Summary of Contents for Planet Audio PATV85
- Page 2 1x User manual + 1x Warranty card The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of ® such marks by Planet Audio is under license. Other trademarks and trade names are those of their respective owners.
-
Page 3: Before You Start
Before You Start Read and understand all instructions before you use your product. If you do not follow the instructions in this manual, we are not responsible for injury or damage resulting from improper handling. This will also void the warranty. Important Safety Precautions •... - Page 4 Getting to Know Your PATV85 Introduction The product is a Bluetooth speaker system which is ideal for installation in a ATV (All Terrain Vehicle) or UTV (Utility Vehicle). You can stream audio from a mobile phone to this product via Bluetooth. You can also play music from an external device (e.g.
-
Page 5: Mounting The Unit
Mounting the Unit Mounting on ATV or UTV Always consult an expert when in doubt about the installation. Use only the supplied accessory for mounting. Using other mounting methods may void the warranty. To ensure safety of the mounted sound system, always check the mounting conditions (e.g. mounting straps) of the sound system before each vehicle ride. -
Page 6: Power Connection
Power Connection Option 1: Using Power Port If your vehicle has a 12V power port, directly connect the sound system to your vehicle for power connection. Connect the supplied functional controller: Align the arrows marked on the connectors for connection. Insert the 12V power port plug of the sound system into your vehicle power port. - Page 7 Power Connection Align arrows Red wire Black wire On/Off switch Fuse Battery (not included) (not included) Vehicle’s metal frame Option 3: Direct connection to vehicle battery Important: • To avoid short circuits and any resulting damage to the sound system, the negative terminal of the vehicle’s battery must be disconnected first.
-
Page 8: Mounting The Controller
Mounting the Controller Note: The supplied functional controller is weatherproof. However, never submerge it. Option 1: Surface Mount You may use double sided adhesive tape (not included) to fasten the supplied functional controller. Regularly check the taped controller to ensure its fastening. Option 2: Handlebar Mount Assemble and fasten the mounting clamp on your handlebar. - Page 9 The Bluetooth LED indicator on the functional controller flashes blue. This indicates that the sound system enters Bluetooth pairing mode. On your mobile device, enable Bluetooth function and select the device name (“Planet Audio ATV”) to pair the sound system with the mobile device. If prompted for password, input “0000”.
- Page 10 You can listen to an external audio device (e.g. MP3 player or a mobile phone) through this sound system. Source LED indicator Connect the AUX input (3.5mm) on the functional controller to the audio output jack on your mobile phone, using the following audio cable.
-
Page 11: Fuse Replacement
Fuse Replacement Fuse replacement of the vehicle power port plug If the power LED indicator on the power port plug does not illuminate, this indicates the fuse inside the power port plug is blown. Replace the blown fuse with a new 10A AGC fuse (glass cartridge type). Locate the screw cap on the front end of the power port plug. -
Page 12: Troubleshooting
Troubleshooting If you have problems using this product, check the following points before you request service. If you still have a problem, contact our technical support. Problem Solution Power connection is not made. See the section “Power Connection” for details. No power. -
Page 13: Specifications
Specifications Bluetooth Bluetooth version ..........3.0 / EDR Bluetooth profile ..........A2DP, AVRCP Transmission distance ........up to 33 ft /10 m (line of sight) Speakers Dimensions ............8” Cone type ............PP carbon + rubber surround Tweeter size .............1.5” PEI soft dome Amplifier Input impedance ..........10 kΩ Frequency response .........45 Hz - 25 kHz LED Light Bar Current draw .............3A total... - Page 14 0324...
