Striem Command Center Operator's Manual

Ph monitoring system

Advertisement

Quick Links

TM
Command Center
pH Monitoring System
Operator Manual
Please read prior to installation and start-up.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Command Center and is the answer not in the manual?

Questions and answers

Summary of Contents for Striem Command Center

  • Page 1 Command Center pH Monitoring System Operator Manual Please read prior to installation and start-up.
  • Page 2: Table Of Contents

    Remote Data Retrieval pH Sensor Maintenance 12-14 Troubleshooting General Functions & Settings 16-20 a. Alarm Functions b. Solenoid Valve Control Functions c. Time & Date Set-Up d. pH Trend Warranty Striem 3100 Brinkerhoff Rd Kansas City, KS 66115 P: 913-222-1500 www.striemco.com...
  • Page 3: Introduction

    Customizations are simple using the easy-to-navigate menus on the color touch screen display. After a few quick start-up steps, the Command Center™ will begin recording to the micro SD card. A second card has been provided to limit the amount of missed data during data transfer from the SD card.
  • Page 4: Components

    Additional cable can be ordered for applications where the sensor will be mounted more than 10 ft. from the Command Center™. Note: If the sensor will be mounted within 10 ft. of the Command Center™, the quick disconnect clip can be removed for direct wiring to the Command Center™.
  • Page 5 Transfer data as frequently as possible to avoid data loss. 4. Relay – The installation of the 120 VAC relay is required to activate the solenoid valve control. The Command Center™ is pre-programmed to power a solenoid valve designed supply fresh water to the outlet line at pre-programmed control set points.
  • Page 6: Installation & Electrical

    Solenoid Control Activation The Command Center™ is pre-programmed to control a solenoid valve that will provide a fresh water flush to the waste stream when the pH level is approaching the high/low alarm limits.
  • Page 7: Data Storage & Activation

    The pH value, date and time will record to the included micro SD card after the SD card is installed in the Command Center™ PLC and the data storage function has been enabled and activated. After the data storage function has been enabled and activated, data will record continuously at a rate of once per minute.
  • Page 8: Reviving Data From The Sd Card

    Recorded data may be retrieved from the SD card by your computer. The card must be removed from the Command Center™ and inserted either directly into the computer or card reader connected to the computer. The files will be retrieved using the Excel program.
  • Page 9 6. Right-click the month you want to delete and select the “Delete” function from the drop-down list 7. This will delete the chosen file; make sure all needed data is saved prior to erasing 8. Return SD card to the Command Center™ PLC (See “Inserting SD Card”) SD card slot Ethernet Port...
  • Page 10: Ethernet Connection Activation

    8. Power Off/On using the power switch in the Command Center™ enclosure After the Ethernet port has been activated and connected to, the Command Center™ may be remotely monitored by the BMS. Note: For the Ethernet connection to activate, the power must be cycled Off/On.
  • Page 11: Remote Data Retrieval

    Remote Data Retrieval In order to remotely retrieve data through the Ethernet connection, the Unitronics Card Suite Program must be installed on the connecting computer and the program configured to the network’s settings. Follow the steps below to install and configure the Unitronics Card Suite Program. Installing Unitronics Card Suite program 1.
  • Page 12: Ph Sensor Maintenance

    pH Sensor Maintenance The pH sensor measures and transmits pH data from the waste stream to the Command Center™. The sensor is pre-calibrated and ready for installation upon delivery. The sensor end must remain wet at all times. Do not remove the protective cap until the sensor is installed in the waste stream.
  • Page 13 15. Once the sensor is placed back into the waste stream, press the “ESC” button. The pH monitoring and control system are now operational, and the main screen will be displayed on the Command Center™. Standard Cell Solution Replenishment and Salt Bridge Replacement The sensor requires periodical standard cell solution replenishment and salt bridge replacement to maintain pH measurement accuracy.
  • Page 14 Striem Note: The typical lifespan of the salt bridge is 1 year. Please contact Products if a replacement salt bridge is needed. 4. Turn sensor over and drain standard cell solution out of the reference chamber 5. Flush the reference chamber with small amount of standard cell solution 6.
  • Page 15: Troubleshooting

    Troubleshooting The Command Center™ will begin to display the pH level of the waste stream immediately after the system is powered “On”. The pH sensor is factory calibrated and ready for installation upon delivery. Below are troubleshooting steps that can be taken if the pH reading is not accurate.
  • Page 16: General Functions & Settings

    The “Alarm Silence” button will silence the local audible alarm located in the enclosure. When the Command Center™ is in alarm condition, the “Alarm Silence” button will flash until the alarm is acknowledged by pressing the button. The alarm will remain silent until the next alarm condition occurs.
  • Page 17 The “High pH Alarm Set Point” is the value at which the Command Center™ will go into alarm mode as the value of the stream pH increases. The “Low pH Alarm Set Point” is the value at which the Command Center™...
  • Page 18 Note: Command Center™ is pre-programmed for low and high “Alarm” set points of 6 and 9 pH, respectively. Pre-programmed low and high “Control” set points are 6.5 and 8.5, respectively. Both low and high “Dead Band” set points are a pre-programmed value of 0.5.
  • Page 19: Time & Date Setup

    Low Control Dead Band: 0.50 C. Time & Date Setup The Command Center™ displays time and date (Month-Date-Year) on the “Main” and “Trend” displays. The date and time are factory set. Central standard time is used for the time setting. Setting Time 1.
  • Page 20: Ph Trend

    D. pH Trend The Command Center™ displays a record (trend) of the waste stream pH and solenoid control valve status. The pH trace will follow the waste stream pH value over time. The current trend will display approximately two hours of operation.
  • Page 21: Warranty

    Warranty Striem Products warrants the Command Center™, to be free from any and all defects in manufacturing, workmanship or materials and will repair or replace products or components at its sole discretion within a period of one year from the date of shipment. Liability hereunder is...
