Summary of Contents for Solt GGSFLW800W
- Page 1 MODEL GGSFLW800W V 1.4 | 0124 User Manual Front Load Washing Machine...
- Page 2 Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO.
- Page 3 You can use our online Support Centre at anytime by Sôlt — visiting http://support.residentiagroup.com.au, or you can Online. contact us via calling us on 1300 11 HELP (4357). www.solt.house — Instagram. It is important that you read through the following use and /solt.house —...
- Page 4 This page is intentionally left blank...
-
Page 5: Table Of Contents
2 Purchase Details Contents 3 Welcome 6 Safety Instructions 8 Installation 10 Your Washing Machine 13 Quick Start Guide 14 Operating Instructions 19 Cleaning & Maintenance 21 Troubleshooting 23 Technical Specifications 25 Attach Your Receipt 26 Warranty Information Customer Care Sôlt recommends the use of original spare parts. -
Page 6: Safety Instructions
Safety Instructions CONDITIONS OF USE INSTALLATION • This appliance is intended to be used in household • Remove all the packaging. and similar applications such as farm houses or by • Do not install or use a damaged appliance. customers in serviced apartments, holiday apartments •... - Page 7 ELECTRICAL CONNECTION APPLIANCE USE WARNING: Caution, risk of fire and electrical shock! WARNING: Risk of fire, explosion, electric shock or damage to the appliance. • To ensure your safety, power plug must be inserted into an earthed three-pole socket. Check carefully and •...
-
Page 8: Installation
Warning! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on Installation the power cord. W> 20mm Before installing the machine, the location characterized follows shall be selected: 1.Rigid, dry, and level surface INSTALLATION POSITIONING •... - Page 9 including the rubber transport bolts with using the cover caps. including the rubber using the cover caps. 1.Put it into the water trough. 2.Connect it to the branch drain parts and keep them a spanner. parts and keep them the trough. for future use.
-
Page 10: Your Washing Machine
Your Washing Machine PRODUCT COMPONENTS Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service panel Drain hose CONTROL PANEL Start/Pause Press the button to start or pause the washing cycle. Programmes Available according to the laundry type. Program selection dial: 3 Additional function buttons: Different washing cycles can be selected according to... - Page 11 DISPLAY SCREEN INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Display Drum Clean Door Child lock Pre Wash Service filter Door lock Extra Rinse Drain hose Delay Mute Note! • The product line chart is for reference only, please refer to real product as ACCESSORIES standard.
- Page 12 Your Washing Machine (Continued) OPERATIONS Detergent Dispenser DETERGENT DISPENSER Pre wash detergent The detergent drawer of your washing machine Main wash detergent is split into three compartments: Softener Pre-wash detergent compartment. Refer to the Wash Programs Table to see which programs utilise a pre-wash. Main detergent compartment.
-
Page 13: Quick Start Guide
Quick Start Guide QUICK START: Follow the procedure below to operate your washing machine. CAUTION: • Before washing, please make sure it’s installed properly. • Your appliance was thoroughly checked before it left the factory. To remove any residual water and to neutralise potential odours, it’s recommended to clean your appliance before first use. -
Page 14: Operating Instructions
Operating Instructions PREPARATION BEFORE WASHING CLOTHES Please follow these steps carefully to avoid trouble with your washing machine and damaging your clothing. Washing Considerations Pay Attention to Detergents • The working condition of the washer should be • Only use suitable front load washing machine (0-40)°C. - Page 15 WASHING CLOTHES FOR THE FIRST TIME Selecting the main washing program depend on the types Before washing any clothes, please perform one cycle of clothing to be washed, as follows: without clothes inside as follows: Steam Wash • Connect the power source and water. •...
- Page 16 Operating Instructions (Continued) Bulky Load ADDITIONAL WASH OPTIONS You can select this procedure for washing bulky items. Delay Function Baby Care The Delay function can be set with this button, where the Washing the baby’s clothes, it can make the baby’s wear delay is 0–24 Hrs.
- Page 17 Reload (Add a Garment) Function Mute function This function can be executed during operation of a This function allows you to turn the audible tone on or off, washing program. When the drum of the machine is still in to indicate that your washing program is complete. motion and/or there is a large amount of water inside, the By default, the audible signal is set to On.
- Page 18 Operating Instructions (Continued) Washing Program Table GGSFLW800 Load Default Temp Default Speed Program Default Time (kg) (° C) (RPM) Steam Wash 1000 1:26 Cotton 1000 1:28 Synthetic 1000 1:25 1000 0:58 Jeans 1:40 ECO Wash 1000 0:59 20° C 1000 1:01 Spin –...
-
Page 19: Cleaning & Maintenance
Cleaning & Maintenance CLEANING PROCEDURES FROZEN WASHING MACHINE Should the temperature drop below zero and your washing WARNING: Before beginning any cleaning or machine becomes frozen, you should: MAINTENANCES MAINTENANCES maintenance, always ensure the appliance is switched off, • Disconnect the power supply for the washing machine. the power plug is removed from the power outlet and the •... - Page 20 Cleaning & Maintenance (continued) CLEANING THE INLET FILTER CLEANING THE DRUM PUMP FILTER You should clean the inlet filter every 3 months, or if (REMOVING FOREIGN OBJECTS) you find that insufficient water is being supplied to your WARNING: To avoid the risk of an electric shock, washing machine when the supply tap is open.
-
Page 21: Troubleshooting
Troubleshooting WARNING Only authorised technicians can carry out repairs. Before contacting our customer service team, please refer to the table below to see if your fault can be fixed by yourself. Should a service technician visit be arranged and its found there are no faults with the appliance, a call out charge will apply. - Page 22 Troubleshooting (continued) INDICATION PROBLEM SOLUTION • Restart after the door is closed Door is not closed properly • Check if there are clothes or washing articles stuck • Check if the water pressure is too low Water injecting problem • Straighten the water pipe while washing •...
-
Page 23: Technical Specifications
Technical Specifications Below outlines the technical specifications for your Washing Machine. Model GGSFLW800W Washing Capacity 8.0kg Dimensions (W × D × H mm) 595 × 533 × 850 mm Net Weight 60kg Rated Power 1950W Power Supply 220-240V, ~50Hz, 10Amp Standard Water Pressure 0.05MPa~1.0MPa... - Page 24 This page is intentionally left blank...
-
Page 25: Attach Your Receipt
Attach your receipt to this page... -
Page 26: Warranty Information
Warranty Information WARRANTY TERMS & CONDITIONS IN THIS WARRANTY LAUNDRY ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in the This document sets out the terms and conditions of the ACL; product warranties for Residentia Group Appliances. - Page 27 You will bear the cost of transportation, travel and For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group in Australia, the Appliances come with a Group or its ASR. If you reside outside of the service guarantee by Residentia Group that cannot be area, you will bear the cost of: excluded under the Australian Consumer Law.
-
Page 28: 1300 11 4357 | E. Support@Residentiagroup.com.au
An initiative by Residentia Group T. 1300 11 4357 E. support@residentiagroup.com.au www.solt.house...
