ZyXEL Communications Dimension ES-2108 Support Notes

Es-2108 series
Hide thumbs Also See for Dimension ES-2108:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
ZyXEL ES-2108 Series
(ES-2108/ES-2108G/ES-2108PWR/ES-2108-LC)
Ethernet Switch

Support Notes

Version 3.60
Feb 2006

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications Dimension ES-2108

Summary of Contents for ZyXEL Communications Dimension ES-2108

  • Page 1: Support Notes

    ZyXEL ES-2108 Series (ES-2108/ES-2108G/ES-2108PWR/ES-2108-LC) Ethernet Switch Support Notes Version 3.60 Feb 2006...
  • Page 2 What is default login password of the console, telnet, and FTP? How to change the password? How to access the Command Line Interface? If I forgot the Switch password, how can I reset the password to default? How do I configure an IP address?
  • Page 3 When I enabled Port Isolated mode, what is the uplink port on ES-2108-LC? Remaining: The following demonstration may not use the exact model that you are using. However, their functions and settings work the same way. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...

  • Page 4: Firmware Upgrade

    Click on the “Click Here” link of the Firmware Upgrade to bring up the following screen. Browse the firmware located or type in the path into the “File Path” field. Click on the Upgrade button. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 5 Enter “ATGO” to restart the switch after done uploading the firmware. From Command Line FTP: Download (and unzipped) the correct model firmware to your computer. Launch the FTP client on your PC to login to Switch. (From the command prompt, type “ftp <Switch IP>” Press “Enter” for the User name Enter password to get the ftp prompt.

  • Page 6: Restore A Configuration File

    Browse to locate the file with the file name or type in the path and the file name into the “File Path” field. Click on the Restore button. From Console Port: Connect to the console port and open the Terminal Emulation Software. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 7 From Command Line FTP: Download (and unzipped) the correct model firmware to your computer. Launch the FTP client on your PC to login to Switch. (From the command prompt, type “ftp <Switch IP>”. Press “Enter” for the User name Enter password to get the ftp prompt.

  • Page 8: Backing Up A Configuration File

    From Console Port: Connect to the console port and open the Terminal Emulation Software. Restarting the Switch to enter the debug mode via the terminal. Enter “ATTD” All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 9 From Command Line FTP: Download (and unzipped) the correct model firmware to your computer. Launch the FTP client on your PC to login Switch. (From the command prompt, type “ftp <Switch IP>” Press “Enter” for the User name Enter password to get the ftp prompt.

  • Page 10: Load Factory Defaults

    Click OK to go to the following dialog. Click on the OK button. Now, all switch configurations has been reset to the factory defaults and the system will be restarted. Please note that the switch IP address is now 192.168.1.1.
  • Page 11 Physical Switch connection How to connect two switches via Fiber Channel ES-2108-LC comes with a mini-GB port and a 100FX SFP port. ZyXEL offers Small Form-factor Pluggable (SFP) transceivers for Gigabit Ethernet and Fiber Channel applications. These small, modular optical interface transceivers offer...
  • Page 12 Here is the photo of the SFP-SX Transceiver & the LC/LC Fiber Cable. Steps to complete this scenario 1. First, pick up your ES-2108-LC and GS-4024Switch and power them up. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 13 ES-2108 Series Switch Support Notes Photo of the ES-2108-LC Switch 2. Find both Mini-GB Port on ES-2108-LC and GS-4024. 3. Get one transceiver and plug it into the Mini-GB Port of ES-2108-LC All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 14 ES-2108 Series Switch Support Notes 4. Plug another transceiver into the Mini-GB Port of GS-4024 Switch All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 15 5. Remove both side of the protection cap from the LC/LC Fiber Cable. 6. Plug the LC/LC Fiber Cable into the transceivers on both ES-2108-LC and GS-4024 Switch. If you connected the cable correctly, the LED of the “LINK” will light up. All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 16 10. From PC “Delta”, PING PC” Alpha” at 192.168.1.4 11. Now you can confirm that the network connection between ES-2108-LC and GS-4024 is up and running. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes PC “Delta” : 192.168.1.5/24)

  • Page 17: What Is Virtual Lan

    The most difference between both VLAN implementations is Tagged VLAN can across Layer-2 switch but Port-based VLAN cannot. Port-based VLAN • Port-based VLANs are VLANs where the packet forwarding decision is based All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 18 An egress port is an outgoing port, that is, a port through which a data packet leaves. There are 5 hosts (Host A, B, C, D and E) connected to a 5-port layer-2 switch which supported port-based VLAN.
  • Page 19 Port-based VLAN across different switch • Port-based VLAN is specific only to the switch on which it was created. Definitely, Port-based VLAN can't across different switches. As the following network diagram shown in most MTU case, for the sake of security, subscribers are isolated with each other except for the gateway.
  • Page 20 Switch-2 VLAN 3 member port: port 4 and port 1 • Host A can't talk to Host B due to the port-based VLAN in Switch-2, and Host C can't talk to Host D due to the port-based VLAN in Switch-3. But both Switch-2 and Switch-3 uplink to the none VLAN Switch-1.
  • Page 21 For Switch-1, port 1, port2, and port 3 are allowed to communicate back and forth with uplink port 4, but not with other ports. Switch-1 VLAN 1 member port: port 1 and port 4 • Switch-1 VLAN 2 member port: port 2 and port 4 •...
  • Page 22 ES-2108 Series Switch Support Notes Scenario In this scenario, Port Based VLAN is used to separate one physical Switch into two smaller logical Switches. Port 1~4 and 9, 10 are in one group. And Port 5~10 are in another group. Port-based VLANs are specific only to the switch on which they were created.
  • Page 23 6. After you login successfully, you will see a similar screen like below. 7. First, we need to tell the Switch to run VLAN as port based instead of 802.1q based. In order to do so, we first click on the “Basic Setting”, then “Switch Setup”;...
  • Page 24 ES-2108 Series Switch Support Notes 8. Now, you need to tell the Switch how you are going to separate the physical Switch into some logical small Switches. Thus, we click “Advanced Application” then “VLAN”. On the right screen, check the boxes to suit your need.
  • Page 25 10. For example, PC A: 192.168.1.4/24 PC B: 192.168.1.5/24 PC C: 192.168.1.6/24 PC D: 192.168.1.7/24 PC Z: 192.168.1.99/24 11. PING PC B from PC A (Should work) All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 26 ES-2108 Series Switch Support Notes 12. PING PC Z from PC A (Should work) 13. PING PC C from PC A (Should NOT work) All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 27 5. Put “en” or “enable” to go into the privileged mode. Then put “config” to go into the configuration mode. 6. Put the following commands to setup Port Based VLAN on the ES-2108-LC Switch in this All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 28 VLAN and QoS (Quality of Service) priority identification. The VLANs can be created statically by hand or dynamically through GVRP. The VLAN ID associates a frame with a specific VLAN and provides the information that switches need to All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 29 VID (VLAN Identifier) of null (0) is called a priority frame, meaning that only the priority level is significant and the default VID of the ingress port is given as the VID of the frame. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 30 How 802.1Q VLAN works • According to the VID information in the tag, the switch forward and filter the frames among ports. These ports with same VID can communicate with each other. IEEE 802.1Q VLAN function contains the following three tasks, Ingress Process, Forwarding Process and Egress Process.
  • Page 31 VID: VLAN ID Port: The switch port number Ad Control: Registration administration control. There are 3 type of ad control, including forbidden registration, fixed registration and normal registration. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 32 3. Egress Process: The Egress Process decides if the outgoing frames but be sent tagged or untagged. The Egress Process refers to the egress tag control information in All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes Port...
  • Page 33 How to connect two switches using VLAN? I want to make VLAN on two layer 2 switches, and I want to connect first switch to second switch with trunk port. There will be 5 VLAN on first ES2024 and there will be 7 VLAN on second switch.
  • Page 34 VID:103 (port 7,8,9,10,"25 TAG") VID:104 (port 23,24,"25 TAG") VID:105 (port 11,12,13,14,"25 TAG") VID:106 (port 15,16,17,"25 TAG") VID:107 (port 18,19.20,21,"25 TAG") ------------------------------------- In switch B, add port 25 in each VLAN VID:101 (port 1,2,3,,4,"25 TAG") All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 35 Port 1, 2, 3, 4 : Port 6, 7, 8, 9, 10, : Port 11, 12, 13, 14, : Port 15, 16, 17, 18: Port 19, 20, 21, 22, 23: Port 25:PVID=any All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...

  • Page 36: What Is Spanning Tree Protocol

    When the broadcast frame arrives at Switch B, Switch will repeat above process, flood it to Segment A. The broadcast frame will endlessly travel around the loop network even Router has already received this frame. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 37 2. Filtering Database Instability: When multiple copies of a frame arrive at different ports of a switch, the MAC entry instability in Filtering Database will occur. Host sends an unicast frame to Router (source MAC address is Host's MAC, destination MAC address is Router's MAC). Both Switch A and Switch B will receive this frame and learn MAC address of Host on Port 2.

  • Page 38: How Stp Works

    STP operation is listed as the following: 1. Select a root bridge Only one switch/ bridge can be selected as the root bridge in a given network. All other decisions in the network, such as which port is blocked and which port is put in forwarding mode, are made regarding this root bridge.
  • Page 39 2. Select a root port for the non-root bridge For the non-root switch/bridge, there will be one root port. The root port is the port through which this non-root switch / bridge communicates with the root bridge (the "leaf"...
  • Page 40 Priority = 32768 Port 1 Port 2 Cost Cost Priority 128 Priority 128 All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes Switch C: MAC = 00A0C5333333 Priority = 1 Port 1 Port 2 Port 1...
  • Page 41 For non-root bridge Switch A, Port 1 path cost to root bridge is 19, Port 2 path cost is 119, 100 (Switch A Port 2) + 19 (Switch B Port 1). For Switch B, Port 1 path cost is 19, Port 2 path cost is 119. Root port = Port 1 of Switch A and Switch B because it has the lowest path cost to the root bridge Switch C.

  • Page 42: Switching Security

    ES-2108 Series Switch Support Notes Switching security MAC freeze As an added protection against network intrusion attacks, ZyXEL has implemented the MAC Freeze feature on ES-3124, ES-3124PWR, GS-2024 and ES-2024A. Security has been the focus of our Ethernet switch design.
  • Page 43 MAC addresses. Figure 2: Displaying MAC Addresses From MAC Freeze After you enabled MAC freeze on port 6 using the CLI command, the switch automatically disables MAC address learning on that port. Display the Port Security screen to verify this.
  • Page 44 ES-2108 Series Switch Support Notes All contents copyright (c) 2006 ZyXEL Communications Corporation.

  • Page 45: Centralized Management

    SNMPc manager to perform network configuration, system management, event/alarm management, performance management and security for all ZyXEL’s Ethernet Switch solutions. SNMPc is network management software produced by Castle Rock that constantly probe the network element (NE) and collect information of those NE for EMS.
  • Page 46 View Window Area: Map View, Mib Tables and Mib Graph windows are displayed here. ♦ View Window Area: Map View, Mib Tables and Mib Graph windows. Figure 2 Main elements of SNMPc All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 47 Green is working and Rd is no response from the device. ♦ System message Panel: View the alarm Status and port status of the selected switch. Figure 3 Overview of EMS All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 48 Netatlas with adding a new device. Follow the procedures from Step 1 to Step Step 1: In the edit button bar shown in the Figure 4 where you may select the icon to insert a new element. Figure 4 Adding a new Device All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 49 Figure 5 Map Object Properties Step 4: In the map object properties, select Access tab to set the parameters of Read Access Mode to SNMP V2c shown in Figure 6. Change the value of All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 50 Step 5: In the map object properties, select Access tab to set the parameters of Read /Write Access Mode to SNMP V2c shown in Figure 7. Change the value of Read/write Access Mode to SNMP V2c. Figure 7 Read/Write Access Mode All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 51 ES-2108 Series Switch Support Notes Step 6: In the map object properties, select Access tab to set the parameters of Read community to public as shown in Figure 8. Figure 8 Read Community All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 52 Read community to public in Figure 9. Change the value of Read//write Community to Public. Figure 9 Read/write Community Step 8: In the Selection tool menu, Click ES-2108 to manage the device. Figure 10 Device Selection All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 53 ES-2108 Series Switch Support Notes Step 9: After the selection, a pop-up menu will display the NetAtlas switch manager diagram. Click the Switch Manager to enter the EMS Mapping shown in Figure 11 Figure 11 Device Selection Step 10: In the EMS mapping, it display a logical hierarchy for the device. In the device list, you may see the devices are added in the Rootmap shown in All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 54 ES-2108 Series Switch Support Notes Figure 12. Figure 12 Rootmap Step 11: Click the ES-2108 to configure the device shown in Figure 13. Figure 13 Device mapping All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 55 VLAN2 in GS-4024. Here are the procedures. Step 1: In the device panel list shown in Figure 12, right-click Configuration, Switch Configuration and then Switch Setup tab as shown in Figure 12 and Figure 13. Step 2: Define the VLAN type, there are two types of VLAN, one is 802.1Q and the other is Port-based VLAN.
  • Page 56 After the VLAN type selection, a pop-up window indicates that you have finished the configuration. Then after we have defined the VLAN type to be the 802.1Q, go back to click the Configuration and then VLAN configuration in All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 57 Click the New button to create a new VLAN ID in Figure 16. Figure 16 Creating a new VLAN ID Selecting Egress ports and defines them to be tagged or untagged in Figure 17 Figure 17 Selecting the ports All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 58 ES-2108 Series Switch Support Notes For more information, reference the user guide of NetAtlas. All contents copyright (c) 2006 ZyXEL Communications Corporation.

  • Page 59: Cluster Management Overview

    To discover the clustering members, the clustering Manager broadcasts a HDAP (Host Discovery and Address assignment Protocol) Discover request. Step 2: Cluster manager (Master device) All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes 1. HDAP Discover REQ 2. HDAP Discover RSP Cluster member...

  • Page 60: Cluster Member

    "Set Address" request. The hardware address uniquely identifies the sender of this response. After the processes are done, the cluster master will be able to manage the All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes Cluster member...
  • Page 61 Cluster Manager. In the middle of this page, there is a table shows all the clustering candidates which can be selected and added as the clustering members. Step 2: All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 62 ES-2108 Series Switch Support Notes Select a device in the Clustering Candidate table and enter the password which is the admin password for the candidate device to add the clustering member. Step 3: All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 63 Click on the index number to manage the selected clustering member. Step 4: In “Member Menu” pages, you can change any setting of the clustering member, except Cluster Management, Firmware Upgrade and Restore Configuration. Step 5: All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 64 Enter “Management”->”Cluster Management”->”Clustering Management Status:” In “Clustering Management Status” pages, you can check the status for each member. Step 6: Enter “Management”->”Cluster Management”->”Clustering Management Configuration:” In “Clustering Management Configuration” pages , by All contents copyright (c) 2006 ZyXEL Communications Corporation.
  • Page 65 Connect the male 9-pin end of the console cable to the console port of the Switch. Connect the female end to a serial port (COM1, COM2 or other COM port) of your computer, which has terminal emulation software configured to...
  • Page 66 How to access the Command Line Interface? There are two ways to access the Command Line Interface. One is “Telnet to the switch” and another is “Connect a computer to the console port and use the terminal emulation software.” Please check “How to access the Switch through the console port?”...
  • Page 67 Connect the console cable to your computer and open the terminal emulation software. Power off and then power on the Switch, and press any key to enter the debug mode when the screen shows “Press any key to enter Debug Mode within 3 seconds.”...
  • Page 68 How to restart device from Web? Click Management and then Maintenance in the navigation panel to display the following screen. All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 69 What fiber cable can I use for the 100FX port? You can use the regular LC/LC fiber cable (62.5/125MM) for the 100FX Port. How far does the 100FX port support in Kilometer? All contents copyright (c) 2006 ZyXEL Communications Corporation. ES-2108 Series Switch Support Notes...
  • Page 70 When I enabled Port Isolated mode, what is the uplink port on ES-2108-LC? Both the Mini-GB (SFP) Port and the 100FX Port are the uplink ports when the Switch is in Port Isolated Mode. Each isolated port can communicate with the uplink port(s). All contents copyright (c) 2006 ZyXEL Communications Corporation.
