EZR23T QUICK GUIDANCE
EZR23T KURZANLEITUNG
EZR23T.Router.Works
Scan the QR code on a smartphone camera to view the full online
manual or type the URL on any device's web browser bar.
Scannen Sie den QR-Code auf einer Smartphone, um das vollständige Online-Handbuch
anzuzeigen, oder geben Sie die URL in die Webbrowserleiste eines beliebigen Geräts ein.
WORKING PRINCIPLE
WIE FUNKTIONIERT ES
INTERNET
PACKAGE CONTENTS
PACKUNGSINHALT
Check and count the package contents.
Please inform our support team if any components are missing.
4G Router
2 x 4G Antennas
SIM-Karten-Router
2 Stück 4G-Antennen
DC Power Adapter
AC-DC-Netzteil
Note:
The AC to DC power adapter contains the appropriate regional electrical
plug to match the destination, whether UK, EU, US, or AU standards.
4G ROUTER
WITH SIM SLOT
2 x WiFi Antennas
2 Stück WLAN-Antennen
LAN Cable
LAN-Kabel
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Outdoor Router EZR23T Series
Summary of Contents for Outdoor Router EZR23T Series
- Page 1 WORKING PRINCIPLE WIE FUNKTIONIERT ES INTERNET 4G ROUTER WITH SIM SLOT PACKAGE CONTENTS PACKUNGSINHALT Check and count the package contents. Please inform our support team if any components are missing. EZR23T QUICK GUIDANCE EZR23T KURZANLEITUNG 4G Router 2 x 4G Antennas 2 x WiFi Antennas SIM-Karten-Router 2 Stück 4G-Antennen...
- Page 2 INTERFACE OVERVIEW SIM CARD & POWER SUPPLY PORTS & SCHNITTSTELLEN SIM-KARTE & STROMVERSORGUNG PINHOLE SIM1 DC Socket PoE & PoE & DC Socket PoE & WAN SIM2 9~48Volt Reset Button PoE & LAN Indicators Dual-SIM Slot SIM-CARD TRAY FOR NANO-SIM (0.5” x 0.3”) SIM CARD DC ADAPTER Please turn off the power while...
- Page 3 LOCATION & SIGNALS After connecting to the router, open a web browser, enter the router IP http://192.168.20.1 on the address bar. Click the Login button to access the admin panel. STANDORT & SIGNALE http://192.168.20.1 * If unable to access the login page, CHOOSE A LOCATION AUTHORIZATION REQUIRED change a web browser and recheck...
- Page 4 LAN NETWORK Turn on DHCP mode on the phone or computer to obtain a local IP address from the router. To use a static IP address, please comply with the below format. Computer IP 192.168.20.100~249 ( pick one IP from 100~249 ) Subnet mask 255.255.255.0 ( 24 on Windows ) Gateway...
