Technics SX-KN920 Service Manual

ip. o
a)
4)
ORDER NO. EMID961616
PCM Keyboard
SX-KN920
(M), (MC), (XM), (EN), (EH), (EF), (EZ), (EW), (EA),
(EP), (EK), (XL), (XR), (XS), (XD), (XT), (X), (XP)
AREAS
U.S.A. the United Kingdom
Canada New Zealand
Mexico Ausiralia
Norway, Sweden Malaysia
Denmark, Finland Saudi Arabia, Hong
Holland, Belgium, Kong, Kuwait
> France, Italy Taiwan
Germany : Thailand, Indonesia,
Switzerland lran, U.A.E., Panama,
: Austria Argentina, Peru, Brasil
Spain, Portugal, Philippines
Greece, Singapore,
South Africa
A\ WARNING
This service Information Is designed for experienced repair technicians only and Is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers In attempting to service a
product. Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any
attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious
injury or death.
Hf Specification
KEYBOARD
. | SOUND GENERATOR
MEUM NUMBE OF NOTES
SOUNDS
SOUND EDIT MEMORY : 40
TRANSPOSE
RHYTHM
START/STOP, INTRO & ENDING 1,2, FILL IN 1,2, COUNT INTRO, SYNCHRO & BREAK, TEMPO,
ae ee ee ee eee)
TECHNI-CHORD
PANEL MEMORY 2 BANKS x 5
16 TRACKS, 10 SONGS .
RESOLUTION : $6 PULSES PER QUARTER-NOTE ;
SEQUENCER STORAGE CAPACITY : APPROX. 30000 NOTES
RECORD MODES : EASY, REALTIME,STEP(CHORD,RHYTHM)
FUNCTIONS : TRACK ASSIGN, EDIT, SONG SELECT/NAME,MEDLEY
5 PARTS : BASS, ACCOMP 1,2,3, DRUMS
STORAGE CAPACITY : APPROX. 10000 NOTES
FUNCTIONS : BEND RANGE, MODE SELECT, PATTERN COPY, SINGLE LOAD, CHORD MAP
MEMORY : 3 BANDS x 10(VARIATION 1-4, INTRO 1,2, FILL IN 1,2, ENDING 1,2)
COMPOSER
©1996 Matushita Electric Industrial
CO., LTD. All rights reserved.
