Zonet ZSR1114WE User Manual
  1. Manuals
  2. Brands
  3. Zonet Manuals
  4. Wireless Router
  5. ZSR1114WE
  6. User manual

Zonet ZSR1114WE User Manual

Wireless lan broadband router
Hide thumbs Also See for ZSR1114WE:
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Version: 1.1
Wireless LAN Broadband Router

Advertisement

Table of Contents
loading

Related Manuals for Zonet ZSR1114WE

Summary of Contents for Zonet ZSR1114WE

  • Page 1 User’s Manual Version: 1.1 Wireless LAN Broadband Router...

  • Page 2: Federal Communication Commission Interference Statement

    Trademarks Copyright @2005 Contents are subject to change without notice. All trademarks belong to their respective proprietors. Copyright Statement THIS DOCUMENT CONTAINS OF PROPRIETARY TECHNICAL INFORMATION THAT IS THE PROPERTY OF THIS COMPANY. AND NO PART OF THIS DOCUMENTATION MAY BE REPRODUCED, STORED IN A RETRIEVAL SYSTEM OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRICAL OR MECHANICAL, BY PHOTOCOPYING, RECORDING, OR OTHERWISE, WITHOUT THE PRIOR WRITTEN CONSENT OF THIS COMPANY.

  • Page 3: Table Of Contents

    USER’S MANUAL OF WLAN BROADBAND ROUTER Table of Contents REVISION HISTORY ...I TERMINOLOGY ... II INTRODUCTION... 1 ... 1 ACKAGE CONTENTS RODUCT PECIFICATIONS ... 2 RODUCT EATURES RONT ANEL ESCRIPTION ANEL ESCRIPTION INSTALLATION ... 6 ARDWARE NSTALLATION OFTWARE NSTALLATION SOFTWARE CONFIGURATION ... 7 REPARE YOUR TO CONFIGURE THE WLAN B...
  • Page 4 USER’S MANUAL OF WLAN BROADBAND ROUTER WDS Security Setup ... 23 WDS AP Table ... 24 3.3.9 Site Survey ... 25 3.3.10 LAN Interface Setup ... 25 3.3.11 WAN Interface Setup ... 27 Static IP... 27 DHCP Client ... 28 PPPoE ...
  • Page 5 USER’S MANUAL OF WLAN BROADBAND ROUTER 4.11 W RTS (R HAT IS EQUEST 4.12 W HAT IS EACON NTERVAL 4.13 W HAT IS REAMBLE 4.14 W SSID B HAT IS ROADCAST 4.15 W HAT IS ROTECTED 4.16 W WPA2? ... 55 HAT IS 4.17 W 802.1...

  • Page 6: Revision History

    USER’S MANUAL OF WLAN BROADBAND ROUTER Revision History DATE REVISION OF USER’S MANUAL 2005/4/7 First release (Version 1.0) 2005/6/15 Add product with SMA Antenna info Version: 1.0 FIRMWARE V1.2.0 V1.2.x...

  • Page 7: Terminology

    USER’S MANUAL OF WLAN BROADBAND ROUTER Terminology 3DES Triple Data Encryption Standard Advanced Encryption Standard ANSI American National Standards Institute Access Point Complementary Code Keying CSMA/CA Carrier Sense Multiple Access/ Collision Avoidance CSMA/CD Carrier Sense Multiple Access/ Collision Detection DDNS Dynamic Domain Name Server Diffie-Hellman Algorithm DHCP...
  • Page 8 USER’S MANUAL OF WLAN BROADBAND ROUTER TKIP Temporal Key Integrity Protocol UPNP Universal Plug and Play Virtual Private Network Wireless Distribution System Wired Equivalent Privacy WLAN Wireless Local Area Network Wi-Fi Protected Access Version: 1.0...

  • Page 9: Introduction

    USER’S MANUAL OF WLAN BROADBAND ROUTER 1 Introduction The Wireless LAN Broadband Router is an affordable IEEE 802.11b/g wireless LAN broadband router solution; setting SOHO and enterprise standard for high performance, secure, manageable and reliable WLAN. This document describes the steps required for the initial IP address assign and other WLAN router configuration.

  • Page 10: Product Features

    USER’S MANUAL OF WLAN BROADBAND ROUTER Version: 1.0 1.3 Product Features Complies with IEEE 802.11b/g standard for 2.4GHz Wireless LAN. Supports bridging, routing, VPN, WISP functions between wireless and wired Ethernet interfaces. Supports 64-bit and 128-bit WEP, WPA, WPA2 encryption/decryption function to protect the wireless data transmission.

  • Page 11: Front Panel Description

    USER’S MANUAL OF WLAN BROADBAND ROUTER 1.4 Front Panel Description Figure 1 –WLAN Broadband Router Front Panel LED Indicator 1. Power LED 2. WLAN LED 3. WAN LED 10/100M 4. LAN LED 10/100M LAN LED WAN LED State Description The WLAN Broadband Router is powered on. The WLAN Broadband Router is powered off.

  • Page 12: Rear Panel Description

    USER’S MANUAL OF WLAN BROADBAND ROUTER 1.5 Rear Panel Description Figure 2 – WLAN Broadband Router Rear Panel (Fixed Antenna) Figure 2.1 – WLAN Broadband Router Rear Panel (SMA Antenna) Fixed Antenna Reset SMA Antenna Version: 1.0 Power Reset Power...
  • Page 13 USER’S MANUAL OF WLAN BROADBAND ROUTER Interfaces 1. Antenna (Fixed / SMA) 2. Reset 3. WAN 4. LAN 5. Power Description The Wireless LAN Antenna. (Figure 2 / Figure 2.1) Push continually the reset button 5 ~ 10 seconds to reset the configuration parameters to factory defaults.

  • Page 14: Installation

    USER’S MANUAL OF WLAN BROADBAND ROUTER 2 Installation 2.1 Hardware Installation Step 1: Place the Wireless LAN Broadband Router to the best optimum transmission location. The best transmission location for your WLAN Broadband Router is usually at the geographic center of your wireless network, with line of sign to all of your mobile stations.

  • Page 15: Software Configuration

    USER’S MANUAL OF WLAN BROADBAND ROUTER 3 Software configuration There are web based management and configuration functions allowing you to have the jobs done easily. The WLAN Broadband Router is delivered with the following factory default parameters on the Ethernet LAN interfaces. Default IP Address: 192.168.1.254 Default IP subnet mask: 255.255.255.0 WEB login User Name: <empty>...
  • Page 16 USER’S MANUAL OF WLAN BROADBAND ROUTER Panel window will appear. 2. Move mouse and double-click the right button on Network and Dial-up Connections icon. Move mouse and double-click the Local Area Connection icon. The Local Area Connection window will appear. Click Properties button in the Local Area Connection window.

  • Page 17: Connect To The Wlan Broadband Router

    USER’S MANUAL OF WLAN BROADBAND ROUTER 3.2 Connect to the WLAN Broadband Router Open a WEB browser, i.e. Microsoft Internet Explore, then enter 192.168.1.254 on the URL to connect the WLAN Broadband Router. 3.3 Management and configuration on the WLAN Broadband Router 3.3.1 Status This page shows the current status and some basic settings of the device, includes system, wireless, Ethernet LAN and WAN configuration information.
  • Page 18 USER’S MANUAL OF WLAN BROADBAND ROUTER Wireless configuration Mode Band SSID Channel Number Encryption Associated Clients BSSID LAN configuration IP Address Subnet Mask Default Gateway DHCP Server MAC Address WAN configuration Attain IP Protocol IP Address Subnet Mask Default Gateway MAC Address It shows wireless operation mode It shows the current wireless operating frequency.

  • Page 19: Setup Wizard

    USER’S MANUAL OF WLAN BROADBAND ROUTER 3.3.2 Setup Wizard This page guides you to configure wireless broadband router for first time Screen snapshot – Setup Wizard Operation Mode This page followed by Setup Wizard page to define the operation mode. Screen snapshot –...

  • Page 20: Time Zone Setting

    USER’S MANUAL OF WLAN BROADBAND ROUTER Time Zone Setting This page is used to enable and configure NTP client Screen snapshot – Time Zone Settings LAN Interface Setup This page is used to configure local area network IP address and subnet mask Screen snapshot –...

  • Page 21: Wan Interface Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER WAN Interface Setup This page is used to configure WAN access type Screen snapshot – WAN Interface Setup Wireless Basic Settings This page is used to configure basic wireless parameters like Band, Mode, Network Type SSID, Channel Number, Enable Mac Clone(Single Ethernet Client) Screen snapshot –...

  • Page 22: Wireless Security Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER Wireless Security Setup This page is used to configure wireless security Screen snapshot – Wireless Security Setup 3.3.3 Operation Mode This page is used to configure which mode wireless broadband router acts Screen snapshot – Operation Mode Item Gateway Description...

  • Page 23: Wireless - Basic Settings

    USER’S MANUAL OF WLAN BROADBAND ROUTER Bridge Wireless ISP Apply Changes Reset 3.3.4 Wireless - Basic Settings This page is used to configure the parameters for wireless LAN clients that may connect to your Broadband Router. Here you may change wireless encryption settings as well as wireless network parameters.

  • Page 24: Wireless - Advanced Settings

    USER’S MANUAL OF WLAN BROADBAND ROUTER Mode Site Survey SSID Channel Number Associated Clients Enable Mac Clone (Single Ethernet Client) Apply Changes Reset 3.3.5 Wireless - Advanced Settings These settings are only for more technically advanced users who have a sufficient knowledge about wireless LAN.
  • Page 25 USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – Wireless Advanced Settings Item Authentication Type Fragment Threshold RTS Threshold Beacon Interval Data Rate Preamble Type Broadcast SSID IAPP Description Click to select the authentication type in Open System, Shared Key or Auto selection. Set the data packet fragmentation threshold, value can be written between 256 and 2346 bytes.

  • Page 26: Wireless - Security Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER 802.11g Protection Apply Changes Reset 3.3.6 Wireless - Security Setup This page allows you setup the wireless security. Turn on WEP, WPA, WPA2 by using encryption keys could prevent any unauthorized access to your wireless network.
  • Page 27 USER’S MANUAL OF WLAN BROADBAND ROUTER Use 802.1x Authentication WPA Authentication Mode Pre-Shared Key Format While Encryption is selected to be WPA. Pre-Shared Key Enable Pre-Authentication Authentication RADIUS Server Apply Changes Reset While Encryption is selected to be WEP. Click the check box to enable IEEE 802.1x authentication function.

  • Page 28: Iwep Key Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER WEP Key Setup Screen snapshot – WEP Key Setup Item Key Length Key Format Default Tx Key Encryption Key 1 Encryption Key 2 Encryption Key 3 Encryption Key 4 Apply Changes Close Reset Description Select the WEP shared secret key length from pull-down menu.

  • Page 29: Wireless - Access Control

    USER’S MANUAL OF WLAN BROADBAND ROUTER WEP encryption key (secret key) length: Length Format ASCII 3.3.7 Wireless - Access Control If you enable wireless access control, only those clients whose wireless MAC addresses are in the access control list will be able to connect to your Access Point.

  • Page 30: Wds Settings

    USER’S MANUAL OF WLAN BROADBAND ROUTER Comment Apply Changes Reset Current Access Control List Delete Selected Delete All Reset 3.3.8 WDS Settings Wireless Distribution System uses wireless media to communicate with other APs, like the Ethernet does. To do this, you must set these APs in the same channel and set MAC address of other AP that you want to communicate with in the table and then enable the WDS.

  • Page 31: Iwds Security Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER Item Enable WDS MAC Address Comment Apply Changes Reset Set Security Show Statistics Delete Selected Delete All Reset WDS Security Setup Requirement: Set [Wireless]->[Basic Settings]->[Mode]->AP+WDS This page is used to configure the wireless security between APs. Refer to 3.3.6 Wireless Security Setup.

  • Page 32: Wds Ap Table

    USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – WDS Security Setup WDS AP Table This page is used to show WDS statistics Screen snapshot – WDS AP Table Item MAC Address Tx Packets Tx Errors Rx Packets Description It shows the MAC Address within WDS. It shows the statistic count of sent packets on the wireless LAN interface.

  • Page 33: Site Survey

    USER’S MANUAL OF WLAN BROADBAND ROUTER Tx Rare (Mbps) Refresh Close 3.3.9 Site Survey This page is used to view or configure other APs near yours. Screen snapshot – Wireless Site Survey Item SSID BSSID Channel Type Encrypt Signal Select Refresh Connect 3.3.10 LAN Interface Setup...
  • Page 34 USER’S MANUAL OF WLAN BROADBAND ROUTER change the setting for IP address, subnet mask, DHCP, etc. Screen snapshot – LAN Interface Setup Item IP Address Subnet Mask Default Gateway DHCP Server DHCP Client Range Show Client 802.1d Spanning Tree Clone MAC Address Description Fill in the IP address of LAN interfaces of this WLAN Broadband Router.

  • Page 35: Wan Interface Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER Apply Changes Reset 3.3.11 WAN Interface Setup This page is used to configure the parameters for wide area network that connects to the WAN port of your WLAN Broadband Router. Here you may change the access method to Static IP, DHCP, PPPoE or PPTP by click the item value of WAN Access Type.

  • Page 36: Dhcp Client

    USER’S MANUAL OF WLAN BROADBAND ROUTER Default Gateway DNS 1 DNS 2 DNS 3 Clone MAC Address Enable uPNP Enable Web Server Access on WAN Enable WAN Echo Reply Apply Changes Reset DHCP Client Screen snapshot – WAN Interface Setup – DHCP Client in the subnet mask for it.
  • Page 37 USER’S MANUAL OF WLAN BROADBAND ROUTER Item DHCP Client Attain DNS Automatically Set DNS Manually DNS 1 DNS 2 DNS 3 Clone MAC Address Enable uPNP Enable Web Server Access on WAN Enable WAN Echo Reply Apply Changes Reset Description Click to select DHCP support on WAN interface for IP address assigned automatically from a DHCP server.

  • Page 38: Pppoe

    USER’S MANUAL OF WLAN BROADBAND ROUTER PPPoE Screen snapshot – WAN Interface Setup – PPPoE Item PPPoE User Name Password Connection Type Description Click to select PPPoE support on WAN interface. There are user name, password, connection type and idle time settings need to be done.
  • Page 39 USER’S MANUAL OF WLAN BROADBAND ROUTER Idle Time MTU Size Attain DNS Automatically Set DNS Manually DNS 1 DNS 2 DNS 3 Clone MAC Address Enable uPNP Enable Web Server Access on WAN Enable WAN Echo Reply Apply Changes Reset connection through PPPoE protocol whenever you send the data packets out through the WAN interface;...

  • Page 40: Pptp

    USER’S MANUAL OF WLAN BROADBAND ROUTER PPTP Screen snapshot – WAN Interface Setup – PPTP Item PPTP IP Address Subnet Mask Server IP Address User Name Description Allow user to make a tunnel with remote site directly to secure the data transmission among the connection. User can use embedded PPTP client supported by this router to make a VPN connection.

  • Page 41: Firewall - Port Filtering

    USER’S MANUAL OF WLAN BROADBAND ROUTER Password MTU Size Attain DNS Automatically Set DNS Manually DNS 1 DNS 2 DNS 3 Clone MAC Address Enable uPNP Enable Web Server Access on WAN Enable WAN Echo Reply Apply Changes Reset 3.3.12 Firewall - Port Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway.

  • Page 42: Firewall - Ip Filtering

    USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – Firewall - Port Filtering Item Enable Port Filtering Port Range Protocol Comments Apply Changes Reset Delete Selected Delete All Reset 3.3.13 Firewall - IP Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway.

  • Page 43: Firewall - Mac Filtering

    USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – Firewall - IP Filtering Item Enable IP Filtering Local IP Address Protocol Comments Apply Changes Reset Delete Selected Delete All Reset 3.3.14 Firewall - MAC Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway.

  • Page 44: Firewall - Port Forwarding

    USER’S MANUAL OF WLAN BROADBAND ROUTER helpful in securing or restricting your local network. Screen snapshot – Firewall - MAC Filtering Item Enable MAC Filtering Click to enable the MAC filtering security function. MAC Address Comments Apply Changes Reset Delete Selected Delete All Reset 3.3.15 Firewall - Port Forwarding...
  • Page 45 USER’S MANUAL OF WLAN BROADBAND ROUTER necessary if you wish to host some sort of server like a web server or mail server on the private local network behind your Gateway's NAT firewall. Screen snapshot – Firewall - Port Forwarding Item Enable Port Forwarding Click to enable the Port Forwarding security function.

  • Page 46: Firewall - Dmz

    USER’S MANUAL OF WLAN BROADBAND ROUTER Reset 3.3.16 Firewall - DMZ A Demilitarized Zone is used to provide Internet services without sacrificing unauthorized access to its local private network. Typically, the DMZ host contains devices accessible to Internet traffic, such as Web (HTTP) servers, FTP servers, SMTP (e-mail) servers and DNS servers.
  • Page 47 USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – VPN Setup Item Enable IPSEC VPN Enable NAT Traversal Click to enable NAT Traversal function. Generate RSA Key Show RSA Public Key Click to show RSA public key that we generate. Apply Changes Current VPN Connection Table...

  • Page 48: Ivpn Setup - Edit Tunnel

    USER’S MANUAL OF WLAN BROADBAND ROUTER VPN Setup - Edit Tunnel Screen snapshot – VPN Setup-Edit-1 Item Enable Tunnel # Connection Name Auth Type Local Site Local IP Address/Network Local Subnet Mask Remote Site Remote Secure Gateway Remote IP Address/Network Remote Subnet Mask Local/Peer ID Local ID Type...
  • Page 49 USER’S MANUAL OF WLAN BROADBAND ROUTER Remote ID Screen snapshot – VPN Setup-Edit-2 Item Key Management Advanced Connection Type Connect Disconnect PreShared Key Remote RSA Key Status Encryption Key Authentication Key Apply Change Reset Refresh Back type Fill in remote ID except IP selected Description Click to select IKE or Manual mode.

  • Page 50: Advanced Ike Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER Advanced IKE Setup Screen snapshot – Advanced VPN Settings for IKE Item Phase 1 Negotiation Mode Encryption Algorithm Authentication Algorithm Key Group Key Life Time Phase 2 Description Main mode. Click to select 3DES or AES128 encryption. Click to select MD5 or SHA1 authentication.

  • Page 51: Management - Statistics

    USER’S MANUAL OF WLAN BROADBAND ROUTER Active Protocol Encryption Algorithm Authentication Algorithm Key Life Time Encapsulation Perfect Forward Secrecy (PFS) Cancel 3.3.18 Management - Statistics This page shows the packet counters for transmission and reception regarding to wireless, Ethernet LAN and Ethernet WAN networks. Screen snapshot –...

  • Page 52: Management - Ddns

    USER’S MANUAL OF WLAN BROADBAND ROUTER Received Packets Ethernet WAN Sent Packets Ethernet WAN Received Packets Refresh 3.3.19 Management - DDNS This page is used to configure Dynamic DNS service to have DNS with dynamic IP address. Screen snapshot – Management – DDNS Item Enable DDNS Service Provider...

  • Page 53: Management - Time Zone Setting

    USER’S MANUAL OF WLAN BROADBAND ROUTER 3.3.20 Management - Time Zone Setting This page is used to configure NTP client to get current time. Screen snapshot – Management – Time Zone Settings Item Current Time Time Zone Select Enable NTP client update NTP Server Apply Change...

  • Page 54: Management - Upgrade Firmware

    USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – Management – Log Item Enable Log Wireless only System all Enable Remote Log Log Server IP Address Apply Changes Refresh Clear 3.3.22 Management - Upgrade Firmware This page allows you upgrade the Access Point firmware to new version. Please note, do not power off the device during the upload because it may crash the system.

  • Page 55: Management Save/ Reload Settings

    USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – Management - Upgrade Firmware Item Select File Upload Reset 3.3.23 Management Save/ Reload Settings This page allows you save current settings to a file or reload the settings from the file that was saved previously. Besides, you could reset the current configuration to factory default.

  • Page 56: Management - Password Setup

    USER’S MANUAL OF WLAN BROADBAND ROUTER Reset Settings to Default 3.3.24 Management - Password Setup This page is used to set the account to access the web server of Access Point. Empty user name and password will disable the protection. Screen snapshot –...
  • Page 57 USER’S MANUAL OF WLAN BROADBAND ROUTER Screen snapshot – Logout Screen snapshot – Logout - OK Item Apply Change Description Click the Apply Change button, Then click OK button to logout. Version: 1.0...

  • Page 58: Frequently Asked Questions (Faq)

    USER’S MANUAL OF WLAN BROADBAND ROUTER 4 Frequently Asked Questions (FAQ) 4.1 What and how to find my PC’s IP and MAC address? IP address is the identifier for a computer or device on a TCP/IP network. Networks using the TCP/IP protocol route messages based on the IP address of the destination. The format of an IP address is a 32-bit numeric address written as four numbers separated by periods.

  • Page 59: What Is Bssid

    USER’S MANUAL OF WLAN BROADBAND ROUTER to the wired LAN for services (file servers, printers, Internet links) they will operate in infrastructure mode. Example 1: wireless Infrastructure Mode Ad hoc mode (also called peer-to-peer mode or an Independent Basic Service Set, or IBSS) is simply a set of 802.11 wireless stations that communicate directly with one another without using an access point or any connection to a wired network.

  • Page 60: What Are Potential Factors That May Causes Interference

    USER’S MANUAL OF WLAN BROADBAND ROUTER What are potential factors that may causes interference? Factors of interference: Obstacles: walls, ceilings, furniture… etc. Building Materials: metal door, aluminum studs. Electrical devices: microwaves, monitors and electrical motors. Solutions to overcome the interferences: Minimizing the number of walls and ceilings.

  • Page 61: What Is Rts (Request To Send) Threshold

    USER’S MANUAL OF WLAN BROADBAND ROUTER fragments each of size equal to fragment threshold. By tuning the fragment threshold value, we can get varying fragment sizes. The determination of an efficient fragment threshold is an important issue in this scheme. If the fragment threshold is small, the overlap part of the master and parallel transmissions is large.

  • Page 62: What Is Preamble Type

    USER’S MANUAL OF WLAN BROADBAND ROUTER stations to establish and maintain communications in an orderly fashion. Beacon Interval represents the amount of time between beacon transmissions. Before a station enters power save mode, the station needs the beacon interval to know when to wake up to receive the beacon (and learn whether there are buffered frames at the access point).

  • Page 63: What Is Wpa2

    USER’S MANUAL OF WLAN BROADBAND ROUTER authentication server, typically one that supports RADIUS and the selected EAP authentication protocol, will be added to the network. 4.16 What is WPA2? It is the second generation of WPA. WPA2 is based on the final IEEE 802.11i amendment to the 802.11 standard.

  • Page 64: What Is Wireless Distribution System (Wds)

    USER’S MANUAL OF WLAN BROADBAND ROUTER 4.21 What is Wireless Distribution System (WDS)? The Wireless Distribution System feature allows WLAN AP to talk directly to other APs via wireless channel, like the wireless bridge or repeater service. 4.22 What is Universal Plug and Play (uPNP)? UPnP is an open networking architecture that consists of services, devices, and control points.

  • Page 65: What Is Ipsec

    USER’S MANUAL OF WLAN BROADBAND ROUTER Version: 1.0 4.28 What is IPSEC? IPSEC is the abbreviation of IP Security. It is used to transferring data securely under VPN.

  • Page 66: Example One - Pppoe On The Wan

    USER’S MANUAL OF WLAN BROADBAND ROUTER 5 Configuration Examples 5.1 Example One – PPPoE on the WAN Sales division of Company ABC likes to establish a WLAN network to support mobile communication on sales’ Notebook PCs. MIS engineer collects information and plans the WLAN Broadband Router implementation by the following configuration.
  • Page 67 USER’S MANUAL OF WLAN BROADBAND ROUTER Configure the WAN interface: Open WAN Interface Setup page, select PPPoE then enter the User Name “H890123456” and Password “PW192867543210”, the password is encrypted to display on the screen. Press Configure the LAN interface: Open LAN Interface Setup page, enter the IP Address...

  • Page 68: Example Two - Fixed Ip On The Wan

    USER’S MANUAL OF WLAN BROADBAND ROUTER Configure the WLAN interface: Open WLAN Interface Setup page, enter the SSID “MyWLAN”, Channel Number “11”. Press 5.2 Example Two – Fixed IP on the WAN Company ABC likes to establish a WLAN network to support mobile communication on all employees’...
  • Page 69 USER’S MANUAL OF WLAN BROADBAND ROUTER SSID: MyWLAN Channel: 11 DHCP client SSID: MyWLAN Channel: 11 DHCP client Internet Figure 4 – Configuration Example Two – Fixed IP on the WAN SSID: MyWLAN Channel: 11 DHCP range: 192.168.1.100 to 192.168.1.200 WAN IP: 192.168.2.254/ 255.255.255.0 Ethernet Cable...
  • Page 70 USER’S MANUAL OF WLAN BROADBAND ROUTER Version: 1.0 Configure the WAN interface: Open WAN Interface Setup page, select Fixed IP then enter IP Address “192.168.2.254”, subnet mask “255.255.255.0”, Default gateway “192.168.2.10”. Press button to confirm the configuration setting. Configure the LAN interface: Open LAN Interface Setup page, enter the IP Address...
  • Page 71 USER’S MANUAL OF WLAN BROADBAND ROUTER Version: 1.0 Configure the WLAN interface: Open WLAN Interface Setup page, enter the SSID “MyWLAN”, Channel Number “11”. Press button to confirm the configuration setting.
