Plassnest
Installation and Operation Guide
Copyright © 2022 Plasson, all rights reserved.
Rev B | Doc P/N: 080205034E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLASSNEST and is the answer not in the manual?

Questions and answers

Related Manuals for Plasson PLASSNEST

Summary of Contents for Plasson PLASSNEST

  • Page 1 Plassnest Installation and Operation Guide Copyright © 2022 Plasson, all rights reserved. Rev B | Doc P/N: 080205034E...

  • Page 2: Table Of Contents

    » Expulsion Sub-system » Egg Collection Conveyor Belt Sub-system » Nest Suspension Sub-system » Power and Control System Overview » Optional Layouts » Typical Installation Workflow  2  Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 3: Safety

    Operation Safety Introduction Installation Instructions 1. Safety This chapter contains an overview of the Plassnest system safety concerns and includes: Safety Overview Safety Conventions Cautions and Warnings Storage, Transport, and Installation EMC Safety  3  Safety | Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 4: Safety Overview

    1.1 Safety Overview Plasson's Plassnest system has been designed to meet all known safety requirements. During normal operation, the Plassnest system presents no hazards to the operator or other personnel. However, in certain circumstances, the following potential hazards to operators and maintenance...

  • Page 5: Safety Conventions

    This signal word is limited to the most extreme situations.  5  Safety | Safety Conventions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 6: Cautions And Warnings

    • Clean up spills and leaks immediately. • In case of unusual or irregular noise or vibration, it is necessary to switch off the system.  6  Safety | Cautions and Warnings Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 7: Storage, Transport, And Installation

    • Whenever you handle or repair the equipment, turn off the power supply first. Transport safety: • Maintenance and repairs must be carried out by qualified technicians authorized by Plasson. • Move the system using appropriate lifting equipment. • Always use Plasson components when replacing any defective components.

  • Page 8: Emc Safety

    Safety Introduction Installation Instructions 1.5 EMC Safety All Plassnest system components comply with IEC EN 61000-6-3, the emission standard for residential, commercial, and light industrial environments.  8  Safety | EMC Safety Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 9: Introduction

    Nest Modules (Single/Double) Expulsion Sub-system Egg Collection Conveyor Belt Sub-system Nest Suspension Sub-system Power and Control System Overview Optional Layouts Typical Installation Workflow  9  Introduction | Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 10: System Concept

     10  Introduction | System Concept Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 11: System Overview

    – transports eggs retrieve their eggs, and forces hens out of the to a collection table nests when it's time to roost  11  Introduction | System Overview Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 12: Nest Modules (Single/Double)

     12  Introduction | Nest Modules (Single/Double) Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 13 The double nest module provides the same environment for hens as the single nest module. Double nest modules allow for more nesting space in longer breeder houses.  13  Introduction | Nest Modules (Single/Double) Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 14: Expulsion Sub-System

    The expulsion grids open and close at preset hours (see Nest Opening/Closing Schedule Setup)  14  Introduction | Expulsion Sub-system Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 15: Egg Collection Conveyor Belt Sub-System

     15  Introduction | Egg Collection Conveyor Belt Sub-system Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 16: Nest Suspension Sub-System

    The second end of the suspension wire is connected to the suspension frame  16  Introduction | Nest Suspension Sub-system Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 17: Power And Control System Overview

    Main power switch nOte: Setting switches to 0 disables their functionality  17  Introduction | Power and Control System Overview Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 18: Optional Layouts

    Installation Instructions 2.8 Optional Layouts PlassNest layouts depend on the dimensions of the chicken house, the service area, and the number of layers and breeders. The following are three examples of PlassNest layouts: Breeder House – All In All Out...
  • Page 19 Installation Instructions 2.8.1 Breeder House – All In All Out Location – Philippines Length – 126 m Width – 15.5 m  19  Introduction | Optional Layouts Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 20 Safety Introduction Installation Instructions 2.8.2 Free Range Commercial Layer House Location – France Length – 100 m Width – 15 m  20  Introduction | Optional Layouts Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 21 Operation Safety Introduction Installation Instructions 2.8.3 Heavy Breeders House Location – Israel Length – 150+13 m Width – 15.5 m  21  Introduction | Optional Layouts Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 22: Typical Installation Workflow

    Verify there are no conflicts with the other systems in the house (i.e., with the cable troughs, the cross auger feeding line, etc.) Follow the Assembly Instructions.  22  Introduction | Typical Installation Workfoo Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 23: Installation

    Operation Safety Introduction Installation Instructions 3. Installation This chapter reviews the tasks associated with installing the Plassnest system and includes: Preparations for Installation System Unpacking Assembly Instructions Power and Control Connections Nest Opening/Closing Schedule Setup Bill of Materials (BOM) ...

  • Page 24: Preparations For Installation

    3.1 Preparations for Installation This chapter details requirements that must be fulfilled before beginning the installation process and includes: Installation Requirements Required Tools and Labor  24  Preparations for Installation Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 25 Electric power for the suspension system, expulsion system, and conveyor belt is set up and ready to be connected (see Power and Control Connections)  25  Preparations for Installation Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 26 NOTE: Need compressed air supply if pneumatic gun is used Plier clamps Electricians Tools Hammers (rubber, plastic, and metal heads) Standard electrician tools Utility knife Scissors  26  Preparations for Installation Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 27: System Unpacking

    Open the system package and verify that all the parts listed in the Bill of Materials (BOM) are located in the package and are intact. If any part is missing or damaged, contact Plasson. nOte: Unpack the system in a clean and dry area.

  • Page 28: Assembly Instructions

    Step 17: Installing the Passage Covers ..................... 57 Step 18: Assembling the Nest Walls ......................59 Step 19: Inserting the Nest Floor Components ..................63  28  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 29: Step 1: Installing The Nest Suspension Drive Unit

    If a nest line has two expulsion systems, install the drive unit between the two systems. Optional Layouts for more details on suspension system layout.  29  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 30: Step 2: Installing The Suspension Pipe Bearings

    100 mm (± 2 mm) from the bottom of the beam nOte: Tolerance between bearings: ▪ Horizontal: 2 mm ▪ Vertical: 5 mm  30  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 31: Step 3: Installing The Suspension Pipes

    (56), and four nuts (57) nOte: If there are more than 20 nests, connect pipes using a chain coupler (79) instead of a pipe adapter  31  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 32: Step 4: Assembling The Nest Bases

    (84) using twelve self-drilling screws (36) Attach four corner triangles (9) to the beams using six self-drilling screws (36) per corner triangle  32  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 33 (2) self-drilling screws (36) per leg and three nuts (5) per profile Lower the legs and insert the locking screws (1) Reverse angle  33  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 34 Inside view Attach each suspension frame to the nest base using one screw (69) and one nut (4)  34  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 35 Assemble the collection table (see Step nOte: Consider connecting the suspension cables to the suspension pipes (see Step 11) before assembling the nest line  35  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 36: Step 5: Assembling The Collection Table

    (1) and four nuts (4) Insert four locking screws (1) through the four brackets and fasten with four wing nuts (68)  36  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 37 (81) to the drive unit Attach the table interconnection bracket (70) to the collection table using five screws (69) and five nuts (4)  37  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 38 (2) and eight nuts (5) Connect the two suspension structure frames together using one screw (2) and one nut (5) Reverse angle  38  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 39: Step 6: Installing The Passage Profiles

    (5) per each side Attach bottom support beam (77) to the passage side profiles using four rivets (6) Bottom view  39  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 40: Step 7: Installing The Conveyor Belt End Unit

    (82) to the nest base using two screws (2) and two nuts (5) nOte: The conveyor belt end unit attaches to the last nest in the line  40  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 41 Loosen the two nuts on either side of the end unit and move the drum as close as possible to the nest base  41  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 42: Step 8: Verifying Alignment And Height Of Nest Line

    (between 55 and 65 cm) 55 - 65 Twist the bottom of the legs to achieve equal heights  42  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 43: Step 9: Attaching A Cable To The Collection Table

    260 cm the two rings on the collection table, place two wire thimble (71), and fasten using two clamps (31) per each loop  43  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 44: Step 10: Cutting Suspension Cables To Length

    L1 plus two meters to length L2 plus two meters Cable length Cable length L1 + 2 meters L2 + 2 meters  44  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 45: Step 11: Connecting Suspension Cables To The Suspension Pipes

    Wind the cable in the direction of the conveyor belt end unit, and verify correct rotation orientation conveyor belt end unit  45  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 46: Step 12: Connecting Suspension Cables To Nest Line

    Step 12: Connecting Suspension Cables to Nest Line To connect the suspension cables (30) to the nest line, place a wire thimble (71) and fasten using two clamps (31)  46  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 47: Step 13: Calibrating The Suspension System

     47  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 48: Step 14: Inserting The Conveyor Belt And Belt Support Grids

    Verify the counterbalance is attached to the collection table nOte: The friction roller must remain parallel to the drive drum Bottom view  48  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 49 At the conveyor belt end unit, insert the conveyor belt under the brush (A), around the drum (B), and under the roller (C)  49  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 50 Pull the conveyor belt over the belt grills and back Bend the ends of the rods inward to the collection table bend Bottom view  50  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 51 Cut the belt to a length sufficient to reach the top of the table and overlap the other end of the belt  51  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 52: Step 15: Connecting The Conveyor Belt Ends

    Cut the bottom belt at a diagonal, keeping five rows of holes overlap nOte: Ensure five holes overlap before cutting the belt  52  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 53 Weave 60 cm of string (73) through the two belt ends and pull tight Belt movement direction Belt movement direction Repeat the weave across all rows  53  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 54: Step 16: Initial Conveyor Belt Alignment

    Bottom view The friction roller must remain parallel to the drive drum Bottom view  54  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 55 (B) nOte: Once the adjustment has been made, retighten the nut (A) to Side view Side view secure the drive drum  55  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 56 Move the friction roller away from the drive drum if belt gets stuck Attach the collection table safety cover (75) using two screws (74)  56  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 57: Step 17: Installing The Passage Covers

    Step 17: Installing the Passage Covers Attach the handle (72) to the passage cover (76) using two screws (52) and two nuts (5) Bottom view  57  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 58 Attach the passage cover to the nOte: passage side beam using two hinges (59), Mind rivet orientation eight screws (52), and eight nuts (5)  58  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 59: Step 18: Assembling The Nest Walls

    (6) Bend the tab in the opposite direction of the folded part above it nOte: Mind rivet orientation  59  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 60 Connect the side walls (12) to the nest base and suspension frame using fourteen rivets (6) per wall nOte: Mind rivet orientation  60  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 61 Introduction Installation Instructions Attach the end unit to the side wall of the last nest using one self-drilling screw (36) on each side  61  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 62 (6) per side wall together using three rivets (6) nOte: nOte: Mind rivet orientation Mind rivet orientation Inside view  62  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 63: Step 19: Inserting The Nest Floor Components

    Step 19: Inserting the Nest Floor Components Attach step plates (17) to both sides of the nest using six screws (2) and six nuts (5) per plate Inside view  63  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 64 Insert nest floors (16) Attach two grid holders (18) into the nest to each step plate using one rivet (6) per holder Inside view  64  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 65 (24) Inside view Place the artificial turf onto the grids Inside view Verify the edges snap firmly onto the step plate  65  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 66: Step 20: Installing The Expulsion Drive Unit

    Step 20: Installing the Expulsion Drive Unit Attach two bearings (12) to each nest side wall using three screws (2) and three nuts (5) per bearing  66  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 67 Attach the expulsion drive unit brackets to the nest side wall using two self-drilling screws (36) per bracket  67  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 68: Step 21: Installing The Expulsion Pipes

    Connect the pipes to the drive unit using a screw (33) and a nut (4) Insert a self-drilling screw (36) into the pipe and drive unit  68  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 69: Step 22: Installing The Expulsion Grids

    Bend the tabs located on the side and middle walls towards the inside of the nest nOte: On the middle wall, bend the tabs in opposite directions  69  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 70: Step 23: Calibrating The Expulsion Grids

    First tighten the lower screw which holds the grid, then tighten the upper screw which holds the pipe  70  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 71 The expulsion grids are in open until the expulsion grids are vertical position when they are vertical Verify activation of the open limit switch  71  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 72 Instructions Insert the expulsion drive unit cover (61) over the drive unit Verify that the cover snaps into the expulsion drive unit brackets  72  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 73: Step 24: Assembling The Nest Roofs

    Step 24: Assembling the Nest Roofs Attach the roof assembly (20) to the nest walls using twelve screws (32) and twelve nuts (5) Reverse view  73  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 74 Operation Safety Introduction Installation Instructions Place the antiperch swing (29) on the roofs (28) Place the roofs on the nest  74  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 75: Step 25: Assembling The Benches

    Instructions Step 25: Assembling the Benches Attach the bench beam supports (30) to the nest base using two self-drilling screws (36) per support  75  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 76 (63, 64) to the nest base using two screws (31) and four nuts (5) per screw Verify that the passage beam support is hooked onto the passage support  76  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 77 Operation Safety Introduction Installation Instructions Attach five passage beams (65) to the passage beam supports using four wood screws (35) per beam  77  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 78 Operation Safety Introduction Installation Instructions Attach five bench beams (66) to the bench beam supports using three wood screws (35) per beam  78  Assembly Instructions Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 79: Power And Control Connections

    Main Power Connection Suspension System Drive Unit Connection Expulsion System Drive Unit Connection Conveyor Belt Drive Unit Connection Auto-stop Sensor Check  79  Power and Control Connections Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 80 X-0 of the main control cabinet Main supply Egg conveyor motor Expul cable cable cable Facility power supply  80  Power and Control Connections Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 81 Motor Power supply cable: motor and on the national electrical grid 4 x 1.5 mm  81  Power and Control Connections Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 82 X-1 of the main control cabinet Motor Motor Motor Expulsion actuator (option up to 3x0.75HP - 1 phase)  82  Power and Control Connections Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 83 Phase Phase Phase 3, and Motor terminal blocks in section X-1 of the main Conveyor actuator control cabinet (3-phase motor 1HP)  83  Power and Control Connections Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 84 Place an egg on belt stops when the egg the conveyor belt reaches the sensor Run the belt at low speed  84  Power and Control Connections Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 85: Nest Opening/Closing Schedule Setup

    This section describes programming of the timer which controls the opening and closing of the nest expulsion grids, and includes: Timer Overview Setting the Time Programming Nest Opening/Closing Times Locking/Unlocking the Timer Manually Opening/Closing Nest  85  Nest Opening/Closing Schedule Setup Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 86 Time is 24-hour format Press buttons Press buttons Press button to at the same time to set the time confirm the time  86  Nest Opening/Closing Schedule Setup Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 87 Press button Press button to confirm to confirm  87  Nest Opening/Closing Schedule Setup Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 88 Press button to automatic mode to close the nest to automatic mode  88  Nest Opening/Closing Schedule Setup Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 89: Bill Of Materials (Bom)

    02323226 DIN 7985 M6 x 25 SCREW ZINC D 02370688 PLSNST SIDE WALL SUPPORT 02323037 DIN 933 M8X50 SCREW ZINC D  89  Bill of Materials (BOM) Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 90 PASSAGE BEAM SUPPORT –L 02370668 PLSNST DOUBLE UNIT MIDDLE SUPPORT PLSNS WOOD PROFILE FOR 1.2M 02370971 02370748 SIDE STEP BRACKET PASSAGE (1166 MM)  90  Bill of Materials (BOM) Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 91 PLSNST PASSAGE COVER FOR 1.5m 02370702 PASSAGE SUPPORT Nest lifting drive unit plate Chain coupler Nest suspension drive unit Collection table motor  91  Bill of Materials (BOM) Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 92: Operation Instructions

    This chapter reviews the tasks associated with first-time operation of the system after installation and includes: Lowering the Nests to the Floor Running the Egg Collection Conveyor Belt  92  Operation Instructions | Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 93: Lowering The Nests To The Floor

    Keep eye contact with the system at all times while operating the suspension mechanism Bottom view  93  Operation Instructions | Lowering the Nests to the Floor Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...

  • Page 94: Running The Egg Collection Conveyor Belt

    50 Hz nOte: The frequency converter box is located inside the control cabinet  94  Operation Instructions | Running the Egg Collection Conveyor Belt Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 95 Operation Safety Introduction Installation Instructions Revision History Revision Date Description Approval Initial release Shaul S.  95  Plassnest | Installation and Operation Guide Rev B | Doc P/N: 080205034E...
  • Page 96 Thank you! Copyright © 2022 Plasson, all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical or otherwise without prior written permission of Plasson.
