OPERATION AND MAINTENANCE BOOK
FLAT - SUPERFLAT
DOCUMENT CODE: 0150MANFLEN.000
1. PREAMBLE
This manual must be considered as an integral part of the machine, and it must always be available for
the people interacting with the machine itself; the manual must always accompany the machine, even if it
is transferred to another user.
The operators must read this manual and carefully follow the instructions given therein, as VINSERVICE
MICRO MATIC shall not be held responsible for damage caused to people and/or property, or suffered by
the machine itself, if the following conditions are not complied with.
The Customer is required to keep trade secrets, therefore these documents and attachments must
not be tampered with or modified, reproduced or transferred to third parties without the permission of
VINSERVICE MICRO MATIC.
VINSERVICE MICRO MATIC S.R.L. Via G. Falcone, 26/34 24050 ZANICA (BG) Italy
Phone: +39.035.672361 Fax: +39.035.672699
www.vinservice.it | e-mail: vinservice@micro-matic.com
1
Advertisement
Table of Contents
Related Manuals for Vinservice FLAT
Summary of Contents for Vinservice FLAT
-
Page 1: Preamble
The operators must read this manual and carefully follow the instructions given therein, as VINSERVICE MICRO MATIC shall not be held responsible for damage caused to people and/or property, or suffered by the machine itself, if the following conditions are not complied with. -
Page 2: Symbols And Signs
2. SYMBOLS AND SIGNS The manual, and/or in some cases the machine, feature: plates, symbols or icons that indicate an obligation, a danger or a prohibition. OBLIGATION SIGNS • Obligation to consult the document, which must be available for future use and must not be deteriorated in any way. -
Page 3: Table Of Contents
3. SUMMARY 1. PREAMBLE ......................1 2. SYMBOLS AND SIGNS ..................2 3. SUMMARY ......................3 4. SUPPLY CONDITIONS ..................4 4.1 REFERENCE STANDARDS ....................4 5. ACCIDENT PREVENTION AND RESIDUAL RISKS ..........5 6. LIFTING AND TRANSPORT ..................6 7. AIM OF THE DOCUMENT ..................6 8. PERSONNEL QUALITIES..................7 9. FIELD OF EMPLOYMENT ..................7 10. EQUIPMENT DESCRIPTION ................8 11. QUICK OPERATION GUIDE ................9 11.1 FIELD OF EMPLOYMENT .................... -
Page 4: Supply Conditions
VINSERVICE MICRO MATIC will not be held liable for any failure to comply with the standards governing correct installation. VINSERVICE MICRO MATIC will not be held liable for any loss in production, unless expressly shown in the purchase order. VINSERVICE MICRO MATIC will not be held liable for any defects or malfunction arising from; improper use of the equipment, alterations due to the transportation or peculiar environmental conditions, lack of or improper maintenance, manhandling or improper service;... -
Page 5: Accident Prevention And Residual Risks
Carefully keep the technical documentation accompanying the equipment. • VINSERVICE MICRO MATIC will not be held liable if installation instructions are not followed. • Do not use the equipment if any operating fault occurs. -
Page 6: Lifting And Transport
sheet metal, self-threading screws, etc… • The single equipment’s output sound level (Noise) when operating at full capacity and correct maintenance is inferior to 70dBA thus absolutely harmless to the operator. Whenever the noise threshold is exceeded due to different and unpredictable installation cases, ask for the intervention of a specialized technician. •... -
Page 7: Personnel Qualities
9. FIELD OF EMPLOYMENT VINSERVICE MICRO MATIC will not be held liable for damages of any type arising from non compliant or unwise usage. The equipment MUST neither be operated by unqualified personnel nor qualified personnel doing so in non compliance with what is described in the present user’s mannual and attached documentation. -
Page 8: Equipment Description
10. EQUIPMENT DESCRIPTION • The cooler VINSERVICE MICRO MATIC belonging to glycol line allows the temperature of the liquid recirculating in the system to lower. As a result the temperature of the dispensing body (C) will also lower and will cause either a condensation or ice effect on the body surface. -
Page 9: Quick Operation Guide
11.2 INSTALLATION ATTENTION: • VINSERVICE MICRO MATIC advises the cleaning of the equipment prior to use with a suitable cleaning agent. • It is recommended to protect the unit with a ground-fault circuit interrupter. • It is recommended to install a residual-current device (RCD) a nominal operating residual current below 30mA. -
Page 10: Digital Thermostat: Instructions
agitator keeps on running to stir water and ease the heat exchange. • The probe (G), positioned in the water, reads the temperature and controls the cooling system switching on and off. • During operation, the recirculation pump (B) allows the cooling of the distributor (C). •... -
Page 11: Maintenance
Used for selecting the parameters and for increasing the value to be set. Also used for acti- ▲ / vating manual defrost (hold pressed for 5 sec.). Used (press and release) for visualising the instrument variables (measured temperatures etc.). -
Page 12: Cleaning And Sanitization
11.5 CLEANING AND SANITIZATION The unit can be cleaned using the detergent TM DESANA or any other industry certified detergent. This procedure must carried out by a trained technician using the appropriate personal protective equipment. If using any another industry certified detergent, it is important to follow the mixing ratio and other instructions as indicated in its literature. -
Page 13: Super_Flat Main Components
12. SUPER_FLAT MAIN COMPONENTS 12.1 DIGITAL THERMOSTAT... - Page 14 1/2HP R404 115V60 COMPRESSOR WASHER ISO 7089 - 4,3 x 9 PROBES SUPPORT FOR MEC. TERM. SUPER FLAT FRONT PANEL ST.PLAS TANK SUPER FLAT 25 LT RBD710-D SUPER FLAT COVER TANK SIDE TANK DRAIN 2010 Suoerfllat compr. side lid NUT TANK DRAIN 2010...
-
Page 15: Electronic Thermostat
12.2 ELECTRONIC THERMOSTAT... - Page 16 ISO - 4032 - M4 12RA POWER CONNECTOR FEMALE 1/2HP R404 115V60 COMPRESSOR WASHER ISO 7089 - 4,3 x 9 TANK SUPER FLAT 25 LT RBD710-D SUPER FLAT FRONT PANEL ST.PLAS TANK DRAIN 2010 SUPER FLAT COVER TANK SIDE NUT TANK DRAIN 2010 Suoerfllat compr.
-
Page 17: Flat_Glycole Main Components
13. FLAT_GLYCOLE MAIN COMPONENTS... - Page 18 ISO 4017 - M4 X 20-C LIGHTED BIPOL. ELECTR. SWITCH WASHER ISO 7089 - 4,3 x 9 POWER CONNECTOR FEMALE FLAT & MINI LADY COPPER EVAPOR TANK FLAT 13 LT RBD710-D 12/14 220/50 PUMP DIGITAL THERMOSTAT Z31Y 110- 12/14 115/60 PUMP...
-
Page 19: Technical Drawing Superf_Flat
14. TECHNICAL DRAWING SUPERF_FLAT measures in mm... -
Page 20: Technical Drawing Flat_Glycole
15. TECHNICAL DRAWING FLAT_GLYCOLE measures in mm... -
Page 21: Technical Specifications
Equipment and manufacturer identification. The CE tag is placed in the position as shown in the picture below. The manufacturer name plates mounted on the side of the equipment which must be cleaned regularly must neither be removed, damaged, soiled, nor hidden, etc. 3194408 FLAT SUPER_FLAT POWER 1/6 HP... -
Page 22: Electric Scheme
17. ELECTRIC SCHEME 17.1 DIGITAL THERMOSTAT LEGEND DIGITAL THERMOSTAT FOR ICE BANK PLUG BIPOLAR SWITCH STIRRER COMPRESSOR 618106 07 30 INTERNAL Out1: 16 (9) A 10 (4) A 12 A Res. BUZZER 30 LRA 5 FL A Out2 :8 (3) A6 (4) A 6 A Res. -
Page 23: Mechanical Thermostat
17.2 MECHANICAL THERMOSTAT LEGEND MECHANICAL THERMOSTAT FOR ICE PLUG BANK BIPOLAR SWITCH STIRRER COMPRESSOR... -
Page 24: Barcinova Thermostat
17.3 BARCINOVA THERMOSTAT LEGEND PLUG BIPOLAR SWITCH COMPRESSOR STIRRER BARCINOVA PROBE BARCINOVA THERMOSTAT FOR ICE BANK... -
Page 25: Cooling Scheme
18. COOLING SCHEME EVAPORATOR COMPRESSOR CAPILLARY TUBE CONDENSER... -
Page 26: Troubleshooting
19. TROUBLESHOOTING ANOMALIES FOUND POSSIBLE CAUSES CHECKS AND REMEDIES The chiller does not work (the Lack of voltage Check the power main master switch (IG) warning light Check that the plug is properly in- does not turn on) serted in the socket outlet The machine does not cool (the Low level of refrigerant Check the refrigerating circuit... -
Page 27: Notes
NOTES... -
Page 28: Declaration Of Conformity
“EMC” 2004/108/CE ANSI/UL 471 CSA C22.2 No. 120 NSF 18:2016 VINSERVICE MICRO MATIC S.R.L. - VIA G.FALCONE 26/34. 24050 ZANICA (BG) Declares under their own responsibility that: FLAT - SUPERFLAT HAVE BEEN DESIGNED AND MANUFACTURED IN CONFORMITY WITH THE SAFETY REQUIREMENTS PROVIDED FOR BY THE “CE”...
