PLASSNEST EXPULSION TIMER
Quick Setup Guide
Copyright © 2020 Plasson, all rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLASSNEST EXPULSION TIMER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Plasson PLASSNEST EXPULSION TIMER

Summary of Contents for Plasson PLASSNEST EXPULSION TIMER

  • Page 1 PLASSNEST EXPULSION TIMER Quick Setup Guide Copyright © 2020 Plasson, all rights reserved...
  • Page 2 Overview This guide explains how to set up the expulsion system timer and includes the following steps: • Initial Timer Setupn (see page 3) • Programming Nest Opening (see page 6) • Programming Nest Closing (see page 13) Nest opening The timer’s C1 channel opens the expulsion grids (i.e., moves them to vertical position).
  • Page 3 Initial Timer Setup Perform the following steps once to set up the timer for operation. Resetting the timer flashes ENGLISH english Press and hold using a pen tip Setting the language Various languages are displayed french Press to choose the desired language Press select a language...
  • Page 4 Setting the current date Year value flashes year 20 20 Press Press select the year Month value flashes month Press Press select the month Day value flashes . 09 Press Press select the day...
  • Page 5 Setting the current time Hour value flashes hour : 00 Press Press select the hour Minute value flashes minute 16 : Press Press select the month Main screen is displayed 2 1 09 20 16 : 20...
  • Page 6 Programming Nest Opening Perform the following steps to define the time of day when the nests open and allow chickens entry. Selecting the nest opening (C1) channel is displayed program program Press Menu Press NEW P flashes new prog Press...
  • Page 7 is displayed channel flashes channel Press Setting the nest opening start time (C1 On) is displayed NOTE: time on flashes At nest opening time on start time, the expulsion motor moves the expulsion grids Press to open (vertical) position Hour value flashes hour : 00 Press...
  • Page 8 Minute value flashes minute Press Press select the minute Setting the start time for all days of the week NOTE: flashes monday The defined start monday time must be copied to all days 6 : 20 of the week Press flashes copy copy...
  • Page 9 flashes add tu add tu 6 : 20 Press Press add we add Th add fr add sa add su Storing the nest opening start time flashes store store 6 : 20 Press Selecting the nest opening (C1) channel NEW P flashes new prog Press...
  • Page 10 is displayed channel flashes channel Press Setting the nest opening end time (C1 Off) is displayed NOTE: time off flashes This step is time off necessary to turn off the opening command after the grids are in place Press NOTE: Hour value flashes Opening end time hour...
  • Page 11 Minute value flashes minute Press Press select the minute Setting the end time for all days of the week NOTE: flashes monday The defined end monday time must be copied to all days 6 : 22 of the week Press flashes copy copy...
  • Page 12 flashes add tu add tu 6 : 22 Press Press add we add Th add fr add sa add su Storing the nest opening end time flashes store store 6 : 22 Press...
  • Page 13 Programming Nest Closing Perform the following steps to define the time of day when the nests close and don’t allow chickens entry. Selecting the nest closing (C2) channel NEW P flashes new prog Press is displayed channel flashes channel Press Press switch to...
  • Page 14 Setting the nest closing start time (C2 On) is displayed NOTE: time on flashes At nest closing start time on time, the expulsion motor moves the expulsion grids to closed (diagonal) Press position our value flashes hour : 00 Press Press select the hour Minute value flashes...
  • Page 15 Setting the start time for all days of the week NOTE: flashes monday The defined start monday time must be copied to all days 18 : 20 of the week Press flashes copy copy 18 : 20 Press flashes add tu add tu 18 : 20 Press...
  • Page 16 Storing the nest closing start time flashes store store 18 : 20 Press Selecting the nest closing (C2) channel NEW P flashes new prog Press is displayed channel flashes channel Press...
  • Page 17 Setting the nest closing end time (C2 Off) is displayed NOTE: time off flashes This step is time off necessary to turn off the opening command after the grids are in place Press NOTE: Hour value flashes Closing end time hour should be six minutes after...
  • Page 18 Setting the end time for all days of the week NOTE: flashes monday The defined end monday time must be copied to all days 18 : 26 of the week Press flashes copy copy 18 : 26 Press flashes add tu add tu 18 : 26 Press...
  • Page 19 Storing the nest closing end time flashes store store 18 : 26 Press Returning to the main screen new prog Press Menu...
  • Page 20 +972-73-241-3001 https://www.plassonlivestock.com Copyright © 2021 Plasson, all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical or otherwise without prior written permission of Plasson.
