- Page 1 MISTRAL Assembly guide for in-line table...
-
Page 2: Need Help
MISTRAL Assembly guide for in-line table Scan the QR code to watch the assembly video. Need help? support@cozey.com +1(888) 828-8371... - Page 3 What’s in your Cozey box Mistral In-line Table Tabletop (x1) Rear Support (x1) Hardware box (x1) Legend Hand Screw M35 Hand Screw M50 (x4) (x4)
- Page 4 Empty the box. Put the tabletop on its side.
- Page 5 Align the rear support and the tabletop back screwing holes. PRO TIP The rear support must be assembled with the U-shaped frame upward.
- Page 6 Screw in the rear support to the tabletop using the M35 hand screws. PRO TIP Flip the table on its upright position.
- Page 7 Place the in-line table in the desired configuration. Built the seat modules as per indicated in the Mistral Sofas & Sectionnals Assembly Guide until reaching the in-line table.
- Page 8 YOU ARE NOW READY TO ASSEMBLE! To install the in-line table, slide the tabletop onto the last seat’s shared leg . PRO TIP...
- Page 9 Add the following shared leg under the tabletop. PRO TIP...
- Page 10 Continue building the modules as per indicated in the Mistral Sofas & Sectionals Assembly Guide until reaching the final arm.
- Page 11 Screw the tabletop into both adjacent legs using the M50 hand screws. PRO TIP...
- Page 12 Screw the rear support into the adjacent backrests using the M35 hand screws. PRO TIP...
- Page 13 Place the cushions. The in-line table can be added anywhere in the configuration, as long as it is positioned in-between two seats.
- Page 14 Enjoy your in-line Mistral table!
- Page 15 Let’s get Cozey Share your creation with us !
