PRODUCT UNPACKING AND INSPECTION
Upon receipt of the product, perform the following unpacking and inspection procedures
N
OTE:
If damage to the shipping container is evident upon receipt, request the carrier to be present when the product
is unpacked
1 Carefully open the shipping package, follow any instructions that may be marked on the exterior Remove all cushioning
material surrounding the product and carefully lift the product from the package
2 Save the package and all packing material for possible use in reshipment or storage
3 Visually inspect the product and applicable accessories for any physical damage such as scratches, loose or broken parts or
any other sign of damage that may have occurred during shipment
N
OTE:
If damage is found, request an inspection by the carrier's agent within 48 hours of delivery and file a claim with the
carrier A claim for equipment damage in transit is the sole responsibility of the purchaser
OVERVIEW
The Flo-Check® USB Hydraulic System Analyzer can be used as a stationary or portable tester for both industrial and mobile
hydraulic system diagnostics, and analysis of the prognostic health of a hydraulic system It features flow, pressure and
temperature sensors that are monitored by a data acquisition module The module records the operating parameters of the
system and transfers them to a laptop via the USB port
The custom software utility is a Windows®-based application This intuitive software configures the displayed information
into user-selected engineering units and provides realtime graphics with instantaneous readings and trends for all three
measurement parameters The software permits the data to be saved as a csv file format, for use with a spreadsheet program
The Hydraulic System Analyzer is powered through the USB port of a PC, which makes it easy to setup and is ideal for portable
applications Interfaced to the PC application, the Hydraulic System Analyzer offers a straightforward method of monitoring
system parameters, complete with data acquisition
June 2022
TST-UM-02433-EN-02
Product Unpacking and Inspection
Page 5
