Summary of Contents for TREBLAB HD-Max

  • Page 1 User’s Manual Please read this manual before using the product...
  • Page 2: What's In The Box

    Thank you for choosing TREBLAB HD-Max! This speaker provides superior sound quality and mobility, combined with rugged construction and the convenience of hands-free wireless operation. WHAT’S IN THE BOX 4. Type-C charging cable 1. TREBLAB HD-Max speaker 5. TREBLAB logo sticker 2.
  • Page 3 BUTTONS AND PARTS PREVIOUS / NEXT / BATTERY LEVEL VOLUME - VOLUME + INDICATOR INDICATOR COLORED COLORED LEDS LEDS PLACE FOR THE PLACE FOR THE CARRYING STRAP CARRYING STRAP STATE PAIRING LIGHT PLAY / PAUSE POWER INDICATOR...
  • Page 4 USB-A PORT TYPE-C CHARGING PORT 3.5MM CABLE PORT...
  • Page 5: Speaker Function

    SPEAKER FUNCTION Function Operation Press and hold the POWER button Power ON for 3 seconds. Press and hold the POWER button Power OFF for 3 seconds. Press the PLAY / PAUSE button. Play/Pause Volume + Press the VOLUME + button. Volume - Press the VOLUME - button.
  • Page 6 Press the PLAY / PAUSE button when End a phone call on a call. Press and hold the LIGHT button for Voice assistant 2 seconds. Double-press the PAIRING button. Enter / exit TWS pairing mode Press the LIGHT button. Switch between LED modes / turn off LEDs Press the POWER button (when the Switch between inputs...
  • Page 7: Setting Up Your Speaker

    BLUE, meaning that the speaker is in pairing mode. • Activate the wireless communication function on your device (smartphone, tablet, laptop). • Select TREBLAB HD-Max from the available devices list. Keep it within 3 feet /1 meter of the speaker while pairing. • If necessary, enter passcode 0000.
  • Page 8 If reconnection does not happen automatically, the speaker will start looking for any other previously paired device within the effective distance range. TREBLAB HD-Max can remember up to 8 recently paired devices. TRUE WIRELESS STEREO (TWS) - PAIRING TWO SPEAKERS...
  • Page 9: Audio Playback

    To adjust the volume, press the VOLUME + or the VOLUME - button while listening to music. To change the track on the HD-Max, press and hold the VOLUME + or the VOLUME - button for 2 seconds. 3.5MM AUDIO CABLE CONNECTION You can connect TREBLAB HD-Max to compatible devices using the supplied 3.5mm audio cable.
  • Page 10: Usb Mode

    USB MODE The TREBLAB HD-Max speaker can play music from the USB flash drives up to 512GB. All you need to do is to copy music to the memory stick (in folders or just to the root), insert it into the USB-A port on the back of the speaker (under the rubber cover).
  • Page 11: Sound Modes

    SOUND MODES TREBLAB HD-Max speaker supports three audio modes: Balanced, Treble Boost and Bass Boost. In the Treble Boost mode, treble is enhanced which ensures higher volume at open spaces. The Balanced mode will be suitable for indoor application. In the Bass Boost mode, low frequencies are enhanced for better listening experience.
  • Page 12: Phone Calls

    PHONE CALLS TREBLAB HD-Max can be used to make and receive phone calls when connected wirelessly. Audio playback will be paused during calls. Press the PLAY / PAUSE button during an To answer a call: incoming call. Press the PLAY / PAUSE button when on a call.
  • Page 13: Battery Level Indication

    (for more details, please check the BATTERY LEVEL INDICATION section) Unplug HD-Max from the charging cable and the cable itself from the power source when not in use. If the speaker is left unused, even the fully charged battery will lose its charge over time.
  • Page 14: Troubleshooting

    POWER BANK MODE TREBLAB HD-Max built-in battery can be used as a power bank to charge your smartphone or tablet. Connect your device to the speaker by plugging your device's charging cable into the USB-A port under the rubber cover at the side of the speaker.
  • Page 15 Repeat the steps for pairing as previously described. Alternatively, disconnect the device from your speaker and remove HD-Max from your device's pairing list. Try to pair again. Not finding Make sure your laptop supports wireless connections.
  • Page 16: Safety Rules

    • Avoid exposing TREBLAB HD-Max to extreme temperatures (below 37°F/3°C or above 112°F/45°C). Extreme temperatures can cause the deformation of the HD-Max components and reduce the battery life and the lifespan of your new speaker. • Don’t put the device's LED lights close to humans' or animals'...
  • Page 17: Specifications

    SPECIFICATIONS Speaker size: 2 x 3mm, 2 x 75mm Water resistance: IPX7 Charging port: TYPE-C Audio port: 3.5mm jack Dimensions: 12.2 x 5.39 x 5.59 inches / 310 x 137 x 142 mm Weight: 4.77 lbs / 2165 g...
  • Page 18 RECYCLING The speakers can be recycled, and they should be in order to keep our planet clean. Where should you bring them? In the US, there are a couple of options: https: //Www.call2recycle.org https: //search.earth911.com https: //recyclenation.com/find https://Www.cta.tech/Consumer-Resources/Greener-Gadgets In Canada, please visit the links below: https: //thinkreuse.net https: //Www.callErecycle.ca In the UK, please visit the links below:...
  • Page 19 THANK YOU We truly appreciate that you chose TREBLAB as your trusted brand of wireless speakers and sincerely hope you enjoy the great sound and seamless usability TREBLAB HD-Max provides. We love making our customers happy by providing true value with our products.
  • Page 20: Year Warranty

    1 YEAR WARRANTY Parts and Labor Warranty Please visit www.treblab.com to register YOUR product. Manufactured by Productech Made in China WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov...
