EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v7.7 or the latest stable version, to ensure compliance
with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
This series Quick Guide covers models: RB924i-2nD-BT5&BG77 (KNOT).
This is a wireless network device. You can find the product model name on the case label (ID).
Please visit the user manual page on
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Full technical specifications, brochures, and more info about products at
Configuration manual for software in your language with additional information can be found
If you need help with configuration, please seek a
This Wireless product is featuring Bluetooth® technology.
First steps:
Ensure your Internet Service Provider (ISP) allows hardware changes and automatically assigns an IP address
Connect the ISP cable to the Ethernet1
Connect the device to the power source;
Connect to the device through any of the ports, excluding Ethernet1, or the wireless network "MikroTik-..." (ensure to check the wireless passwords on the
sticker);
Establish a connection using a mobile
Start configuration within the chosen tool, using the default IP address 192.168.88.1. If the IP address is unavailable, use Winbox and choose the "Neighbors"
tab to find the device;
Proceed to connect using the MAC address. The username is "admin," and there is no password (or, for some models, check user and wireless passwords on
the sticker);
Click the "Check for updates" button and update RouterOS to the latest
For a manual update of the device, visit the products page
the "Support&Downloads" menu;
Upload downloaded packages to the WebFig or Winbox "Files" menu and reboot the device;
By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;
In the "QuickSet" menu set up the following: Choose your country, to apply country regulation settings;
Set up your wireless network password in the left field;
Set up your router password in the bottom field.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Unijas iela 2, Riga, Latvia, LV1039.
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v7.7 или най-новата стабилна версия, за да се гарантира спазването на местните
наредби!
Крайните потребители са отговорни да спазват местните разпоредби, включително работа в рамките на законни честотни канали, изходна
мощност, изисквания за окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства MikroTik трябва да бъдат
инсталирани съгласно инструкциите.
Тази серия Кратко ръководство обхваща модели: RB924i-2nD-BT5&BG77 (KNOT).
Това е безжично мрежово устройство. Името на модела на продукта можете да намерите на етикета на калъфа (ID).
Моля, посетете страницата с ръководството за потребителя на
кода с мобилния си телефон.
Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.
Пълни технически спецификации, брошури и повече информация за продуктите
https://mt.lv/um
for the full up-to-date user manual. Or scan the QR code with your mobile phone.
consultant https://mikrotik.com/consultants
port;
application. Alternatively, use Webfig in a web browser or the "WinBox" configuration tool at
at https://mikrotik.com/products
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

https://mikrotik.com/products
at https://mt.lv/help
version;

to find your product. The required packages are accessible under
https://mt.lv/um
за пълното актуално ръководство за потребителя. Или сканирайте QR
на https://mikrotik.com/products
;
 https://mt.lv/winbox

;
