharing, you can go back to the intercom conversation.

  • Page 23: Bluetooth Intercom

    5. Tap Scan ) and repeat steps 3-4 to pair with Intercom Friends (C) and (D). Note: The Smart Intercom Pairing (SIP) is not compatible with NEXX products that use Bluetooth 3.0 or below. X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 24: Using The Button

    7.1.2 Using the Button Users (You, B) enter into Intercom Pairing. Blinking HOLD “ Intercom pairing” 2. Tap the Center Button on either headsets. Turns white 3. Repeat the steps above to pair with other headsets (C and D). 7.2 LAST-COME, FIRST-SERVED The intercom pairing queue is Last-Come, First-Served.

  • Page 25: Two-Way Intercom

    7.3 TWO-WAY INTERCOM You can start or end an intercom conversation with an Intercom Friend. Intercom Intercom Intercom Friend1 Friend2 Friend3 Start/End Conversation with the First Intercom Friend D Start/End Conversation with the Second Intercom Friend C Start/End Conversation with the Third Intercom Friend B 7.4 MULTI-WAY INTERCOM Multi-Way Intercom enables conference-call-style conversations with up to three Intercom Friends at the same time.

  • Page 26: Starting A Four-Way Intercom Conference

    1. You (A) need to be paired with two other Intercom Friends (B and C) for the Three-Way Intercom Conference. Intercom Intercom Friend1 Friend2 2. Start an intercom conversation with the First Intercom Friend (C) by tapping the Center Button. Intercom Intercom Friend1...

  • Page 27: Ending Multi-Way Intercom

    3. Now you (A), two Intercom Friends (B and C), and a new participant (D) are having a Four-Way Intercom Conference. Intercom Intercom Participant Friend1 Friend2 7.4.3 Ending Multi-Way Intercom You can completely terminate the conference intercom or just disconnect an intercom connection with one of your active Intercom Friends.

  • Page 28: Three-Way Conference Phone Call With Intercom Users

    7.5 THREE-WAY CONFERENCE PHONE CALL WITH INTERCOM USERS You can have a Three-Way Conference Phone Call by adding an Intercom Friend to the mobile phone conversation. 1. During a mobile phone call, tap the Center Button once, twice, or three times to invite one of your Intercom Friends to the conversation.

  • Page 29: Group Intercom

    7.6 GROUP INTERCOM Group Intercom allows you to instantly create a Multi-Way Conference Intercom with three of the most recently paired headsets. To Start the Group Intercom 1. Go through intercom pairing with up to three headsets you want to have Group Intercom with.

  • Page 30: Universal Intercom

    Bluetooth headsets. Non-NEXX Bluetooth headset can be connected to the NEXX headset if they support the Bluetooth Hands-Free Profile (HFP). You can pair the headset with only one non-NEXX headset at a time. The intercom distance depends on the performance of the headset to which it’s connected.

  • Page 31: Multi-Way Universal Intercom

    If you disconnect the intercom call, the mobile phone connection is made again automatically so that you can use a mobile phone call function. 1. You (A) need to be paired with a non-NEXX Bluetooth headset (B) and another headset (C) for the Three-Way Conference Intercom. Non-NEXX Headset 2.

  • Page 32: Four-Way Universal Intercom

    4. Now you (A), non-NEXX Bluetooth headset (B), and the other headset (C) are having a Three-Way Conference Intercom. Non-NEXX Headset 8.3.2 Four-Way Universal Intercom You may make the Four-Way Universal Intercom call the same way as a normal Four-Way Intercom call.

  • Page 33: Using The Fm Radio

    USING THE FM RADIO 9.1 FM RADIO ON/OFF FM Radio On HOLD “ FM on” FM Radio Off HOLD “ FM off” 9.2 SEEK AND SAVE RADIO STATIONS The “Seek” feature searches for radio stations. 1. Search for radio stations. Seek Stations Forward Seek Stations Backward 2.

  • Page 34: Scan And Save Radio Stations

    9.3 SCAN AND SAVE RADIO STATIONS The “Scan” function automatically searches for radio stations, starting with the current station’s frequency, then up from there. 1. Scan for stations. Start Scanning Stop scanning HOLD HOLD 2. The Sena tuner pauses at each station it finds for 8 seconds before moving to the next.

  • Page 35: Navigating Preset Stations

    9.5 NAVIGATING PRESET STATIONS Using the methods above, up to 10 radio stations can be stored. You can navigate through the saved stations. Navigate through Preset Stations HOLD X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 36: Function Priority And Firmware Upgrades

    (lowest) FM radio 10.2 FIRMWARE UPGRADES You can upgrade the firmware using the NEXX Device Manager by connecting the USB Power & Data Cable (USB-C) to your PC. Download the NEXX Device Manager at https://oem.sena.com/NEXX/. X.COM3 - MOTORCYCLE BLUETOOTH COMMUNICATION SYSTEM...

  • Page 37: Configuration Setting

    CONFIGURATION SETTING 11.1 HEADSET CONFIGURATION MENU Accessing the Configuration Navigating Between Menu Options Menu HOLD Execute Menu Options Headset Configuration Menu Voice Configuration Menu Tap the Center Button Phone Pairing None Second Mobile Phone Pairing None GPS Pairing None Delete All Pairings Execute Remote Control Pairing Execute...

  • Page 38: Software Configuration Setting

    11.2 SOFTWARE CONFIGURATION SETTING You can change the settings of the headset through the Sena Motorcycles App or the NEXX Device Manager. Sena Motorcycles NEXX Device Manager 11.2.1 Headset Language You can select or change the device language, which will stay saved even if the headset is rebooted.

  • Page 39: Vox Intercom (Default: Disable)

    11.2.4 VOX Intercom (Default: Disable) If this feature is enabled, you can initiate an intercom conversation with the last connected intercom friend by voice. When you want to start intercom, say a word such as “Hello” loudly or blow air into the microphone. If you start an intercom conversation by voice, the intercom terminates automatically when you and your intercom friend remain silent for 20 seconds.

  • Page 40: Audio Source Priority (Default: Intercom)

    11.2.8 Audio Source Priority (Default: Intercom) Audio Source Priority allows you to select the priority between the intercom and music (which includes GPS app instructions and message notifications) from a smartphone. If the intercom is selected as the Audio Source Priority, your music will be interrupted during an intercom conversation.

  • Page 41: Background Volume (Default: Level 5)

    Note: • Audio Multitasking will be activated during two-way intercom conversations with a headset that also supports this feature. • When Audio Multitasking is disabled, the background audio source will return to its independent volume level. • For Audio Multitasking to work properly, you need to power the headset off and on.

  • Page 42: Advanced Noise Control™ (Always On)

    11.2.15 Advanced Noise Control™ (Always On) The background noise is reduced during an intercom conversation. 11.2.16 Region Selection When using the region setting, you can optimize the seek function to avoid unnecessary frequency ranges, allowing you to select the proper FM frequency range for your location.

  • Page 43: Troubleshooting

    TROUBLESHOOTING 12.1 FACTORY RESET To erase all of your settings and start fresh, the headset can be restored to factory default settings using the Factory Reset feature. HOLD “ Configuration menu” “ Factory reset” “ Headset reset, good-bye” 12.2 FAULT RESET When the headset is not working properly, you can easily reset the unit: 1.

  • Page 44: Quick Reference

    QUICK REFERENCE : Center Button : (+) Button : (−) Button Type Operation Button Duration Turn on & Press 1 sec Basic Turn off & Operations Volume up/down Answer phone call End phone call Press 2 sec Phone Reject phone call Press 2 sec Usage Call a Voice Assistant...
