ALL
PUSH
START
THAR-VW1 INSTALLATION
INSTALLATION THAR-VW1
PUSH
START
VEHICLE
VEHICULES
VOLKSWAGEN
Golf
Push-to-Start
HARDWARE VERSION
VERSION MATÉRIELLE
MINIMUM
Parts required (Not included)
1x Vehicle Key
1x THAR-VW1
1x Diode
1x AR35 (optional)
NOTES
1 KEY REQUIRED FOR THE
INSTALLATION
MANDATORY INSTALL | INSTALLATION OBLIGATOIRE
* HOOD PIN
HOOD STATUS : THE HOOD PIN SWITCH MUST BE INSTALLED
IF THE VEHICLE CAN BE REMOTE STARTED WITH THE HOOD OPEN.
CONTACT
STATUT DE CAPOT : LE CONTACT DE CAPOT, DOIT ÊTRE INSTALLÉ SI LE
DE CAPOT
VÉHICULE PEUT DÉMARRER À DISTANCE, LORSQUE LE CAPOT EST OUVERT.
1 / 8
Page
Vehicle functions supported in this diagram (functional if equipped) | Fonctions du véhicule sup-
YEARS
ANNÉES
2015-2018
FIRMWARE VERSION
VERSION LOGICIELLE
6
61.[04]
VW MINIMUM
Program bypass option:
Programmez l'option du contournement:
Program bypass option
(If equiped with OEM
Programmez l'option du contournement
(Si équipé d'une alarme
REV.: 20190109
PUSH
START
portées dans ce diagramme (fonctionnelles si équipé)
PUSH
START
To add the firmware version and the options, use the
FLASH LINK UPDATER or FLASH LINK MOBILE tool,
UNIT OPTION
OPTION UNITE
C1
D6
UNIT OPTION
OPTION UNITE
alarm):
D2
d'origine):
Pièce(s) requise(s) (Non incluse(s))
1x Clé du véhicule
1x THAR-VW1
1x Diode
1x AR35 (optionnel)
1 CLÉ REQUISE À L'INSTALLATION
Notice: the installation of safety
elements are mandatory. The hood pin
is an essential security element and
must be installed.
Notice: l'installation des éléments de
sécurité est obligatoire. Le contact de
capot est un élément de sécurité
essentiel et doit absolument être
installé.
Guide # 63321
ADDENDUM - SUGGESTED WIRING CONFIGURATION
ADDENDA - SCHÉMA DE BRANCHEMENT SUGGÉRÉ
sold separately.
Pour ajouter la version logicielle et les options,
utilisez l'outil FLASH LINK UPDATER
ou FLASH LINK MOBILE, vendu séparément.
DESCRIPTION
OEM Remote status (Lock/Unlock)
monitoring
Suivi des status (Verrouillage/Déverrouil-
lage) de la télécommande d'origine
Push-to-Start
Push-to-Start
DESCRIPTION
Unlock before / Lock after (Disarm OEM
alarm)
Déverrouille avant / Verrouille après
(Désarme l'alarme d'origine)
THIS MODULE MUST BE INSTALLED BY A
QUALIFIED TECHNICIAN. A WRONG
CONNECTION CAN CAUSE PERMANENT
DAMAGE TO THE VEHICLE.
CE MODULE DOIT ÊTRE INSTALLÉ PAR
UN TECHNICIEN QUALIFIÉ, TOUTE
ERREUR DANS LES BRANCHEMENTS
PEUT OCCASIONNER DES DOMMAGES
PERMANENTS AU VÉHICULE.
PUSH
START

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVO ALL THAR-VW1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fortin EVO ALL THAR-VW1

  • Page 1 1 / 8 REV.: 20190109 Guide # 63321 Page PUSH PUSH START START THAR-VW1 INSTALLATION ADDENDUM - SUGGESTED WIRING CONFIGURATION INSTALLATION THAR-VW1 ADDENDA - SCHÉMA DE BRANCHEMENT SUGGÉRÉ Vehicle functions supported in this diagram (functional if equipped) | Fonctions du véhicule sup- portées dans ce diagramme (fonctionnelles si équipé) PUSH PUSH...
  • Page 2 This guide may change without notice. See www.fortin.ca for latest version. 2 / 8 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. DESCRIPTION | DESCRIPTION Pull the clips to release the cover of the connector.
  • Page 3 This guide may change without notice. See www.fortin.ca for latest version. 3 / 8 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. AUTOMATIC TRANSMISSION WIRING CONNECTION | SCHÉMA DE BRANCHEMENT TRANSMISSION AUTOMATIQUE HOOD PIN...
  • Page 4 This guide may change without notice. See www.fortin.ca for latest version. 4 / 8 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. MANUAL TRANSMISSION WIRING CONNECTION | SCHÉMA DE BRANCHEMENT TRANSMISSION MANUELLE RS8 OUT...
  • Page 5 This guide may change without notice. See www.fortin.ca for latest version. 5 / 8 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. KEY CONTROL | CONTRÔLE DE LA CLÉ Remove the battery from 1 OEM Remove the battery from 1 OEM Retirez la pile d'une des télécommandes...
  • Page 6 This guide may change without notice. See www.fortin.ca for latest version. 6 / 8 Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. PROGRAMMING PROCEDURE | PROCÉDURE DE PROGRAMMATION Appuyez maintenir Press hold enfoncé...
  • Page 7 Véhicules avec bouton Push-to-Start. 7 / 8 START Page Ce guide peut faire l’objet de changement sans préavis. Voir www.fortin.ca pour la récente version. REMOTE STARTER FUNCTIONALITY | FONCTIONNALITÉS DU DÉMARREUR À DISTANCE Unlock the doors with All doors must...
  • Page 8 The installation in every case is the sole responsibility of the installer performing the work and FORTIN ELECTRONIC SYSTEMS assumes no liability or responsibility whatsoever resulting from any type of installation, whether performed properly, improperly or any other way.
