Summary of Contents for Johnson Controls LE4050M
- Page 1 LE4050M INSTALLATION MANUAL 29011324R001...
- Page 2 LE4050M INSTALLATION MANUAL...
-
Page 3: Table Of Contents
DSC connect technical support......................8 Product description............................9 Main features............................9 Technical specifications.........................9 LE4050M package contents........................ 10 Wiring the communicator to the DSC Power Series Neo alarm panels........11 DSC Powerseries NEO panel programming..................11 Wiring the communicator to the DSC PowerSeries alarm panels..........12 DSC PowerSeries panel programming....................13... - Page 4 LE4050M INSTALLATION MANUAL...
-
Page 5: Introduction
Antenna gain must be as per below. Gain de l'antenne doit être comme ci-dessous: Table 1: LTE antenna gain Frequency band / Bande de fréquence Antenna gain / Gain de l'antenne 1.315 1.3525 1.3375 1.6075 -0.18 0.1125 1.6125 1.265 1.695 1.3525 1.40875 LE4050M INSTALLATION MANUAL... - Page 6 Antenna gain / Gain de l'antenne 1.69 1800 1900 This transmitter shall not be co-located or operating in conjunction with any other antenna or transmitter. L'émetteur ne doit pas être colocalisé ou fonctionner en conjonction avec une autre antenne ou émetteur. LE4050M INSTALLATION MANUAL...
- Page 7 IC of the module is not visible, the host device shall display the provide label referring to the FCC ID and IC of the enclosed module. This label is shipped together with the model LE4050M and it is the responsibility of the integrator to apply it to the exterior of the enclosure as displayed in the following figure.
-
Page 8: Safety Instructions
This unit must be checked by a qualified technician once a year. • The LE4050M device contains a radio transceiver operating in LTE CAT-M1 band. • Do not use the Device with medical devices, or where it can interfere with other devices and cause any potential danger. -
Page 9: Product Description
Product description The LE4050M is a digital serial port alarm communicator. It represents the latest communication technology for the security industry. The communicator is equipped with dual-SIM supporting multiple carriers per country. This communication solution is a complete communication platform for data transfer from alarm systems at remote sites to Central Monitoring Stations (CMS). -
Page 10: Le4050M Package Contents
1,73” x 3.58” (44 x 90 mm) Weight 0.05 kg (excluding the antenna) LE4050M package contents Inside the box of the LE4050M you will find the following items: • LE4050M Cellular Communicator • GSM Antenna with 1 m (3 ft) cable, SMA connector •... -
Page 11: Wiring The Communicator To The Dsc Power Series Neo Alarm Panels
Section 382 >> enable option 5 “Alternate Comm.” • Section 300 >> set Receiver 1 to Alt. Comm Auto” • Section 015 >> Option 7 >> Disable TLM Monitoring • Section 310 >> Set System Account Code LE4050M INSTALLATION MANUAL... -
Page 12: Wiring The Communicator To The Dsc Powerseries Alarm Panels
• For dry/indoor use only. The LE4050M communicator is equipped with 2 Terminals for power supply and a 5 PIN connector that should be wired and mounted into the box of the DSC PowerSeries alarm panel. Figure 3: Wiring diagram for DSC PowerSeries alarm panels... -
Page 13: Dsc Powerseries Panel Programming
Important notes • Use only PC link cabels provided with LE4050M communicators. • Note the “Red” marking on the Communicator and the “1” marking on the Panel • Always connect the device to a current limited power source. Never connect it to a battery... -
Page 14: Mounting The Communicator
RF interference or where metal objects can shield it or otherwise block the cellular radio RF signal. 3. Wire the communicator to the alarm panel – refer to the wiring sections of this manual. 4. Power up the panel. LE4050M INSTALLATION MANUAL... -
Page 15: Led Indicator Status
Adding a device from the DSC installer web portal 1. Go to My Devices > Devices > Add New Device. 2. Select the preferred monitoring station/reporting channel. 3. Type in the device Serial Number and Config Key and Save. LE4050M INSTALLATION MANUAL... -
Page 16: Adding A Device From The Dsc Connect Installer App
Digital Security Controls (“DSC”), a division of Tyco Safety Products Canada Ltd, a part of the Johnson Controls group of companies (“JCI”), warrants the original purchaser that for a periodof twelve months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use. - Page 17 Any alarm system of any type may be compromised deliberately or may fail to operate as expected for a variety of reasons. Some but not all of these reasons may be: LE4050M INSTALLATION MANUAL...
- Page 18 Smoke may not be able to reach the smoke detectors, such as when the fire is in a chimney, walls or roofs, or on the other side of closed doors. Smoke detectors may not detect LE4050M INSTALLATION MANUAL...
- Page 19 The testing should include all sensing devices, keypads, consoles, alarm indicating devices and any other operational devices that are part of the system. LE4050M INSTALLATION MANUAL...
-
Page 20: End-User License Agreement (Eula)
Software and any related Hardware) and Digital Security Controls, a division of Tyco Safety Products Canada Ltd., a part of Johnson Controls group of companies (“JCI”), the manufacturer of the integrated security systems and the developer of the software and any related products or components (“HARDWARE”) which You acquired. - Page 21 THE GREATER OF THE AMOUNT ACTUALLY PAID BY YOU TO LICENSE THE SOFTWARE PRODUCT AND FIVE CANADIAN DOLLARS (CAD$5.00). BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. LE4050M INSTALLATION MANUAL...
-
Page 22: Copyright And Trademark
Not all products include all features. Availability varies by region; contact your sales representative. ©2024 Johnson Controls. All rights reserved. Johnson Controls, Tyco and DSC are trademarks and/ or registered trademarks. Unauthorized use is strictly prohibited. Techsupport: 1-800-387-3630 (Canada and U.S), or 1-905-760-3036 (International)
