Philio PSM08 Manual

Door/Window Sensor PSM08
The door/window sensor PSM08 has door/window sensor function,
based on Z-Wave TM technology.
This device is a Security Enabled Z-Wave Plus Product. Z-Wave
wireless communication protocol designed for home automation,
specifically to remotely control applications in residential and light
commercial environments. The technology uses a low-power RF radio
embedded or retrofitted into home electronics devices and systems,
such as lighting, home access control, entertainment systems and
household appliances.
This product can be included and operated in any Z-Wave
with other Z-Wave TM certified devices from other manufacturers and/or
other applications. All non-battery operated nodes within the network
will act as repeaters regardless of vendor to increase reliability of the
network.
The device adopt the Z-Wave
network system is all made by Z-Wave
network system will have the advantages as below.
TM 500 series chip, when your Z-Wave
TM 500 series devices. The
Concurrent multi-channel support reduces external interference.
•
Better RF range, improve about 10 meters in indoor.
•
Support 100 Kbps transmit speed, speed up communication.
•
Add to/Remove from Z-Wave
There are three keys in the device, one is a button, the others are
tamper keys. Button can add, remove, reset or association from Z-
Wave TM network.
In the first time, add the device into the Z-Wave
make sure the primary controller is in the add mode. And then power
on the device, just take out the insulation Mylar in the back side of the
device. The device will auto start the NWI (Network Wide Inclusion)
mode. And it should be included in 5 seconds.
Notice: Including a node ID allocated by Z-Wave
TM is a
"Add" or "Inclusion". Excluding a node ID allocated by Z-Wave
Controller means "Remove" or "Exclusion".
Function
Add
TM network
Remove
TM
1
TM Network
Description
1. Have Z-Wave TM Controller entered inclusion mode.
2. Pressing button once to enter the inclusion mode.
3. After add successful, the device will wake to
receive the setting command from Z-Wave
Controller about 20 seconds.
1. Have Z-Wave TM Controller entered exclusion mode.
2. Pressing button once to enter the exclusion mode.
Node ID has been excluded.
TM network. First,
TM Controller means
TM
TM
