- Page 1 Gas heating - firebox insert - INDOOR USE DOMINO 40 - 60 - 80 - 130 - 180 - 180C INSTALLATION and MAINTENANCE Only for device manufacturers and specialists...
- Page 2 COMPLIANCE O u r e q u i p m e n t i s c o n f o r m i n g w i t h : • Regulations (UE) 2016/426 (GAR) • Electromagnetic Compatibility Directive 2014/30/UE •...
-
Page 3: Warranty
Dear Technician, You are fortunate to have available an appliance capable of ensuring maximum and lasting aesthetic well-being ensuring high reliability, efficiency, quality and safety With this manual our intention is to provide you with the information we consider necessary for correct and easier installation of the appliance, adding to your proven expertise and technical expertise. - Page 4 In same parts of the book there are used these symbols: Attention: it used to underline particular caution or actions. Prohibited: it used to underline the actions that don’t half to be executed.
-
Page 5: General Warnings
GENERAL WARNINGS After removing the packaging ensure the integrity This manual is an integral part of the appliance and and completeness of the contents. In case of non- must therefore be stored carefully and must ALWAYS compliance, contact the Agency that sold the appliance. accompany the appliance even if it is sold to another owner or user or transferred to another system. -
Page 6: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE This appliance is for decorative purposes. This appliance is designed for decorative purposes in compliance with the applicable European standard EN509, for this reason the performance has not been evaluated as the usual appliances for heating. IDENTIFICATION The appliance can be identified by: - Packaging label... -
Page 7: Pre-Installation
PRE-INSTALLATION TYPES OF GAS Before proceeding with installation, check that the data on the label of the appliance corresponds to the type and pressure of the gas supplied. Gas installation and connection must be carried out by qualified personnel, in full compliance with the applicable Standards. - Page 8 GAS CONNECTION The appliance is equipped with a table that uniquely identifies it. paste here adhesive plate 180C Rated power (p.c.i.) 8.30 10.00 12.50 15.00 8.30 10.00 12.50 15.00 Number of main burner injectors Main burner injector diameter 2.50 2.90 2.30 2.50 1.45...
- Page 9 COMPLIANCE WITH THE STANDARDS For installation of this appliance it is always necessary to comply with the rules in force in the country in which it is to be used. Elements to be respected for GAS CONNECTION: For LPG appliances, all rooms with a floor below the external pedestrian floor or communicating with this type of environment are excluded.
- Page 10 STRUCTURE 1 - Burner cover 2 - Burner 3 - Frame 4 - Infrared receiver 5 - Ignition unit 6 - On/Off valve switch 7 - Flame control board 8 - Gas valve 9 - MAX adjustment screw 10 - Burner gas pipe 11 - Thermal switch for thermocouple 12 - Pilot gas pipe 13 - 6V DC power socket...
-
Page 11: Receiving The Product
RECEIVING THE PRODUCT The appliance is supplied with: no. 1 Device with remote valve no. 1 Standard On/Off remote control no. 1 Document envelope: no. 1 User instructions manual no. 1 Installer manual no. 1 Warranty certificate no. 1 Warranty labels... -
Page 12: Dimensions And Weights
DIMENSIONS AND WEIGHTS 180C 1276 1825 1534 1308 1010 1000 1000 1700 1700 1700 1700 L (receiver) 1000 net weight gross weight 10.5... -
Page 13: Installation
INSTALLATION The appliance in your possession includes: • Burner body incorporated in the structure provided for the recess 5 mm • Gas valve connected to the burners with hoses of 1m length for mod.40 - 60 and 1.7m for the others (from the center of the burners) •... - Page 14 COMMANDS Automatic operation position with REMOTE CONTROL MANUAL operation position 1 - Adjustment knob 2 - MAX gas adjustment screw 3 - Valve Connector/Flame control board 4 - Piezoelectric power button (manual) 5 - O-1 switch 6 - Magnet leg for manual operation 7 - Manual intervention position knob 8 - Piezoelectric connection cable connector (manual) 9 - Flame control board...
- Page 15 REMOTE CONTROL This appliance is equipped with an infrared remote control, for safety reasons in compliance with current regulations. To switch on the appliance, point the remote control directly at the sensor at A maximum distance of 3m avoiding interference with front light sources or obstacles.
-
Page 16: First Ignition
11) The final phase is the furnishing of the firebox with the accessories provided in accordance with the speci- fic instructions attached. - Page 17 MANUAL CONTROL (without remote control) The appliance can also be used in manual mode, in case of: - repair work carried out by authorised technical personnel - depleted remote control batteries Switching on - Open the gas supply valve. - Turn on the valve unit by setting the switch (5) to “I”; - Set the adjustment knob (1) to “OFF”;...
- Page 18 To try to align the various heights use the screw C with a screwdriver: - turn on the appliances with a flame at MAX. - turn clockwise to raise the flame - turn anti-clockwise to lower the flame This type of adjustment was not designed or supported to align all the flames but can help improve perception of the assembly.
- Page 19 WOOD OR STONES The firebox can be furnished: - without stones or wooden kit - with a wood kit proposed by the Manufacturer - with a stone kit proposed by the Manufacturer - with stones from 15mm to 40mm in marble, stone or river.
-
Page 20: Special Installations
SPECIAL INSTALLATIONS TABLE INSTALLATION When installing this appliance on a table, comply with the following minimum safety requirements: • Fix the table to the floor. • the materials of which the table is made must be re- sistant to minimum temperatures of 80°C plus ambient temperature: materials that by their nature are consi- dered flammable must be avoided. -
Page 21: Useful Information
USEFUL INFORMATION Seller THE FLAME GMBH Schalserstraße 41 A-6200 Jenbach tel. + 43 5244 62592 fax + 43 5244 62592 16 www. theflame.at Installer Street tel. Technical Service Assistance THE FLAME GMBH Schalserstraße 41 A-6200 Jenbach tel. + 43 5244 62592 fax + 43 5244 62592 16 www. - Page 22 0063 CU3238...
