Plasson PLASSNEST Installation And Operation Manual page 91

ID# P/N Description
PLSNST WOOD PROFILE 40X40 FOR
66 02370862
SINGLE NEST (2440mm)
67 02320076 DIN 933 M8X35 SCREW ZINC D
68 02310431 DIN 315 M8 WING NUT
69 02323233 DIN 933 M8X20 SCREW
PLSNST COLLECTION TABLE ADAPTER TO
70 02370962
PASSAGE
71 02323039 THIMBLE FOR 6MM CABLE
72 02370666 PLSNST HANDLE
73 02370813 PLSNST EGGS BELT CONNECTION STRIP
74 02323232 DIN 933 M8X16 SCREW
75 02370966 PLSNST COLLECTION TABLE SAFETY COVER
76 02370878 PLSNST PASSAGE COVER FOR 1.5m
77 02370702 PASSAGE SUPPORT
78 Nest lifting drive unit plate
79 Chain coupler
80 Nest suspension drive unit
81 Collection table motor
91  Bill of Materials (BOM)
Safety Introduction
QTY.
ID#
Single Double
82
40
83 02371105
84 02371104
1 1
1 2
12 12
1 1
1
4 6
1 1
1 1

WWW
Installation
P/N Description
Conveyor belt end unit
PLSNST SHORT BEAM
PLSNST LONG BEAM V2.1 90X35X20
Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E
Operation
Instructions
QTY.
Single Double
1 1
3
2
