HD7
WIRELESS SPEAKER
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TREBLAB HD7

Summary of Contents for TREBLAB HD7

  • Page 1 WIRELESS SPEAKER USER’S MANUAL...

  • Page 2: What's In The Box

    Thank you for choosing TREBLAB HD7! This speaker provides superior sound quality and mobility combined with rugged construction convenience hands-free wireless technology. WHAT’S IN THE BOX Speaker Charging cable 3.5 mm audio cable Carrying strap Carabiner...
  • Page 3 BUTTONS AND PARTS POWER ON / OFF Place for the carrying strap Microphone (Mic) Bike mounting - PREVIOUS / 1/4-20 UNC VOLUME - 3.5 mm PLAY / PAUSE cable port MicroUSB NEXT / port VOLUME +...
  • Page 4 Function Operation Press and hold the POWER button for 3 seconds Power ON Press and hold the POWER button for 5 seconds Power OFF Play / Pause Press the PLAY / PAUSE button Press the VOLUME + button Volume + Press the VOLUME - button Volume - Press the PLAY / PAUSE button...

  • Page 5: Wireless Pairing

    Press and hold the POWER button for 5 seconds. You will hear the sound cue, and the flashing BLUE LED light will go OFF. WIRELESS PAIRING Make sure TREBLAB HD7 is fully charged and that the AUX cable is not plugged in.
  • Page 6 Activate the WIreless Mode on your device (smartphone, tablet, laptop). Select TREBLAB HD7 from the Wireless devices list. Keep it within 3 feet / 1 meter of the speaker while pairing. If necessary, enter passcode 0000.
  • Page 7 LED indicator will slowly flash BLUE. The other speaker’s LED will turn BLUE Turn ON the Bluetooth mode on your smart device Choose TREBLAB HD7 from the list of paired devices and click Connect You should hear “Connected,” and both speakers’ LED indicators will stay BLUE...

  • Page 8: Audio Playback

    Now you can use the speakers in stereo mode. Kindly note that the maximum distance between speakers should not exceed 33 feet / 10 meters NOTE: If the speakers were already paired with each other, you would skip the TWS pairing steps, as they will switch to the stereo mode automatically. After turning both speakers ON simultaneously, wait for “Stereo mode”...
  • Page 9 To change the track on the HD7, press and hold the VOLUME + or the VOLUME - button for 2 seconds. 3.5 MM AUDIO CABLE CONNECTION You can connect TREBLAB HD7 to compatible devices using the supplied 3.5 mm audio cable.

  • Page 10: Phone Calls

    PHONE CALLS TREBLAB HD7 can be used to make and receive phone calls when connected wirelessly. Audio playback will be paused during calls. Press the PLAY / PAUSE button. To Answer / End Call: Press and hold the PLAY / PAUSE button for To Reject Call: 2 seconds.
  • Page 11 Repeat the steps for pairing as previously described. Alternatively, disconnect the device from your speaker and remove HD7 from your device’s pairing list. Try to pair again. Make sure your laptop supports wireless connections. If it Not finding doesn’t, you will need an external wireless USB adapter...
  • Page 12 25 hours at 50% volume. When the battery is running low, you will hear a voice signal. TREBLAB HD7 may be used while charging in both Wireless Mode and 3.5 mm audio cable mode. To charge the speaker, plug one end of the cable into the Micro-USB charging port under the rubber cover at the side of the speaker.
  • Page 13 Maximize the battery lifespan by charging your speaker through a computer’s USB port. Unplug HD7 from the charging cable and the cable - from the power source when not in use. If the speaker is left unused, make sure that it is charged, as this may lead to the reduction of battery capacity.
  • Page 14 Check for other possible locations next to you on these websites (just enter your ZIP to find a location): https: //search.earth911.com https: //recyclenation.com/find https: //www.cta.tech/Consumer-Resources/Greener-Gadgets In Canada, please visit the link below for help: https: //thinkreuse.net In the UK, please visit the link below for help: https: //www.recycle-more.co.uk/...

  • Page 15: Safety Rules

    Make sure the speaker is completely dry before charging. Clean only with a dry cloth. Avoid exposing TREBLAB HD7 to extreme temperatures (below 37°F / 3°C or above 112°F / 45°C). Extreme temperatures can cause deformation of HD7 components and reduce battery life and the lifespan of your new speaker.

  • Page 16: Specifications

    SPECIFICATIONS Battery: Up to 25 hours playtime 2500 mAh 3.7 V, rechargeable Li-Ion Input 5 V / 0.5 A - 1.5 A Charging time: 3 hours Wireless connection version: 4.2 HFP, A2DP, AVRCP, GAVDP, AVDTP, SPP, AVCTP Signal range: 33 ft / 10 m Output power: 2x 6W Water resistance:...
  • Page 17 THANK YOU We truly appreciate that you chose TREBLAB as your trusted brand of wireless speakers and sincerely hope you enjoy the great sound and seamless usability TREBLAB HD7 provides. We love making our customers happy by ensuring true value of our products. If for any reason you are not completely satisfied with your purchase or have any questions, please visit www.treblab.com/cotuct_us.

  • Page 18: Year Warranty

    1 YEAR WARRANTY Parts and Labor Warranty. Please visit www.treblab.com WIRELESS SPEAKER to register YOUR product. Manufactured by: Productech Corp Made in China WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov...
