Rockwell RCV288ACx Command Reference Manual

At commands
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AT Commands for
RCV56ACx, RCV336ACx,
RCV288ACx, and RCV144ACx Modems
Reference Manual
(Preliminary)
Order No. 1048
Rev. 4, February 20, 1997

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCV288ACx and is the answer not in the manual?

Questions and answers

Related Manuals for Rockwell RCV288ACx

Summary of Contents for Rockwell RCV288ACx

  • Page 1 AT Commands for RCV56ACx, RCV336ACx, RCV288ACx, and RCV144ACx Modems Reference Manual (Preliminary) Rev. 4, February 20, 1997 Order No. 1048...
  • Page 2 AT Command Reference Manual NOTICE I n f o r m a t i o n f u r n i s h e d b y R o c k w e l l I n t e r n a t i o n a l C o r p o r a t i o n i s b e l i e v e d t o b e a c c u r a t e a n d r e l i a b l e . H o w e v e r , n o r e s p o n s i b i l i t y i s a s s u m e d b y R o c k w e l l I n t e r n a t i o n a l f o r i t s u s e , n o r a n y i n f r i n g e m e n t o f p a t e n t s o r o t h e r r i g h t s o f t h i r d p a r t i e s w h i c h m a y r e s u l t f r o m i t s u s e .
  • Page 3 This manual supersedes the following manuals: AT Command Reference Manual for the RC288ACi and RC288ACL Modem Families (Order No. 1048, Rev.3, January 9, 1996). Addendum 1 to AT Commands for RC288ACx and RC144ACx Modem Families (Order No. 1048R3A1, Rev.1, August 2, 1996).
  • Page 4 AT Command Reference Manual This page is intentionally blank. 1048...

  • Page 5: Table Of Contents

    1. INTRODUCTION ...1-1 1.1 OVERVIEW ...1-1 1.1.1 Command Syntax ..1-1 1.1.2 Command Descriptions...1-1 1.1.3 Call Progress and Blacklisting Parameters ...1-2 1.1.4 ConfigurACE II for Windows Utility Program..1-2 1.2 REFERENCE DOCUMENTATION ...1-2 2. COMMAND SYNTAX ...2-1 2.1 DTE/DCE INTERCHANGE CIRCUITS...2-1 2.2 COMMAND SYNTAX AND GUIDELINES...2-1 2.2.1 DTE Commands ...2-1 2.2.2 DTE Command Lines...
  • Page 6 &Jn - Telephone Jack Control... 3-15 &Kn - Flow Control ...3-15 &Ln - Leased Line Operation ... 3-15 &Mn - Asynchronous/Synchronous Mode Selection ... 3-16 &Pn - Select Pulse Dial Make/Break Ratio ... 3-16 &Qn - Sync/Async Mode..3-17 &Rn - RTS/CTS Option... 3-18 &Sn - DSR Override ...
  • Page 7 Example of Formatted Form Reporting ..3-37 Unformatted Form Reporting ...3-37 Example of Unformatted Form Reporting ..3-37 3.7 CELLULAR COMMANDS...3-38 3.7.1 Cellular Phone Drivers ... 3-38 3.7.2 Cellular Commands ... 3-38 ^C2 - Download Cellular Phone Driver ... 3-38 ^I - Identify Cellular Phone Driver...
  • Page 8 CONNECT 26400 (63)... 3-45 CONNECT 28800 (64)... 3-46 COMPRESSION: CLASS 5 (66) ... 3-46 COMPRESSION: V.42 bis (67) ... 3-46 COMPRESSION: NONE (69) ... 3-46 PROTOCOL: NONE (70) ...3-46 PROTOCOL: LAPM (77) ...3-46 CARRIER 31200 (78) ... 3-46 CARRIER 33600 (79) ... 3-46 PROTOCOL: ALT (80)...3-46 PROTOCOL: ALT-CELLULAR (81)...
  • Page 9 S0 - Number of Rings to Auto-Answer ..4-4 S1 - Ring Counter...4-4 S2 - Escape Character ..4-4 S3 - Carriage Return Character ...4-4 S4 - Line Feed Character...4-4 S5 - Backspace Character ...4-4 S6 - Wait Time for Dial Tone Before Blind Dialing, or After “W” Dial Modifier (W-Class Models)...4-5 S7 - Wait Time For Carrier After Dial, For Silence, or For Dial Tone After “W”...
  • Page 10 5.1.9 Fax Data Reception ...5-3 5.2 COMMANDS ...5-4 +FCLASS=n - Select Service Class ...5-4 +F<command>? - Report Active Configuration...5-4 +F<command>=? - Report Operating Capabilities...5-4 +FAE=n - Data/Fax Auto Answer ...5-4 +FTS=n - Stop Transmission and Wait...5-4 +FRS=n - Receive Silence ...5-4 +FTM=n - Transmit Data ...
  • Page 11 6.4.1 +FCON, Facsimile Connection Response ... 6-13 6.4.2 +FDCS:, Report Current Session Capabilities ... 6-13 6.4.3 +FDIS:, Report Remote Station Capabilities... 6-13 6.4.4 +FCFR, Indicate Confirmation to Receive ... 6-13 6.4.5 +FTSI:, Report the Transmit Station ID ...6-13 6.4.6 +FCSI:, Report the Called Station ID...6-13 6.4.7 +FPTS:, Receive Page Transfer Status...6-14 6.4.8 +FET:, Post Page Message Response...
  • Page 12 Voice to Data...7-9 Unsuccessful Data Connection Attempt to Voice...7-9 7.2.10 Caller ID ...7-9 7.3 AT VOICE COMMAND SUMMARY... 7-10 7.3.1 Global AT Command Set Extensions ... 7-10 ATA - Answering in Voice/Audio... 7-11 ATD - Dial Command in Voice/Audio... 7-11 ATH - Hang Up in Voice/Audio ...
  • Page 13 8.4 W-CLASS COMMANDS...8-5 8.5 CALLER ID COMMANDS ...8-5 8.6 FAX CLASS 1 ...8-5 8.7 FAX CLASS 2 ...8-6 8.8 VOICE/AUDIO COMMANDS...8-7 8.9 CELLULAR COMMANDS...8-7 8.10 AUDIOSPAN AND DSVD COMMANDS ...8-7 8.11 SYNCHRONOUS ACCESS MODE COMMANDS ...8-7 9. COMMON CONFIGURATION SETUP STRINGS ...9-1 1048 AT Command Reference Manual xiii...
  • Page 14 AT Command Reference Manual List of Tables Table 3-1. Result Codes ...3-11 Table 3-2. Remote Modem Configuration and Resulting Transmit Levels ... 3-41 Table 4-1. S-Register Summary...4-2 Table 5-1. Fax Class 1 Commands ...5-1 Table 5-2. Fax Class 1 Calling Sequence (One Page)...5-7 Table 5-3.

  • Page 15: Introduction

    1.1 OVERVIEW This manual describes the AT commands for the following Rockwell modem families: RC56ACi RCV56ACFL/SP RCV56ACF/SP RCV56ACF/SVD RC336ACi RC336ACL RC336ACFL/SP RCV336ACi/SP RCV336ACF/SP RCV336ACF/SVD RC288ACi RC288ACL RC288ACLW-GSM RCV288ACi/SP RC144ACi and RC144ATi RC144ACL and RC144ATL RC144ACG RC144ACF/ATF RC144ACFL/ATFL RCV144ACi/SP RCV144ACF/SP The descriptions apply to all these modems with any differences between modem product families noted. Refer to Modem Firmware Release notes for commands applicable to modem firmware.

  • Page 16: Call Progress And Blacklisting Parameters

    1.1.3 Call Progress and Blacklisting Parameters The modem MCU firmware may be provided either in reconfigurable form or preconfigured form. Consult the specific firmware release notes for exact configuration information. Reconfigurable Form. The modem MCU firmware can be configured for operation in specific countries by the PC- compatible ConfigurACE II program.

  • Page 17: Command Syntax

    AT Command Reference Manual 2. COMMAND SYNTAX 2.1 DTE/DCE INTERCHANGE CIRCUITS Communication between the DTE and modem is half duplex (i.e., only one entity 'talks' at a time). 2.2 COMMAND SYNTAX AND GUIDELINES 2.2.1 DTE Commands The ISO 646 character set (CCITT T.50 International Alphabet 5, American Standard Code for Information Interchange) is used for the issuance of commands and responses.
  • Page 18 AT Command Reference Manual This page is intentionally blank. 1048...

  • Page 19: At Command Set

    AT Command Reference Manual 3. AT COMMAND SET 3.1 AT COMMAND GUIDELINES The basic AT commands used to control modem operation are defined in this section. These commands are summarized in Appendix A. All these commands may not be available in a specific product depending upon supported data rates and modes.

  • Page 20: At Command Set

    3.2 AT COMMAND SET The modem will respond to the commands detailed below. Parameters applicable to each command are listed with the command description. The defaults shown for each configuration command are those used in the Rockwell factory profile 0. 3.2.1 AT Commands A/ - Re-execute Command The modem behaves as though the last command line had been re-sent by the DTE.

  • Page 21: Cn - Carrier Control

    Cn - Carrier Control This command is included for compatibility only, and has no effect other than returning a result code. The only valid parameter is 1. Result Codes: n = 1. ERROR Otherwise. Dn - Dial This command directs the modem to go on-line, dial according to the string entered and attempt to establish a connection. If no dial string is supplied, the modem will go on-line and attempt the handshake in originate mode.

  • Page 22: En - Command Echo

    Wait for silence: the modem will wait for at least 5 seconds of silence in the call progress frequency band before continuing with the next dial string parameter. If the modem does not detect these 5 seconds of silence before the expiration of the call abort timer (S7), the modem will terminate the call attempt with a NO ANSWER message.

  • Page 23: Fn - Select Line Modulation (Rc144 Models Only)

    Fn - Select Line Modulation (RC144 Models Only) This command selects the line modulation according to the parameter supplied. The line modulation is fixed unless Automode is selected. This command interacts with the S37 and the N command. The parameter value, if valid, is written to S37 bits 0-4.

  • Page 24: Hn - Disconnect (Hang-Up)

    Hn - Disconnect (Hang-Up) This command initiates a hang up sequence. This command may not be available for some countries due to PTT restrictions. The modem will release the line if the modem is currently on-line, and will terminate any test (AT&T) that is in progress.

  • Page 25: Mn - Speaker Control

    Mn - Speaker Control This command selects when the speaker will be on or off. The parameter value, if valid, is written to S22 bits 2 and 3. Speaker is always off. Speaker is on during call establishment, but off when receiving carrier. (Default.) Speaker is always on.

  • Page 26: P - Set Pulse Dial Default

    P - Set Pulse Dial Default This command forces pulse dialing until the next T dial modifier or T command is received. Sets S14 bit 5. As soon as a dial command is executed which explicitly specifies the dialing mode for that particular call (e.g., ATDT...), this command is overridden so that all future dialing will be tone dialed.

  • Page 27: T - Set Tone Dial Default

    T - Set Tone Dial Default This command forces DTMF dialing until the next P dial modifier or P command is received. The modem will set an S- Register bit to indicate that all subsequent dialing should be conducted in tone mode. Note that the DP command will override this command.

  • Page 28: Xn - Extended Result Codes

    Xn - Extended Result Codes This command selects which subset of the result messages will be used by the modem to inform the DTE of the results of commands. Blind dialing is enabled or disabled by country parameters. If the user wishes to enforce dial tone detection, a "W" can be placed in the dial string (see D command).

  • Page 29: Table 3-1. Result Codes

    Short Form CONNECT RING NO CARRIER ERROR CONNECT 1200 NO DIALTONE BUSY NO ANSWER CONNECT 0600 CONNECT 2400 CONNECT 4800 CONNECT 9600 CONNECT 7200 CONNECT 12000 CONNECT 14400 CONNECT 19200 CONNECT 38400 CONNECT 57600 CONNECT 115200 CONNECT 230400 CONNECT 75TX/1200RX CONNECT 1200TX/75RX DELAYED BLACKLISTED...
  • Page 30 Short Form CONNECT 26400 CONNECT 28800 COMPRESSION: CLASS 5 COMPRESSION: V.42 bis COMPRESSION: NONE PROTOCOL: NONE PROTOCOL: LAPM CARRIER 31200 CARRIER 33600 PROTOCOL: ALT PROTOCOL: ALT-CELLULAR CONNECT 33600 CONNECT 31200 CARRIER 32000 CARRIER 34000 CARRIER 36000 CARRIER 38000 CARRIER 40000 CARRIER 42000 CARRIER 44000 CARRIER 46000...

  • Page 31: Yn - Long Space Disconnect

    Yn - Long Space Disconnect This command enables/disables the generation and response to long space disconnect. The parameter value, if valid, is written to S21 bit 7. Disables long space disconnect. (default.) Enables long space disconnect. In non-error correction mode, the modem will send a long space of four seconds prior to going on-hook.

  • Page 32: At& Commands

    3.2.2 AT& Commands &Cn - RLSD (DCD) Option The modem controls the RLSD output in accordance with the parameter supplied. The parameter value, if valid, is written to S21 bit 5. &C0 RLSD remains ON at all times. &C1 RLSD follows the state of the carrier. (Default.) Result Codes: n = 0 or 1.

  • Page 33: Gn - Select Guard Tone

    &Gn - Select Guard Tone The modem generates the guard tone selected by this command according to the parameter supplied (DPSK modulation modes only). The parameter value, if valid, is written to S23 bits 6 and 7. &G0 Disables guard tone. (Default for US models.) &G1 Disables guard tone.

  • Page 34: Mn - Asynchronous/Synchronous Mode Selection

    &Mn - Asynchronous/Synchronous Mode Selection This command determines the DTR operating mode. The modem treats the &M command as a subset of the &Q command. &M0 Selects direct asynchronous operation. Note that the command sequence &M0\N0 selects normal buffered mode, but the command sequence \N0&M0 selects direct mode. This is because the \N0 command is analogous to the &Q6 command.

  • Page 35: Qn - Sync/Async Mode

    &Qn - Sync/Async Mode This command is an extension of the &M command and is used to control the connection modes permitted. It is used in conjunction with S36 and S48. (Also, see \N.) NOTE: When the &Q0 to &Q4 command is issued to select the mode, the subsequent connect message will report the DCE speed regardless of the W command and S95 settings.

  • Page 36: Rn - Rts/Cts Option

    &Rn - RTS/CTS Option This selects how the modem controls CTS. CTS operation is modified if hardware flow control is selected (see &K command). The parameter value, if valid, is written to S21 bit 2. &R0 In sync mode, CTS tracks the state of RTS; the RTS-to-CTS delay is defined by S26. In async mode, CTS is normally ON and will turn OFF only if required by flow control.

  • Page 37: Display Current Configuration And Stored Profiles

    &V - Display Current Configuration and Stored Profiles Reports the current (active) configuration, the stored (user) profiles, and the first four stored telephone numbers. The stored profiles and telephone numbers are not displayed if the NVRAM is not installed or is not operational as detected by the NVRAM test during reset processing.

  • Page 38: Wn - Store Current Configuration

    &Wn - Store Current Configuration Saves the current (active) configuration (profile), including S-Registers, in one of the two user profiles in NVRAM as denoted by the parameter value. This command will yield an ERROR message if the NVRAM is not installed or is not operational as detected by the NVRAM test.

  • Page 39: At% Commands

    3.2.4 AT% Commands %En - Enable/Disable Line Quality Monitor and Auto-Retrain or Fallback/Fall Forward Controls whether or not the modem will automatically monitor the line quality and request a retrain (%E1) or fall back when line quality is insufficient or fall forward when line quality is sufficient (%E2). The parameter value, if valid, is written to S41 bits 2 and 6.

  • Page 40: Plug And Play Serial Number

    %7 - Plug and Play Serial Number %7<8 hex numbers><same 8 hex numbers><cr> - Sets Plug and Play Serial Number Sets and stores eight serial numbers in hex format used for serial Plug and Play and for ISA Plug and Play which use the Rockwell 11575 Plug and Play device.

  • Page 41: At\ Commands

    3.2.5 AT\ Commands \Kn - Break Control Controls the response of the modem to a break received from the DTE or the remote modem or the \B command according to the parameter supplied. The parameter value, if valid, is written to S40 bits 3, 4, and 5. The response is different in three separate states.

  • Page 42: Nn - Operating Mode

    \Nn - Operating Mode This command controls the preferred error correcting mode to be negotiated in a subsequent data connection. This command is affected by the OEM firmware configuration. Selects normal speed buffered mode (disables error-correction mode). (Forces &Q6.) Serial interface selected - Selects direct mode and is equivalent to &M0, &Q0 mode of operation. (Forces &Q0.) Parallel interface selected - Same as \N0.

  • Page 43: At+ Commands

    Voice and Data = Blank for Data mode only. “SVD” for AudioSpan analog simultaneous audio/voice and data. “DSVD” for G.729A or DigiTalk digital simultaneous voice and data. 3.2.6 AT+ Commands +MS - Select Modulation This extended-format command selects the modulation and, optionally, enables or disables automode, specifies the lowest and highest connection rates, selects -Law or A-Law codec type, and enables or disables robbed bit signaling generation (server modem) or detection (client modem) using one to five subparameters.
  • Page 44 Subparameter Definitions <mod> = A decimal number which specifies the preferred modulation (automode enabled) or the modulation (automode disabled) to use in originating or answering a connection. The options are: <mod> Modulation V.21 V.22 V.22 bis V.23 V.32 V.32 bis V.34 K56flex Bell 103...
  • Page 45 To emulate issuance of the N0S37=x command sequence to select fixed mode operation, specify the <max_rate> and <min_rate> both to be the (same) requested speed, and <mod> to be the modulation for that speed. For example: +MS=11,0,16800,16800 selects V.34 16800 bps fixed mode (no comparable S37 command). +MS=10,0,12000,12000 selects V.32 bis 12000 bps fixed mode (same as N0S37=10).

  • Page 46: Hn - Enable/Disable Rpi And Dte Speed

    +Hn - Enable/Disable RPI and DTE Speed This command enables or disables Rockwell Protocol Interface (RPI) processing and sets the DTE speed. (Applicable only to modems supporting RPI and RPI+). Disable protocol interface and video ready mode. Enable RPI mode and set DTE speed to 19200 bps. Enable RPI mode and set DTE speed to 38400 bps.

  • Page 47: At** Command

    3.2.7 AT** Command ** - Download to Flash Memory The linear flash memory downloader in the modem firmware allows flash memory connected to the modem external memory bus to be upgraded with revised modem firmware. This process transfers (uploads) the upgraded modem firmware (data) from the host computer to the modem which transfers (downloads) the data to the flash memory device.

  • Page 48: At- Commands

    3.2.8 AT- Commands -SDR=n - Enable/Disable Distinctive Ring This command enables or disables detection and reporting of distinctive ring. The syntax is AT-SDR=n, where n is a number from 0 to 7. One, two, or three distinctive ring types can be simultaneously enabled depending upon the value of n (bit mapped).

  • Page 49: Error Detection And Data Compression Commands

    3.3 ERROR DETECTION AND DATA COMPRESSION COMMANDS 3.3.1 AT% Commands %C - Enable/Disable Data Compression Enables or disables data compression negotiation. The modem can only perform data compression on an error corrected link. The parameter value, if valid, is written to S41 bits 0 and 1. Disables data compression.

  • Page 50: Mnp 10 Commands

    3.4 MNP 10 COMMANDS 3.4.1 AT) Commands )Mn - Enable Cellular Power Level Adjustment This command is included only for compatibility and performs no function. )M0 command. )M1 command. )M2 command. Result Codes: n = 0 to 2. ERROR Otherwise. *Hn - Link Negotiation Speed This command is included only for compatibility and performs no function.

  • Page 51: Sec=N - Enable/Disable Mnp10-Ec

    -SEC=n - Enable/Disable MNP10-EC Enables or disables MNP10-EC operation. The command format is: -SEC=n,[<tx level>] -SEC=0 -SEC=1,[<tx level>] Result Codes: n=0, 1, or 1 and <tx level>=0 to 30 ERROR Otherwise Example: AT-SEC=1,18 enables MNP10-EC and sets the transmit level to -18 dBm. Note: If AT-SEC=0, the modem will automatically set AT-SEC=1 if the remote modem indicates Cellular in the V.8 bis/V.8 phase or if a Cellular Driver is loaded and the Cell Phone is attached.

  • Page 52: W-Class Commands

    3.5 W-CLASS COMMANDS 3.5.1 AT* Commands *B - Display Blacklisted Numbers This command requests the modem to return a list of blacklisted numbers to the DTE. The format of the response is shown by the example below. Permanently forbidden numbers as defined by country requirements will not appear on this list. If no numbers are blacklisted, only the OK result code is issued.

  • Page 53: Ncn - Country Select

    *NCn - Country Select Up to four sets of country parameters may be stored in the EPROM. This command checks to see if the entered number matches the country code of one of the countries stored in the EPROM. If found, the modem stores the location of that country in NVRAM.

  • Page 54: Caller Id Commands

    3.6 CALLER ID COMMANDS 3.6.1 AT#CID Command #CIDn - Caller ID Enables or disables Caller ID. #CID=0 Disables Caller ID. (Default.) #CID=1 Enables Caller ID with formatted presentation to the DTE. The modem will present the data items in a <Tag><Value> pair format. The expected pairs are data, time, caller code (telephone number), and name.

  • Page 55: Example Of Formatted Form Reporting

    Example of Formatted Form Reporting The following example illustrates the standard Caller ID message packet. RING DATE TIME NMBR NAME RING RING The following example illustrates the case where the tag of the packet is not recognized by the modem. RING MESG RING...

  • Page 56: Cellular Commands

    3.7 CELLULAR COMMANDS The Direct Connect Modem allows a direct interface to most cellular telephones eliminating the need for other intelligent interfaces. Landline modems operate with the telephone system by either going off hook detecting dialtone and the dialing the telephone number using pulses or DTMF digits, or detecting the RING signal and answering the call.

  • Page 57: T6 - Indicate Status Of Cellular Phone

    ^T6 - Indicate Status of Cellular Phone The status of the cellular phone connected to the modem is reported in response to the ^T6 command. The status is reported in a single byte formatted as a decimal number. The individual status signals assigned to the status byte bits are: bit 0 Cellular phone is receiving an incoming call bit 1...

  • Page 58: Fax Configuration

    AT Command Reference Manual In V.34 modems if MNP10-EC is enabled manually (using AT-SEC=1) no particular modulation will be chosen, therefore if the user wishes to force V.32bis modulation they should use the AT+MS=10,1,minspeed,maxspeed command (e.g. AT+MS=10,1,4800,12000 would force V.32bis and limit the speed between 4800 and 12000 bps). To allow V.34 modulation use AT+MS=11,1,minspeed,maxspeed (e.g.

  • Page 59: Table 3-2. Remote Modem Configuration And Resulting Transmit Levels

    Table 3-2. Remote Modem Configuration and Resulting Transmit Levels Remote Modem Configuration V.34 AT&F Mod = V.32bis Direct Mode = -EC Connect RTxlv = Driver BTxlv = x AT&F-SEC=1,x Mod = V.34 Mode = -EC RTxlv = x BTxlv = x V.32bis AT&F Mod = V.32bis...

  • Page 60: At Command Result Codes

    3.8 AT COMMAND RESULT CODES The modem responds to commands from the DTE and to activity on the line by signalling to the DTE in the form of result codes. The result codes that the modem can send are described below. Two forms of each result code are available: long-form, an English-like "verbose"...

  • Page 61: Busy (7)

    BUSY (7) For X3 and X4, if busy tone detection is enforced, the modem sends this result code when attempting to originate a call if the busy (engaged) signal is detected on the line. NO ANSWER (8) The modem sends this result code when attempting to originate a call if a continuous ringback signal is detected on the line until the expiration of the timer S7.

  • Page 62: Connect 38400 (17)

    AT Command Reference Manual The DTE speed is 19200 bps and the modem has been instructed to report the DTE speed to the DTE upon connecting. CONNECT 38400 (17) For X1, X2, X3, and X4, the modem sends this result code upon connecting when the DTE speed is 38400 bps and the modem has been instructed to report the DTE speed to the DTE upon connecting.

  • Page 63: Carrier 7200 (49)

    AT Command Reference Manual CARRIER 7200 (49) The modem sends this result code when a 7200 bps data rate has been detected on the line and carrier reporting has been enabled. (See S95 and Xn.) CARRIER 9600 (50) The modem sends this result code when a 9600 bps data rate has been detected on the line and carrier reporting has been enabled.

  • Page 64: Connect 28800 (64)

    AT Command Reference Manual CONNECT 28800 (64) For X1, X2, X3, and X4, the modem returns this result code upon connecting when the DTE speed is 28800 bps and the modem has been instructed to report the DTE speed upon connecting. COMPRESSION: CLASS 5 (66) This message is sent to the DTE when the modem has connected in MNP Class 5 and COMPRESSION message reporting has been enabled.

  • Page 65: Carrier 36000 (152)

    AT Command Reference Manual CARRIER 36000 (152) The modem sends this result code when a 36000 bps data rate has been detected on the line and carrier reporting has been enabled. (See S95 and Xn.) CARRIER 38000 (153) The modem sends this result code when a 38000 bps data rate has been detected on the line and carrier reporting has been enabled.

  • Page 66: Connect 38000 (168)

    AT Command Reference Manual CONNECT 38000 (168) For X1, X2, X3, and X4, the modem returns this result code upon connecting when the DTE speed is 38000 bps and the modem has been instructed to report the DTE speed upon connecting. CONNECT 40000 (169) For X1, X2, X3, and X4, the modem returns this result code upon connecting when the DTE speed is 40000 bps and the modem has been instructed to report the DTE speed upon connecting.

  • Page 67: Audiospan And Dsvd Commands

    3.9 AUDIOSPAN AND DSVD COMMANDS AudioSpan and DSVD are two technologies that allow simultaneous voice and data operation using a Rockwell modem connected to a telephone line. AudioSpan and DSVD implementations differ in the manner that voice and modem data are combined.

  • Page 68: Vls = X - Voice Line Select

    Notes AudioSpan audio quality is dependent upon modulation mode, data rate and telephone line quality. Some guidelines are: Higher quality telephone lines provide better audio quality than impaired telephone lines. A lower data speed with audio provides better audio quality than higher data speed with audio. For example, a ML288/9600 connection will be audibly superior to a ML288/14400 connection.

  • Page 69: Commands Supported Only By Audiospan

    3.9.3 Commands Supported Only by AudioSpan The following commands are applicable only for modems supporting AudioSpan mode. The command has no effect in DSVD mode. Modems that supports DSVD but not AudioSpan will report ERROR in response to these commands. -SQS= x, y - Select AudioSpan Modulation x: Select modulation mode V.61...
  • Page 70 (0,1,2),(0,1) -SMC= x - Enable/Disable ML144 Data Burst Disable data burst Enable data burst ML144 data burst can be enabled using the -SMC command in ML144 modulation. Data burst will keep the audio channel open only when energy is detected on the handset or headset. When silence is detected in data burst mode, the connected modems will upshift in speed for higher throughput.

  • Page 71: Examples

    3.9.4 Examples Example 1: Establish a AudioSpan data connection between two RCV288 modems and use handset as audio interface. Both DTEs are set at 57600 bps: Originate Modem AT&F AT-SMS=2 ATDTxxxx CONNECT 57600 <data> NO CARRIER 1048 AT Command Reference Manual Answer Modem AT&F AT-SMS=2...
  • Page 72 Example 2: Switch from normal handset conversation to AudioSpan data connection between two RCV288 modems. The originate DTE is set to 57600 bps and the answer DTE is set to 115200 bps: Originate Modem AT&F AT-SMS=2 CONNECT 57600 <data> NO CARRIER Note: The transition from handset conversation to AudioSpan mode can take up to 8 seconds.
  • Page 73 Example 3: Switch from normal handset conversation to AudioSpan data connection between two RCV288 modems in normal (non-error corrected) mode. Headset operation will be selected on the originate modem and speakerphone operation will be selected on the answer modem as the audio interface during AudioSpan connection. The originate DTE prefers a ML288/14400 connection for good audio quality and does not require high throughput.
  • Page 74 Example 4: Establish a ML144/7200 data connection between two RCV288 modems in headset mode, then switch to handset later in the session so conversation can continue after modem call is hung up. This may be typical for configuring an interactive gaming software. Both DTEs are set at 38400 bps: Originate Modem AT&F AT-SQS=1...
  • Page 75 Example 5: Originate modem places speakerphone call to remote handset which is connected to the answer modem. The originate modem switches from speakerphone mode to establish a AudioSpan/Speakerphone data connection between two RCV288 modems. The originate DTE is set to 57600 bps and the answer DTE is set to 115200 bps: Originate Modem AT&F#CLS=8 #VLS=6#VRN=0...

  • Page 76: Synchronous Access Mode

    3.10 SYNCHRONOUS ACCESS MODE 3.10.1 Synchronous Access Mode Commands Three commands support Synchronous Access Mode: Enables and disables Synchronous Access Mode in the client or central site modem +ESA Configures the operation of the Synchronous Access Submode + ITF Selects Transmit Flow Control Thresholds Enabling Synchronous Access Mode enables the use of the 8-bit command characters defined in Table 9/V.80 of the Draft ITU-T Recommendation V.80 (DATA COMMUNICATION OVER THE TELEPHONE NETWORK;...

  • Page 77: Esa - Configure Synchronous Access Submode

    Reporting Selected Options The modem reports the selected options in response to the following command: +ES? The response is: +ES: <orig_rqst>,<orig_fbk>,<ans_fbk> Example: +ES? +ES: 3,0,2 For the defaults. +ES: 6,0,8 Synchronous Access Mode originator and answerer enabled (client modem only) +ES: 7,0,9 Frame Tunneling Mode originator and answerer enabled (central site modem only) Reporting Supported Options...
  • Page 78 <crc_type> Specifies the CRC polynomial used while operating in Framed sub-Mode. The options are: <nrzi_en> Specifies if Non Return to Zero Inverted (NRZI) encoding is to be used by the modem for transmit and receive data. The options are: <syn1>, <syn2> Specifies the octet value(s) to be used while performing character-oriented framing. <syn1> is to be commanded to 255 (FFh);...

  • Page 79: Itf - Transmit Flow Control Thresholds

    + ITF - Transmit Flow Control Thresholds The +ITF command determines the flow control thresholds used by the modem for transmit data from the DTE. The command format is: +ITF=[<off>[,<on>[,<report_period>]]] This optional compound parameter allows the DTE to determine the input buffer size in the modem for data on circuit 103 (transmit data) from the DTE, to control the threshholds used for flow control of such data, and to control how often the modem reports to the DTE the number of octets in this buffer.
  • Page 80 AT Command Reference Manual This page is intentionally blank. 3-62 1048...

  • Page 81: S-Registers

    AT Command Reference Manual 4. S-REGISTERS The S-Registers are summarized in Table 4-1 along with their default values; registers denoted with an '*' may be stored in one of the two user profiles by entering the &Wn command. One of these profiles may be loaded at any time by using the Zn command.

  • Page 82: Table 4-1. S-Register Summary

    Register Function Rings to Auto-Answer Ring Counter Escape Character Carriage Return Character Line Feed Character Backspace Character Wait Time for Dial Tone Wait Time for Carrier Pause Time for Dial Delay Modifier Carrier Detect Response Time Carrier Loss Disconnect Time DTMF Tone Duration Escape Prompt Delay Reserved...
  • Page 83 Register Function General Bit-Mapped Options Status General Bit-Mapped Options Status S42-S45 Reserved Data Compression Control V.42 Negotiation Control LAPM Break Control Call Failure Reason Code PSTN Transmit Attenuation Level Fax Transmit Attenuation Level Result Code Messages Control * Register value may be stored in one of two user profiles with the &W command. ** Default values may be modified using ConfigurACE.

  • Page 84: S-Register Definitions

    4.2 S-REGISTER DEFINITIONS S0 - Number of Rings to Auto-Answer Sets the number of the rings required before the modem automatically answers a call. Setting this register to zero disables auto-answer mode. Range: 0-255 rings Default: 0 S1 - Ring Counter S1 is incremented each time the modem detects a ring signal on the telephone line.

  • Page 85: S6 - Wait Time For Dial Tone Before Blind Dialing, Or After "W" Dial Modifier (W-Class Models)

    S6 - Wait Time for Dial Tone Before Blind Dialing, or After “W” Dial Modifier (W-Class Models) Sets the length of time, in seconds, that the modem will wait before starting to dial after going off-hook when blind dialing. This operation, however, may be affected by some ATX options according to country restrictions. The “Wait for Dial Tone”...

  • Page 86: S12 - Escape Prompt Delay (Epd)

    S12 - Escape Prompt Delay (EPD) Defines the maximum period, in fiftieths of a second, allowed between receipt of the last character of the three escape character sequence from the DTE and sending of the OK result code to the DTE. If any characters are detected during this time, the OK will not be sent.

  • Page 87: S16 - General Bit Mapped Test Options Status

    S16 - General Bit Mapped Test Options Status Indicates the test in progress status. Default: 0 Bit 0 Local analog loopback Bit 1 Not used Bit 2 Local digital loopback Bit 3 Remote digital loopback (RDL) status Bit 4 RDL requested (AT&T6) Bit 5 RDL with self test Bit 6...

  • Page 88: S19 - Autosync Bit Mapped Options

    S19 - AutoSync Bit Mapped Options Defines the options for AutoSync operation (see &Q4 command). S19 must be set to the desired value before &Q4 is issued. Default: 0 Bit 0 Reserved Bit 1 BSC/HDLC format select Bit 2 Address detection enable/disable Bit 3 NRZI/NZI coding select Bit 4...

  • Page 89: S21 - V.24/General Bit Mapped Options Status

    S21 - V.24/General Bit Mapped Options Status Indicates the status of command options. Default: 52 (34h) (00110100b) Bit 0 Set by &Jn command but ignored otherwise. Bit 1 Reserved Bit 2 CTS behavior (&Rn) Bits 3-4 DTR behavior (&Dn) Bit 5 RLSD (DCD) behavior (&Cn) Bit 6 DSR behavior (&Sn)

  • Page 90: S22 - Speaker/Results Bit Mapped Options Status

    S22 - Speaker/Results Bit Mapped Options Status Indicates the status of command options. Default: 117 (75h) (01110101b) Bits 0-1 Speaker volume (Ln) Bits 2-3 Speaker control (Mn) Bits 4-6 Limit result codes (Xn) Bit 7 Reserved 4-10 AT Command Reference Manual Off (L0) Low (L1) (Default.) Medium (L2)

  • Page 91: S23 - General Bit Mapped Options Status

    S23 - General Bit Mapped Options Status Indicates the status of command options. Default: 62 (3Dh) (00111110b) Bit 0 Grant RDL Bits 1-3 DTE Rate Bits 4-5 Assumed DTE parity Bits 6-7 Guard tone (&Gn) S24 - Sleep Inactivity Timer Sets the length of time, in seconds, that the modem will operate in normal mode with no detected telephone line or DTE line activity before entering low-power sleep mode.

  • Page 92: S27 - Bit Mapped Options Status

    S27 - Bit Mapped Options Status Indicates the status of command options. Default: 73 (49h) (01001001b) Bits 0,1,3 Synchronous/asynchronous selection (&Mn/&Qn) Bit 2 Leased line control (&Ln) Bits 4 - 5 Internal clock select (&Xn) Bit 6 CCITT/Bell mode select (Bn) Bit 7 - Reserved 4-12 AT Command Reference Manual...

  • Page 93: S28 - Bit Mapped Options Status

    S28 - Bit Mapped Options Status Default: 0 Bits 0 - 1 Reserved Bit 2 Reserved (always 0). Bits 3 - 4 Pulse dialing (&Pn) Bit 5-7 Reserved S29 - Flash Dial Modifier Time Sets the length of time, in units of 10 ms, that the modem will go on-hook when it encounters the flash (!) dial modifier in the dial string.

  • Page 94: S31 - Bit Mapped Options Status

    S31 - Bit Mapped Options Status Default: 194 (C2h) (11000010b) Bit 0 Single line connect message enable/disable (\Vn) Bit 1 Auto line speed detection (Nn) Bits 2-3 Error correction progress messages (Wn) Bits 4-5 Caller ID (#CID) Bits 6-7 Reserved (Default = 11b) S32 - XON Character Sets the value of the XON character.

  • Page 95: S36 - Lapm Failure Control

    S36 - LAPM Failure Control Default: 7 (00000111b) Bits 0-2 This value indicates what should happen upon a LAPM failure. These fallback options are initiated immediately upon connection if S48=128. If an invalid number is entered, the number is accepted into the register, but S36 will act as if the default value has been entered. Bits 3-7 Reserved 1048...

  • Page 96: S37 - Desired Line Connection Speed

    S37 - Desired Line Connection Speed This register specifies the desired line connection speed. Notes: When the Nn command is issued or the S37 register value is modified, the +MS command subparameters are updated to reflect the speed and modulation specified by the S37 value (see +MS command). For example: If N0 command is active, S37=10 updates the +MS command subparameters to reflect +MS=10,1,300,12000 If N1 command is active, S37=10 updates the +MS command subparameters to reflect +MS=10,0,12000,12000 S37 is not updated by the +MS command.

  • Page 97: S38 - Delay Before Forced Hang Up

    S38 - Delay Before Forced Hang Up This register specifies the delay between the modem's receipt of the H command to disconnect (or ON-to-OFF transition of DTR if the modem is programmed to follow the signal), and the disconnect operation. Applicable to error-correction connection only.

  • Page 98: S40 - General Bit Mapped Options Status

    S40 - General Bit Mapped Options Status Indicates the status of command options. Default: 104 (68h) (01101000b) Bits 0-1 MNP Extended Services (-Kn) Bit 2 Reserved Bits 3-5 Break Handling (\Kn) Bits 6-7 MNP block size (\An) 4-18 AT Command Reference Manual Disable extended services (-K0) (Default) Enable extended services (-K1) Enable extended services (-K2)

  • Page 99: S41 - General Bit Mapped Options Status

    S41 - General Bit Mapped Options Status Indicates the status of command options. Default: 195 (C3h) (11000011b) Bits 0 -1 Compression selection (%Cn) Bits 2, 6 Auto retrain and fallback/fall forward (%En) Bit 6 Bit 2 Bit 3 Reserved Bits 4-5 Reserved Bit 7 Reserved...

  • Page 100: S82 - Break Handling Options

    S82 - Break Handling Options S82 is for compatibility purposes only, changing this register will not have any affect. S86 - Call Failure Reason Code When the modem issues a NO CARRIER result code, a value is written to this S-Register to help determine the reason for the failed connection.

  • Page 101: S95 - Extended Result Codes

    S95 - Extended Result Codes The bits in this register can be set to override some of the Wn command options. A bit set to a 1 in this register will enable the corresponding result code regardless of the Wn setting. Also, refer to Table 3-1. Default: 0 Bit 0 CONNECT result code indicates DCE speed instead of DTE speed.
  • Page 102 AT Command Reference Manual This page is intentionally blank. 4-22 1048...

  • Page 103: Fax Class 1 Commands

    5. FAX CLASS 1 COMMANDS 5.1 FAX I/O PROCESSING The fax I/O interface supports asynchronous serial and parallel interfaces. The interface rate is 19200 bps. The character format is 8 bits data, no parity, and 1 stop bit. Start and stop elements are removed from the transmit data and added to the receive data.

  • Page 104: Fax Answering

    AT Command Reference Manual 5.1.5 Fax Answering Answering of fax calls is identical to answering of data calls with the exception that the modem enters the fax handshaking mode instead of the data handshaking mode after going off-hook. If +FAE=0, the modem, after sending answer tone, automatically enters fax mode (+FTH=3), sends the CONNECT message to the DTE, and starts sending FSK flags.

  • Page 105: Fax Data Transmission

    AT Command Reference Manual <DLE><ETX>, generates the ERROR message, and returns to command mode. The modem keeps looking for HDLC flags followed by more data from the remote, with the selected modulation scheme. If the modem detects a receive buffer overflow condition, it concludes that there was an FCS error in that frame. The modem will receive more frames only if a starting flag is detected and there is room in the receive buffer.

  • Page 106: Commands

    5.2 COMMANDS +FCLASS=n - Select Service Class +FCLASS=n command sets the active service class. Parameters: 0-2 Command options: +FCLASS=0 Select Data Mode (Default.) +FCLASS=1 Select Facsimile Class 1 +FCLASS=2 Select Facsimile Class 2 +F<command>? - Report Active Configuration +F<command>? interrogates the modem to determine the active configuration. Typical responses are: +FAE? 0 if auto answer is disabled;...

  • Page 107: Ftm=N - Transmit Data

    +FTM=n - Transmit Data +FTM=n causes the modem to transmit data using the modulation defined below. An ERROR response code results if this command is issued while the modem is on-hook. Parameters: See Command options Command options: +FTM=24 +FTM=48 +FTM=72 +FTM=73 +FTM=74 +FTM=96...

  • Page 108: Fth=N - Transmit Data With Hdlc Framing

    +FTH=n - Transmit Data with HDLC Framing +FTH=n causes the modem to transmit data using HDLC protocol and the modulation defined below. An ERROR response code results if this command is issued while the modem is on-hook. Parameters: See Command options. Command options: +FTH=3 +FTH=24...

  • Page 109: Table 5-2. Fax Class 1 Calling Sequence (One Page)

    Table 5-2. Fax Class 1 Calling Sequence (One Page) DTE Commands (Host) AT+FCLASS=1 PHASE A ATDT6163 PHASE B (10) AT+FRH=3 (11) CONNECT (13) <CSI>,OK (14) AT+FRH=3 (15) CONNECT (17) <DIS>,OK (19) AT+FTH=3 (20) Send HDLC flags (21) CONNECT (22) <TSI> (23) Send TSI frame (25) CONNECT (26) <DCS>...

  • Page 110: Table 5-3. Fax Class 1 Answering Sequence (One Page)

    Table 5-3. Fax Class 1 Answering Sequence (One Page) DTE Commands (Host) AT+FCLASS=1 PHASE A PHASE B (10) <NSF> (11) Send NSF frame (13) CONNECT (14) <CSI> (15) Send CSI frame (17) CONNECT (18) <DIS> (19) Send DIS frame (21) OK, drop carrier (22) AT+FRH=3 (23) CONNECT (25) <TSI>, OK...

  • Page 111: Fax Class 2 Commands

    6. FAX CLASS 2 COMMANDS The fax class 2 commands are summarized in Table 6-1. 6.1 COMMAND SYNTAX AND GUIDELINES 6.1.1 DTE Commands The ISO 646 character set (CCITT T.50 International Alphabet 5, American Standard Code for Information Interchange) is used for the issuance of commands and responses.

  • Page 112: Table 6-1. Fax Class 2 Commands

    Fax Class 2 commands can be separated by the “:” character. The “;” character can be omitted if desired. Note that non-data commands cannot be separated by the “;” which is allowed as a dial modifier. Command +FCLASS= +FDT +FET=N +FDR +FCON +FDCS:...

  • Page 113: Serial Port Speed And Flow Control

    All Class 2 commands are assumed to be the final command on a command line. Additional characters will be ignored. An ERROR message will be generated if any of the following conditions occur: A Class 1 command is received while in Class 2. A Class 2 command is received while in Class 1.

  • Page 114: Session Status Reporting

    6.1.5 Session Status Reporting The DCE provides reports to the DTE on the status of a session. The DCE provides the following status reports: Connection and hang up status: +FCON +FHNG:<0-255> Requested DIS session parameters +FDIS: <string> reports remote facsimile capabilities. Syntax: +FDIS: VR, BR, WD, LN, DF, EC, BF, ST +FDCS: <string>...

  • Page 115: Atd, Originate A Call

    6.3.1 ATD, Originate a Call Syntax: ATD...<CR> The DCE can support a DTE command to originate a call using the ATD command (see Section 3.2). If this command is unsuccessful, the DCE reports an appropriate failure or error type result code such as NO CARRIER, NO DIALTONE, or BUSY (see Section 3.3).

  • Page 116: Fdt, Data Transmission

    6.3.3 +FDT, Data Transmission Syntax: +FDT <CR> The +FDT command prefixes Phase C data transmission. When the DCE is ready to accept Phase C data, it issues the negotiation responses and the CONNECT result code to the DTE. In Phase B, the +FDT command releases the DCE to proceed with negotiation, and releases the DCS message to the remote station.

  • Page 117: Table 6-2. T.30 Session Subparameter Codes

    Label Function Vertical Resolution Bit Rate (See Note 1) Page Width Page Length Data Compression Format Error Correction (Annex A/T.30) Binary File Transfer Scan Time/Line Notes: 1. CCITT T.30 does not provide for the answering station to specify all speeds exactly using the DIS frame. Implementation of some BR codes (e.g., code 2) by an answering DCE is manufacturer specific.

  • Page 118: Fet, Transmit

    6.3.4 +FET, Transmit Page Punctuation Syntax: +FET=<ppm>[,<pc>,<bc>,<fc>] DCE response: +FPTS:<ppr> This command is used to punctuate page and document transmission after one or more +FDT commands. This command generates T.30 Post Page Messages selected by the <ppm> code (Table 6-3). The +FET=<ppm>...

  • Page 119: Fdr, Begin Or Continue Phase C Receive Data

    6.3.5 +FDR, Begin or Continue Phase C Receive Data Syntax: +FDR <CR> Default value: 3 seconds in some places The +FDR command initiates transition to Phase C data reception. This can occur after answering, dialing, a document is received, or a page is received. The DCE reports the negotiated T.30 parameters, with the remote ID information if available.

  • Page 120: Continue Document Reception

    Continue Document Reception The DTE may issue a +FDR command in Phase D, which releases the post page message, and indicates readiness to receive another page after receipt of a Multipage (+FET:0) or PPS-NULL (+FET:3) message. The DCE response will be: CONNECT (<DC2>...

  • Page 121: Fcig, Set Polling Id

    6.3.7 +FCIG, Set Polling ID This command allows setting the Local Polling ID string used in a CIG frame. The syntax of this command is identical to +FLID. Write syntax: +FCIG="<local ID string>" Valid value: 20-character ASCII string Default value: Empty 6.3.8 +FLPL, Indicate a Document for Polling This command allows setting up an answering modem to know that it has a document available for polling.

  • Page 122: Table 6-5. Hang Up Status Codes

    Code 10-19 20-39 40-49 50-69 70-89 90-99 100-119 120-255 Note: Some codes are not implemented. 6-12 AT Command Reference Manual Table 6-5. Hang Up Status Codes Cause Description Call Placement and Termination Normal and proper end of connection Ring Detect without successful handshake Call aborted, from +FK or AN No Loop Current Transmit Phase A &...

  • Page 123: Service Class 2 Dce Responses

    6.4 SERVICE CLASS 2 DCE RESPONSES The DCE sends information responses to the DTE as a facsimile session proceeds. They indicate the state of the facsimile session and convey needed information. These messages are solicited messages generated in execution of DTE action commands described in Section 6.3.

  • Page 124: Fpts:, Receive Page Transfer Status

    6.4.7 +FPTS:, Receive Page Transfer Status Syntax: +FPTS:<ppr>, <lc> [,<blc>, <cblc>] The +FPTS:<ppr> is generated by the DCE at the end of Phase C data reception in execution of a +FDR command. The <ppr> is generated by the DCE; it depends on the DCE capabilities at T.4 error checking. See Table 6-4 for <ppr> values.

  • Page 125: Fcig:, Report The Polled Station Id

    6.4.11 +FCIG:, Report the Polled Station ID Syntax: +FCIG: “< ID string>” Polled Station ID This response reports the received transmit station ID string, if any. This message is generated in execution of Originate, Answer, +FDT, or +FDR commands. 6.4.12 +FDTC:, Report the Polled Station Capabilities Syntax: +FDTC: “<...

  • Page 126: Service Class 2 Parameters

    6.5 SERVICE CLASS 2 PARAMETERS All Service Class 2 parameters can be read, written, and tested for range of legal values by the DCE. The general syntax is described in Section 6.1. Group 3 FAX devices negotiate session parameters in DIS, DCS, and DTC frames. The following parameters are provided to condition the facsimile DCE for the capabilities it will offer and to report the session settings negotiated.

  • Page 127: Fdcs, Current Session Results Parameters

    6.5.3 +FDCS, Current Session Results Parameters Read syntax: +FDCS? DCE response: +FDCS=VR,BR,WD,LN,DF,EC,BF,ST +FDCS= Valid values: See Table 6-2 Default values: 0,0,0,0,0,0,0,0 The +FDCS parameter is loaded with the negotiated T.30 parameters for the current session. A transmitting DCE generates DCS; a receiving DCE gets DCS from the remote station. The DTE may read this parameter. The +FDCS parameter is initialized 0,0,0,0,0,0,0,0 upon initialization and at the beginning of a session.

  • Page 128: Flid=, Local Id String

    6.5.4 +FLID=, Local ID String Write syntax: +FLID="<local ID string>" Valid value: 20-character ASCII string Default value: Empty If FLID is not a null string, it generates a TSI or CSI frame. Table 3/T.30 includes digits 0-9, “+” and space. If the DCE supports use of Table 3/T.30 only, the response to a +FLID=? command is “(20) (32, 43, 48-57).”...

  • Page 129: Faxerr, T.30 Session Error Report

    The +FPHCTO command determines how long the DCE will wait for a command after reaching the end of data when transmitting in Phase C. When this time-out is reached, the DCE assumes there are no more pages and no documents to send.

  • Page 130: Fbuf?, Buffer Size

    6.5.12 +FBUF?, Buffer Size Read syntax: +FBUF? DCE response syntax: <bs>, <xoft>, <xont>, <bc> where: <bs> = total buffer size <xoft> = XOFF threshold <xcont> = XON threshold <bc> = current buffer byte count Example: +FBUF? 512, 506, 500, 0 The +FBUF parameter allows the DTE to determine the characteristics of the DCE's data buffer.

  • Page 131: Table 6-6. Send Two Pages, 1-D, No Errors

    DTE Command AT+CLASS=2 AT+FLID="<local ID>" AT<dial string> +FCON [+FCSI:"<csi>"] +FDIS: <dis codes> AT+FDT +FDCS:<DCS codes> CONNECT <XON> <1st page data> <DLE><ETX> AT+FET=0 +FPTS:1 AT+FDT CONNECT <XON> <2nd page data> <DLE><ETX> AT+FET=2 +FPTS:1 +FHNG:0 1048 AT Command Reference Manual Table 6-6. Send Two Pages, 1-D, No Errors DCE Response Local DTE Action Set Class 2...

  • Page 132: Table 6-7. Receive Two Pages, 1-D Data, No Errors

    Table 6-7. Receive Two Pages, 1-D Data, No Errors DTE Command AT+FCR=1 AT+FLID="<local ID>" RING +FCON [+FTSI:"<tsi>"] +FDCS:<dcs codes> AT+FDR +FCFR [+FDCS:"<dcs codes>] CONNECT <DC2> <page data stream> <DLE><ETX> +FPTS:1, <lc> +FET:0 AT+FDR CONNECT <DC2> <page data stream> <DLE><ETX> +FPTS:1, <lc> +FET:2 AT+FDR +FHNG:0...

  • Page 133: Voice/Audio Commands

    7. VOICE/AUDIO COMMANDS The modem is configured into Voice Mode (modem models not supporting business audio) or Voice/Audio Mode (modem models supporting business audio) in response to the AT #CLS=8 command, and this mode is composed of the Voice and Audio sub-configurations as described in this section.

  • Page 134: Voice Transmit Mode

    In this mode, and when the sampling rate is 7.2 kHz, the modem detects and reports DTMF, dial tone, and busy tone cadence as enabled by the #VTD command. Additionally, the modem detects and reports inactivity (periods of silence) as enabled by the #VSS command.

  • Page 135: Call Establishment - Answer

    AT Command Reference Manual 7.2.2 Call Establishment - Answer Directed Answer (Answer as a specific modem type) If the DTE wants to be only one kind of answerer (i.e., voice/audio, fax, or data), it can configure the modem to answer exclusively in the chosen mode.

  • Page 136: Voice/Audio Data Transfer

    7.2.3 Voice/Audio Data Transfer A significant area of concern when handling the transfer of voice/audio data is the data transfer rate on the modem/DTE interface. Data transfer rates can be expressed as the number of interrupts which must be serviced per time period to keep up.

  • Page 137: Table 7-2. Codes Sent To The Dte

    Code Sent to DTE DTMF. Digits 0 through 9, *, #, or A through D detected by the modem, i.e., user has pressed a key <DLE>0 – <DLE>9, <DLE>*, on a local or remote telephone. The modem sends only one <DLE> code per DTMF button pushed. <DLE>#, <DLE>A –<DLE>D <DLE>a...

  • Page 138: Shielded Commands From The Dte

    Table 7-2. Shielded Codes Sent to the DTE (Cont’d) Code Sent to DTE <DLE>s Silence. Sent in Voice Receive Mode after the silence detection timer (#VSP) expires and if valid voice has not been detected (#VSS). In general, <DLE>s is sent if no sound was detected at all. This differs slightly from Quiet (<DLE>q) in that it can be used by the DTE in its discrimination algorithms as a means of determining if anything at all is coming from the remote station.

  • Page 139: Table 7-3. Shielded Dte Codes

    Code Sent to Modem Pause. Sent during Voice Transmit Mode to force the modem to suspend sending voice data to the <DLE>p selected output device(s). Any data currently in the voice transmit buffer is saved until either a resume (<DLE>r), or cancel <DLE><CAN>, is received, in which case the data is lost. If a <DLE><ETX>...

  • Page 140: Voice Record

    7.2.6 Voice Record To effect recording of a message received via a handset or microphone, the DTE must configure the modem for Voice Mode (#CLS=8), and select the proper relay setup (#VLS) to instruct the modem whether to use the auxiliary device. The modem responds to the #VLS command by issuing a relay activate command to select the input device.

  • Page 141: Voice Call Termination

    AT Command Reference Manual 7.2.8 Voice Call Termination Local Disconnect The DTE can disconnect from a telephone call by commanding a mode change to Online Voice Command Mode (if not already in it), and by issuing the H command. Remote Disconnect Detection When in Voice Receive Mode, the modem sends the proper shielded <DLE>...

  • Page 142: At Voice Command Summary

    7.3 AT VOICE COMMAND SUMMARY Table 7-4 provides a complete summary of the AT voice commands described in detail in Sections 7.3.1 and 7.3.2. Command #BDR #CID #CLS #MDL? #MFR? #REV? #VBQ? #VBS #VBT #VCI? #VLS #VRA #VRN #VRX #VSD #VSK #VSP #VSR...

  • Page 143: Ata - Answering In Voice/Audio

    ATA - Answering in Voice/Audio The answer action command works analogously to the way it works in Data and Fax Modes except for the following: When configured for Voice/Audio Mode (#CLS=8), the modem enters Online Voice Command Mode immediately after going off-hook.

  • Page 144: Atz - Reset From Voice Mode

    ATZ - Reset from Voice Mode This command works the same as in Data and Fax modes. In addition, the Z command resets all voice related parameters to default states, forces the #BDR=0 condition (autobaud enabled), and forces the telephone line to be selected with the handset on-hook.
  • Page 145 AT Command Reference Manual #CID=2 Enables unformatted Caller ID reporting of any ICLID packet received after the first RING cycle including SDM, MDM, or call waiting packets. 1048 7-13...

  • Page 146: Cls - Select Data, Fax, Or Voice/Audio

    #CLS - Select Data, Fax, or Voice/Audio This command selects Data, Fax, or Voice/Audio Mode from operation in any mode. Parameters: n = 0, 1, 2, or 8 Default: Result Codes: If n = 0, 1, 2, or 8. ERROR Otherwise.

  • Page 147: At#V Commands Enabled Only In Voice Mode (#Cls=8)

    7.3.2 AT#V Commands Enabled Only in Voice Mode (#CLS=8) The commands described in the following subsection are extensions to the command set which the modem recognizes only when configured for Voice/Audio Mode with the #CLS=8 command. #TL- Audio Output Transmit Level This command provides adjustment of the transmit level of the data pump audio output, affecting both the playback level of the handset and speaker and telephone line.

  • Page 148: Vbt - Beep Tone Timer

    #VBT - Beep Tone Timer This command defines the time period, in 10ths of a second up to 4 seconds (40) which is used by the modem as the DTMF or fixed tone duration for generating tones while in Online Voice Command Mode. Parameters: n = 0 –...

  • Page 149: Vls - Voice Line Select

    #VLS - Voice Line Select This action command can be used to select which devices are routed through the modem. Parameters: n = 0-9 as supported by the modem model. [This is the device position number (not device number) as reflected in response to #VLS=?] Default: Result Codes: If n = 0-9 as supported by the modem model.

  • Page 150: Table 7-5. Device Types Supported By #Vls

    ASCII Digit Telephone Line with Telephone handset. This is the default device selected. In this configuration, the user can pick up a handset which is connected to the same telephone line as the modem, and * record both sides of a conversation with a remote station. The modem currently supports one telephone line/handset, which is in the first position of the #VLS =? response.

  • Page 151: Vra - Ringback Goes Away Timer (Originate)

    #VRA - Ringback Goes Away Timer (Originate) This command can be used, when originating a voice/audio call (#CLS=8) to set the “Ringback Goes Away” timer value, i.e., an amount of time (in units of 100 ms) measured from when the ringback cadence stops once detected. If ringback is not detected within this period, the modem assumes that the remote has picked up the line and switches to Online Voice Command Mode.

  • Page 152: Vsd - Enable Silence Deletion (Voice Receive) [Adpcm]

    #VSD - Enable Silence Deletion (Voice Receive) [ADPCM] This command provides no function other than command response compatibility. Parameters: n = 0 or 1 Default: Result Code: If n = 0 or 1. ERROR Otherwise. Command options: #VSD? Returns the current setting of the #VSD command as an ASCII decimal value in result code format.

  • Page 153: Vsp - Silence Detection Period (Voice Receive) [Adpcm]

    #VSP - Silence Detection Period (Voice Receive) [ADPCM] This command sets the Voice Receive Mode silence detection period (inactivity timer) value. The parameter, in units of 100 ms, can be used when receiving voice data. This is an amount of time, which if elapsed without receiving any ADPCM data, causes the modem to send the <DLE>s or <DLE>q codes after insuring that the buffer is empty.

  • Page 154: Vss - Silence Detection Tuner (Voice Receive) [Adpcm]

    #VSS - Silence Detection Tuner (Voice Receive) [ADPCM] This command enables or disables the Voice Receive mode silence detection, and controls the sensitivity employed by the modem in ADPCM compressing periods of silence. Parameters: n = 0 – 3 Default: Result Codes: If n = 0 –...

  • Page 155: Vtd - Dtmf Tone Reporting

    #VTD - DTMF Tone Reporting This command queries and controls which types of tones can be detected and reported to the DTE via shielded codes in Voice Transmit, Voice Receive, and Online Voice Command Modes. Parameters: i, j, k (three ASCII hexadecimal bit maps) Default: 3F, 3F, 3F Result Codes:...

  • Page 156: Vtm - Enable Timing Mark Placement

    #VTM - Enable Timing Mark Placement This command controls the placement of <DLE><T> timing marks by the DCE in the data stream during ADPCM recording. Parameters: n=0 (disabled) or 10 (1 second interval) Default: n=0 (disabled) Result Codes: If n=0 or 10 ERROR Otherwise Command Options:...

  • Page 157: Vtx - Voice Transmit

    #VTX - Voice Transmit This action command can be issued if and only if the modem is in the Online Voice Command Mode (indicated previously with the VCON message), and is the switch to Voice Transmit Mode. #VTX is used when a voice file is to be transmitted to the line, speaker, or handset.

  • Page 158: Originating A Call In Speakerphone Mode

    Originating a Call in Speakerphone Mode To initiate a call with the speakerphone, issue: AT#CLS=8 AT#VRN=0 AT#VLS=6 (Selects the speakerphone) It is recommended to set the VRN command to 0 which disables ringback detection before reporting the VCON message. ATDT<number> The modem then responds with: VCON (based on the AT#VRA and #VRN setting)

  • Page 159: Recording A Handset Conversation On The Phone Line

    Recording a Handset Conversation on the Phone Line To recording a handset conversation on the phone line, issue: AT#VLS=8 (valid after Voice On-line mode) This command engages the Caller ID relay to allow recording of conversation when using a handset by routing the signal to the audio codec (if populated).
  • Page 160 <spkr> Speaker Output Attentuation Range: 0 to15 (speaker attenuation in 2 dB steps) <mic> Microphone Gain Parameter Range: 0 to 3 <mic> 7-28 AT Command Reference Manual 0 dB attenuation 10 dB attenuation (default) 30 dB attentuation Speaker mute 0 dB gain 10 dB gain 15 dB gain (default) 20 dB gain...

  • Page 161: Room Monitor

    It is not necessary to enter all <mute>,<spkr>,<mic> options while issuing AT#SPK. Examples: AT#SPK= <mute>,,, AT#SPK = ,<spkr>,, AT#SPK = ,, <mic> AT#SPK = <mute>,<spkr>,, AT#SPK = <mute>,,<mic> AT#SPK = ,<spkr>,<mic> Room Monitor The modem can be configured to a listen only mode where the microphone automatic gain control is set to maximum (50 dB).

  • Page 162: Using Voiceview With Speakerphone, Headset, And Handset Modes

    7.3.4 Using VoiceView with Speakerphone, Headset, and Handset modes Handset (#VLS=0), speakerphone (#VLS=6), or headset mode (#VLS=5) can be selected during VoiceView mode (+FCLASS=80), when dialing is done on the handset. The ATA command is not accepted while in VoiceView mode in accordance with the VoiceView Protocol specification.

  • Page 163: Using Modem As Dialer Prior To Voiceview Mode

    Using Modem as Dialer Prior to VoiceView Mode To use the modem to dial a call, the modem must be in Voice On-line mode (via #CLS=8) to dial before enabling VoiceView mode. VoiceView mode can enabled by the AT+FCLASS=80 parameter after Voice On-line (VCON) mode in handset, speakerphone or handset emulation modes.

  • Page 164: S-Registers

    7.4 S-REGISTERS The following S-Register is global, meaning that it can be set in any appropriate mode (i.e., any #CLS setting). S30 - Disconnect Inactivity Timer Range: n = 0 – 255 Default: 0 (OFF, which means DTE should usually set it to some value for Voice) Command options: S30=0 Disconnect Inactivity timer off.

  • Page 165: Table 7-7. Record A Greeting Message

    DTE to Modem Modem to DTE #CLS=8 #VBS=4 S30=60 #BDR=16 #VSP=20 #VSS =1 #VLS=? 0,1,2,3,4 #VLS=1 VCON 1048 AT Command Reference Manual Table 7-7. Record a Greeting Message Description and Interpretation Configure the modem for Voice Mode. The modem confirms command implemented, and is now set up for voice. The DTE asks for 4-bit compression (ADPCM).
  • Page 166 DTE to Modem Modem to DTE #VRX CONNECT <Data> <DLE>q <DLE>* <DLE><ETX> VCON #VLS=0 7-34 AT Command Reference Manual Table 7-7. Record a Greeting Message [Cont’d] Description and Interpretation This tells the modem that the DTE is ready to receive a voice message at the current compression/sampling settings.

  • Page 167: Table 7-8. Playback A Greeting Message

    DTE to Modem Modem to #CLS=8 #VBS=4 #BDR=16 #VLS=2 VCON #VTX CONNECT <Data> <DLE><ETX> VCON 1048 AT Command Reference Manual Table 7-8. Playback a Greeting Message Description and Interpretation Configure the modem for Voice Mode. The modem confirms command reception, and is now set up for voice. The DTE asks for 4-bit compression.

  • Page 168: Table 7-9. Answer Call/Play Greeting/Record Message

    Table 7-9. Answer Call/Play Greeting/Record Message DTE to Modem Modem to DTE #CLS=8 #VBS=4 #VSS =2 #VLS=0 RING #CLS=8 #BDR=16 VCON 7-36 AT Command Reference Manual Description and Interpretation Configure the modem for Voice Mode. Note that the #BDR setting is assumed to be zero here, meaning that no time-out occurs forcing #CLS=0.
  • Page 169 Table 7-9. Answer Call/Play Greeting/Record Message [Cont’d] DTE to Modem Modem to DTE #VTX CONNECT <Data> <DLE><ETX> VCON #VBT=12 #VTS=# #VBS=4 #VRX CONNECT <Data> <DLE>b <DLE><ETX> VCON 1048 AT Command Reference Manual Description and Interpretation The DTE does not wait for any tones, and tells the modem that it is ready to send a voice greeting at the current compression and sampling settings (4-bit/7200).

  • Page 170: Table 7-10. Call/Record Message/Receive Fax

    DTE to Modem Modem to DTE #CLS=8 #VBS=4 #VSS=2 #VLS=0 #CLS=8 RING #BDR=16 VCON #VTX CONNECT <Data> <DLE><ETX> VCON #VBT=13 #VTS= [1000,0,20],9, 7-38 AT Command Reference Manual Table 7-10. Call/Record Message/Receive Fax Description and Interpretation Configure the modem for Voice Mode. The modem agrees, and is now set up for voice.
  • Page 171 Table 7-10. Answer Call/Record Message/Receive Fax (Cont’d) DTE to Modem Modem to DTE #VRX CONNECT <Data> <DLE>5 <DLE><ETX> VCON #CLS=1 1048 AT Command Reference Manual Description and Interpretation The DTE instructs the modem to turn the line around and begin recording a message from the remote.

  • Page 172: Table 7-11. Answer Call, Determine It's A Fax

    DTE to Modem Modem to DTE RING #CLS=8 #VBS=4 #BDR=16 #VSS =2 VCON <DLE>c #CLS=1 7-40 AT Command Reference Manual Table 7-11. Answer Call, Determine It's a Fax Description and Interpretation Sometime later, the next beta-site calls. Configure the modem for Voice Mode. The modem agrees, and is now set up for voice.

  • Page 173: Table 7-12. Adaptive Fax/Data/Voice; Determine Data

    Table 7-12. Adaptive Fax/Data/Voice; Determine Data DTE to Modem Modem to DTE RING #CLS=8 #BDR=16 #VSS=2 VCON #VTX CONNECT <Data> <DLE><ETX> VCON #VTS=# VCON #VRX <DLE>s <DLE><ETX> VCON #CLS=0 1048 AT Command Reference Manual Description and Interpretation Sometime later, we receive a call. Configure the modem for Voice Mode (still ADPCM).

  • Page 174: Table 7-13. Originate A Call, Send Answerer A Message

    Table 7-13. Originate a Call, Send Answerer a Message DTE to Modem Modem to DTE #CLS=8 #BDR=16 #VLS=0 #VRA=45 DT6807 VCON #VTX CONNECT <Data> <DLE><ETX> VCON 7-42 AT Command Reference Manual Description and Interpretation Configure the modem for Voice Mode (still ADPCM). The modem agrees, and is now set up for voice.

  • Page 175: At Command Set Summary

    8. AT COMMAND SET SUMMARY 8.1 BASIC AT COMMANDS Command Re-execute command. Go off-hook and attempt to answer a call. Select V.22 connection at 1200 bps. Select Bell 212A connection at 1200 bps. Return OK message. Dial modifier. Turn off command echo. Turn on command echo.
  • Page 176 Force DTMF dialing. Report short form (terse) result codes. Report long form (verbose) result codes. Report DTE speed in EC mode. Report line speed, EC protocol and DTE speed. Report DCE speed in EC mode. Report basic call progress result codes, i.e., OK, CONNECT, RING, NO CARRIER (also, for busy, if enabled, and dial tone not detected), NO ANSWER and ERROR.
  • Page 177 &M0 Select direct asynchronous mode. &M1 Select sync connect with async off-line command mode. * &M2 Select sync connect with async off-line command mode and enable DTR dialing of directory zero. * &M3 Select sync connect with async off-line command mode and enable DTR to act as Talk/Data switch.

  • Page 178: Ecc Commands

    Controls break handling during three states: When modem receives a break from the DTE: \K0,2,4 Enter on-line command mode, no break sent to the remote modem. Clear buffers and send break to remote modem. Send break to remote modem immediately. Send break to remote modem in sequence with transmitted data.

  • Page 179: Mnp 10 Commands

    8.3 MNP 10 COMMANDS Disable MNP 10 extended services. Enable MNP 10 extended services. Enable MNP 10 extended services detection only. -SEC=0 Disable MNP10-EC. -SEC=1,[<tx level>] Enable MNP10-EC and set transmit level <tx level> 0 to 30 (0 dBm to -30 dBm). 8.4 W-CLASS COMMANDS Display list of permanently blacklisted numbers.

  • Page 180: Fax Class 2

    8.7 FAX CLASS 2 +FCLASS=n Service class. +FAA=n Adaptive answer. +FAXERR Fax error value. +FBOR Phase C data bit order. +FBUF? Buffer size (read only). +FCFR Indicate confirmation to receive. +FCLASS= Service class. +FCON Facsimile connection response. +FCIG Set the polled station identification. +FCIG: Report the polled station identification.

  • Page 181: Voice/Audio Commands

    8.8 VOICE/AUDIO COMMANDS #BDR Select baud rate (turn off autobaud). #CLS Select data, fax, or voice. #MDL? Identify model. #MFR? Identify manufacturer. #REV? Identify revision level. #SPK= Speakerphone setting. Audio output transmit level. #VBQ? Query buffer size. #VBS Bits per sample. #VBT Beep tone timer.
  • Page 182 AT Command Reference Manual This page is intentionally blank. 1048...

  • Page 183: Common Configuration Setup Strings

    9. COMMON CONFIGURATION SETUP STRINGS This appendix describes setup strings to establish commonly used configurations. Force V.42 bis data compression with LAP-M error correction. AT\N4%C2-K0 Force V.42 bis data compression with MNP error correction. AT\N5%C2 Force MNP 5 data compression with MNP error correction. AT\N5%C1 Note: With the setup strings in examples 1-3, if the remote is unable to negotiate the desire rate mode, the modem will disconnect and respond with NO CARRIER.
  • Page 184 AT Command Reference Manual This page is intentionally blank. 1048...
  • Page 185 INSIDE BACK COVER NOTES...
  • Page 186 REGIONAL SALES OFFICES Headquarters US Southwest Office Rockwell Semiconductor Systems Rockwell Semiconductor Systems 4311 Jamboree Road, 5000 Birch Street P.O. Box C Suite 400 Newport Beach, CA 92658-8902 Newport Beach, CA 92660 Phone: (714) 221-4600 Phone: (714) 222-9119 Fax: (714) 221-6375 Fax: (714) 222-0620 US Southwest Satellite Office...
