KLARITY Supine Breast System Instructions For Use

Klarity Supine Breast System
INSTRUCTIONS FOR USE
GENERAL INFORMATION
The Klarity Supine Breast System is used for positioning and re-
positioning patients during breast radiation therapy treatment and other
treatment modalities.
PRODUCT DESCRIPTION
The Klarity Breast System is an adjustable baseplate with different
options for optimal treatment and positioning. The baseplate attaches to
a treatment table and can be raised or lowered with elevation supports.
Arm cups support the lower arms, and wrist cups or hand grips can be
used for the upper arms. Both are included for hand placement. The
patient's bottom is supported by a bottom stopper and leg cushions
elevate the lower limbs.
PRODUCT SPECIFICATIONS
Board Weight (without accessories): 5.44 kg/12 lbs
Board Weight (with accessories): 6.80 kg/15 lbs
Dimensions: 131 cm Length
41 cm Width
4 cm Height
20 mm Thickness
Material: Carbon Fiber
Absorption Factor (AF%):
Co-60: 2.6
6MV: 2
8MV: 1.7
15MV: 1.5
STORAGE AND CLEANING
Store in a clean, dry place away from direct sunlight. Wipe thoroughly
with a neutral antiseptic cleaner. Allow to dry thoroughly before next use.
To be used by a qualified medical professional
IFU.BP.007.01 9/20/21
INSTRUCTIONS FOR USE
1. Attach the baseplate to the treatment table or CT Couch using an
2. Next, achieve the desired elevation by selecting the 5˚, 10˚, 15˚,
3. Lower the top plate and lock into place with the pushpin at the top
4. Place either the wrist cups or hand grips into the top holes
5. Position the head cup into the desired hole
6. Attach the arm cups into the baseplate by screwing the attachment
7. Position the patient on the baseplate.
8. If needed, breast/torso and head-only S-type thermoplastic masks
9. Once the mask cools, release the mask by pulling up the pins.
35˚C
Keep in a
cool and dry Store below
environment 35˚C (95˚F)
indexing bar.
20˚, or 25˚ support bar. Place the elevation bar into the slot on the
underside of the top place.
of the plate. Secure with the Velcro straps.
screws from the bottom. Please note that the "wings" of the arm
cups should be towards the outside of the board, away from the
patient. Adjust the arm cups to the desired angle and position.
can be used to secure the patient. Please see a full list of
compatible masks at www.klaritymedical.com/masks. If using a
mask, draw the mask down over the patient and secure it to the
baseplate using the pins on either side of the mask.
