- Page 1 2017 SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 Page 1 of 17...
-
Page 2: Table Of Contents
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Contents Page No: Cover removal ..........................3 Cover assembly ..........................5 Control board cover disassembly ....................5 Control board, ribbon cable disconnection ................6 Earth cable disconnection ......................6 External fan disassembly ......................7 Internal fan disassembly ...................... -
Page 3: Cover Removal
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 1. Cover removal Use a Torx T30 screwdriver to remove cover holding display Use a large flathead screwdriver to remove cable protection cover Page 3 of 17... - Page 4 SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Use a Philips screwdriver to remove flange plate cover (Torque setting 1Nm) Page 4 of 17...
-
Page 5: Cover Assembly
2017 SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2. Cover assembly 3. Control board cover disassembly Page 5 of 17... -
Page 6: Control Board, Ribbon Cable Disconnection
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 4. Control board, ribbon cable disconnection Remove connector by holding the sides of the connector and lifting away from the PC per the direction shown 5. Earth cable disconnection Remove the connector by pulling away from the PC per the direction shown Remove cable from connector... -
Page 7: External Fan Disassembly
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 6. External fan disassembly Remove direction of the arrow, push fit connector Remove connector using a terminal screwdriver Fan box can now be removed by pushing in the clips towards the heatsink with flat headed screwdriver. -
Page 8: Internal Fan Disassembly
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Fan box assembly 2. Internal fan disassembly 7. External fan disassembly Ensure white fan labels face inwards to ensure correct air flow direction Page 8 of 17... -
Page 9: Internal Fan Disassembly
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 7. Internal fan disassembly The internal fan is simply cable tied to control PCB mounting Fan is connected to the Power board via a push fit connector Page 9 of 17... -
Page 10: Internal Plastic Terminal Cover
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 8. Internal Plastic terminal cover Remove 2 x screws holding the cover in place using a Torx 20 screwdriver (Torque setting 2Nm) 1) Ensure fan lead is disconnected 2) As shown in the picture above the cover can be removed by lifting the plastics in the direction of... -
Page 11: Control Board Removal
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 9. Control board removal Unclip legs of plastics control board supports from power board Tilt control board support up in the direction of the arrow and pull support out ensure no other components are damaged Page 11 of 17... -
Page 12: Power Board Removal
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Power board removal Remove the 14 x T25 Torx screws highlighted in red (Torque set to 4Nm) Remove the 2 x T20 Torx screws highlighted in orange (Torque set to 4Nm) Page 12 of 17... - Page 13 SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Ensure antistatic precautions are taken whenever handling electronic equipment Remove board ensure only not static sensitive are being held Ensure flying lead are pushed out of the way of the metalwork during removal of the power board Ensure flying lead are pushed out of the way of the metalwork...
-
Page 14: Dc Capacitor's
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 DC capacitor’s Remove the 8 x T20 Torx screws highlighted in red (Torque set to 4Nm) Ensure correct polarity of the DC capacitors Page 14 of 17... -
Page 15: Chokes
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Chokes Remove the 6 x T20 Torx screws highlighted in red (Torque set to 4Nm) Ensure correct polarity of the DC capacitors Page 15 of 17... -
Page 16: Heatsink Removal
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Heatsink removal Remove the 8 x T20 Torx screws highlighted in red (Torque set to 4Nm) When replacing the thermistrate ensure they are in good condition with no holes, replacements available from IDL UK Page 16 of 17... -
Page 17: Heatsink Guard Removal
SERVICE MANUAL ODP-2/HVAC FRAME SIZE 5 2017 Heatsink guard removal Page 17 of 17...
