Philio PSM09-A User Manual

PSM09-A/B
Recessed Door Sensor + Door lock Sensor
The PSM09 can detect the the door is open or not, and lock or unlock.
The Recessed door sensor PSM09 is Base on Z-Wave
It is the Z-Wave TM plus product, it support the security, OTA... Those newest
features of the Z-Wave TM technology. Z-Wave
protocol designed for home automation, specifically to remotely control
applications in residential and light commercial environments. The technology
uses a low-power RF radio embedded or retrofitted into home electronics
devices and systems, such as lighting, home access control, entertainment
systems and household appliances.
Notice: if user use some command,it have to check device is security bootstrap
otherwise some command can not increment.
Function Compare A/B
Door Sensor
PSM09-A V
PSM09-B V
TM technology.
TM is a wireless communication
Door lock Sensor
V
CAUTION
– replacement of a battery with an incorrect type that can defeat
a safeguard (for example, in the case of some lithium battery
types);
– disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion;
– leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
flammable liquid or gas;
– a battery subjected to extremely low air pressure that may re-
sult in an explosion or the leakage of flammable liquid or gas
The marking information is located at the bottom of the apparatus.

Specification

Operating Voltage
Range
Operating Temperature
Storage Temperature
Location
Frequency Range
RF Maximum Power (peak)
RF Maximum Power (Average) -10dBm (Average)
FCC ID
Patent number
** Specifications are subject to change and improvement without notice.
1
DC3.6V 1000mAh (ER14250 Li-Battery)
Minimum 40M in door and 100M in outdoor,
line of sight
-10°C ~ 40°C (85% humidity)
-20 C ~ 60°C
Indoor use only
868.40 MHz, 869.85 MHz (EU)
908.40 MHz, 916.00 MHz (US)
920.9MHz, 921.7MHz, 923.1MHz (TW/KR/Thai/SG)
+5dBm (peak)
RHHPSM09
US 10,287,801 B1/ 3215012 (JP)
202017107537.0 (DE)
