KLARITY Athena Breast System R610-NDCF Instructions For Use

Klarity Athena Breast System
R610-NDCF
INSTRUCTIONS FOR USE
GENERAL INFORMATION
The Klarity Athena Breast System is used for positioning and re-
positioning patients during breast radiation therapy treatment and other
treatment modalities.
PRODUCT DESCRIPTION
The Klarity Athena Breast System is an adjustable baseplate for supine
positioning. The carbon fiber baseplate attaches to a treatment table
and can be raised or lowered with elevation supports. The Athena R610-
NDCF includes arm cups and upper hand grips for overhead arm
positioning. Lower hand grips are also included to facilitate additional
arm positioning options. The patient's bottom is supported by an
adjustable bottom cushion. A leg cushion elevates the lower limbs for
better patient comfort. A headrest is included as well.
The R610-NDCF is compatible with the Athena Wingboard (ordered
separately). The Athena Breast System is also compatible with standard
S-type masks from Klarity and other manufacturers, as well as breast
and thorax masks from Klarity.
PRODUCT SPECIFICATIONS
Weight Limit: 440lbs
Elevations: 5˚, 10˚, 15˚, 20˚
Dimensions: 145 cm Length
41 cm Width
2 cm Thickness
Material: Carbon Fiber
STORAGE AND CLEANING
Store in a clean, dry place away from direct sunlight. Wipe thoroughly
with a neutral antiseptic cleaner. Allow to dry thoroughly before next use.
To be used by a qualified medical professional
IFU-B-014
35˚C
Keep in a
cool and dry Store below
environment 35˚C (95˚F)
INSTRUCTIONS FOR USE
1. Attach the baseplate to the treatment table or CT Couch using two
indexing bars (upper and lower).
2. Next, determine the desired elevation for the baseplate. Lift the
baseplate; raise the selected elevation bar and insert it into the
connector piece at the top of the baseplate. To release, push the
pink tab up and remove the elevation bar.
3. Place the headrest onto the baseplate.
4. To attach the upper arm supports open the latch and insert the
pegs into the desired hole (4, 5, 6, or 7). Close the latch to secure.
The arm supports can be adjusted horizontally, vertically, and
laterally. To adjust in any direction, push the button to adjust and
release to lock into place.
5. Place the upper hand grips in the desired hole(s) (1, 2, or 3).
6. If positioning the arms down by the patient's side(s), attach the
lower hand grips to either or both sides of the baseplate by screwing
the hand grip knobs into the baseplate. Adjust the hand grip posts
as needed.
7. To adjust the bottom cushion (also called a bum stop), unscrew the
knobs to slide the cushion to the ideal position. Tighten the knobs to
secure.
8. Position the patient on the baseplate and adjust as needed.
9. S-type Head-only thermoplastic masks as well as breast masks may
be used with the Athena Breast System. If using a mask, follow the
instructions for that specific mask. The baseplate is equipped with
holes to receive S-type head masks (around the head) and secure it
to the baseplate using the pins on either side of the mask.
10. To store the baseplate, collapse the elevation bars. Wrap the
attached Velcro strap over the top of the elevation blocks and
connect at the back to keep the baseplate contained.
