ATTE APT-3-11 Instruction Manual

APT-3-11
Switch PoE 3 ports – LAN +PoE extender
10/100Mbps 1xPoE IN 802.3at/af + 2xPoE OUT 802.3at/af
INSTRUCTION MANUAL
APT-3-11 is an unmanaged PoE network switch working as an extender (repeater) of the LAN network
and PoE power supply. Most often used as an "active splitter" in situations when we need to run
several network devices (e.g. several IP cameras) on one UTP cable or when an additional network
branch is necessary.
It is designed to work with any network devices, IP cameras and other devices powered by the PoE
802.3 at/af standard.
The APT (Atte Power Tree) series devices provide compatibility with the IEEE 802.3 at/af standards as
PoE power receivers and IEEE 802.3 at/af on all output ports. After connecting the device to ports 2-3,
the receiver is identified and, if it is a PoE-powered device, power will be turned on in the port.
The device has a very small size, which allows for easy installation in small spaces.
The APT (Atte Power Tree) product series allows you to connect system elements in a tree topology.
APT devices can be powered directly from PoE. Power transmitted over a single UTP cable allows you
to power several IP cameras.
General view of the device
