- Page 1 User Manual 60887625_00 JetViewMobile 306 ISOBUS terminal...
- Page 2 Bucher Automation AG has created this document with the requisite care and based on the current state of tech- nology. Changes and further technical developments to our products are not automatically made available in a revised document. Bucher Automation AG shall accept no liability or responsibility for errors of content or form, missing updates or any damage or disadvantages arising therefrom.
-
Page 3: Table Of Contents
USB interface ........................15 4.10 Inputs/outputs according to ISO11786:1995 ..................15 4.11 Acoustic signal generator ........................17 4.12 Real-time clock ........................... 17 Mechanical installation ..........................18 Allowed mounting orientations......................19 Electrical connection ..........................20 Deutsch plug DT12..........................21 User Manual – JetViewMobile 306... - Page 4 Defining the date format ........................43 Maintenance..............................45 Repairs ............................... 45 Storage and shipment ........................45 Return and disposal..........................45 10 Service................................. 47 10.1 Customer service..........................47 11 Spare parts and accessories........................48 11.1 Accessories ............................48 Glossary ..............................49 User Manual – JetViewMobile 306...
-
Page 5: Introduction
For information on new revisions of this document, visit the download area on our web- site. This document is not subject to any updating service. Start | Bucher Automation - We automate your success. For further information refer to the following information products: –... -
Page 6: Legal Notices
ST lib ST Microelec- http://www.st.com/software_li- Free for con- tronics cense_agreement_liberty_v2 trollers belong- ing to ST Python Python Soft- https://docs.python.org/3/license.html GPL-compatible ware Founda- tion (PSF) srec_cat Peter Miller http://srecord.sourceforge.net GNU GPLv3 Tab. 1: Licenses of third-party providers User Manual – JetViewMobile 306... -
Page 7: Safety
This device is no safety-related part as per Machinery Directive 2006/42/EC, and must, therefore, not be used for safety-relevant applications. This device is NOT intended for the purpose of personal safety, and must, therefore, not be used to protect persons. User Manual – JetViewMobile 306... -
Page 8: Warnings Used In This Document
Low risk Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Material damage Indicates a situation which, if not avoided, could result in malfunc- tions or material damage. User Manual – JetViewMobile 306... -
Page 9: Product Description
This document refers to firmware version 2.0.0.84 and higher. 3.1 Design Front side Fig. 1: Front side of the control unit On/Off key ISB key Home key Settings key Special function keys ESC key Navigation keys OK key Function keys TFT touchscreen User Manual – JetViewMobile 306... -
Page 10: Product Features
1 digital input for the ignition signal – 1 Deutsch plug DT12 – Real-time clock (RTC) with battery backup – ISOBUS-UT function 16 MB flash memory (for IOP data) – ISOBUS-TECU function Calibrating function for the tractor speed signal User Manual – JetViewMobile 306... -
Page 11: Nameplate
Update of the operating system and system menu via USB – Adaptable system menu 3.3 Nameplate Fig. 3: Nameplate Manufacturer logo Barcode Serial number Certification mark Hardware revision Part number Product type 3.4 Scope of delivery Scope of delivery Item number Quantity JVM-306 10002173 User Manual – JetViewMobile 306... -
Page 12: Technical Data
58.4 57.4 43.6 74.1 42.5 Fig. 4: Dimension in mm 4.2 Display Parameter Description Type TFT screen with touch function Resolution 640 x 480 pixels Screen diagonal 5.7" Backlighting LED, typ. 600 cd/m , dimmable Tab. 2: Technical data – display User Manual – JetViewMobile 306... -
Page 13: Pushbuttons
Standards Operating temperature -20 °C … +70 °C ISO 16750-4 Climatic conditions Humid heat Storage temperature -30 °C … +70 °C ISO 16750-4 DIN EN 60068-2-1 DIN EN 60068-2-2 Relative humidity 5% … 95% Degree of protection With mating plug: IP65; Without mating plug: IP20 Tab. 6: Technical data – environmental conditions User Manual – JetViewMobile 306... -
Page 14: Electrical Properties
Function class with ISO 16750-2 Load Dump (12 V on-board 70 V / 2 Ω / 350 ms systems) Tab. 9: Pulses in accordance with ISO 16750-2 for 12 V on-board systems Irradiation in Irradiation Function class accordance with 20 MHz ... 2 GHz 30 V/m ISO 11452 Tab. 10: Irradiation in accordance with ISO 11452 User Manual – JetViewMobile 306... -
Page 15: Ports And Interfaces
Digital inputs for Parameter Description tractor speed ISO11786: Digital inputs for wheel speed and ground speed with 2 modes. Abbreviation IN_1 … IN_2 Quantity Pull resistance 4.7 kΩ H level Mode 1: ≥ 3.4 V Mode 2: ≥ 6.2 V L level Mode 1: ≥ 2.5 V User Manual – JetViewMobile 306... -
Page 16: Tab. 15 Digital Inputs For Tractor Speed Acc. To Iso11786:1995
Analog input for Parameter Description hitch position ISO11786: Hitch position (analog input) Abbreviation TP_AI_IN Quantity Voltage range 0 V … 10 V Input resistance > 3 kΩ Tab. 18: Analog input for hitch position acc. to ISO11786:1995 Input/output for Parameter Description ignition Ignition input/output User Manual – JetViewMobile 306... -
Page 17: Acoustic Signal Generator
4.12 Real-time clock Parameter Description Battery type CR2032 Service life Approx. 10 years from pro- The service life of the battery de- duction. pends on the ambient conditions and may therefore differ. Tab. 21: Technical data – real-time clock User Manual – JetViewMobile 306... -
Page 18: Mechanical Installation
► Clean the area around a connector prior to removing the mat- ing connector. NOTICE Compliance with degree of protection The protection class of the device is only ensured if the M12 cable gland is tightened securely. User Manual – JetViewMobile 306... -
Page 19: Allowed Mounting Orientations
Mechanical installation | 5 5.1 Allowed mounting orientations The device has a RAM mount connection and can be installed in the driver's cab with a suitable holder. Fig. 5: Permitted installation position with RAM mount holder User Manual – JetViewMobile 306... -
Page 20: Electrical Connection
Surges resulting from missing protection or fusing Surges may cause malfunctions or damage to the product. ► Protect the voltage inputs from surges according to the re- quirements. ► Ensure that the device is handled in accordance with ESD regulations. User Manual – JetViewMobile 306... -
Page 21: Deutsch Plug Dt12
Fig. 6: Deutsch plug, 12- High side CAN-H Low side CAN-L Analog input for hitch position, TP_AI_IN RS-232-RX RS-232-TX Wheel speed of the tractor IN_1 Ignition On/Off (max. 0.5 A), IGN_KEY Ground speed of the tractor IN_2 Reference potential User Manual – JetViewMobile 306... -
Page 22: Firmware And System Menu
Adapt the content of this column to the name of your IOP file if necessary. – Column 4 is the comment field. It is not compiled. Multiple menu To integrate additional menu languages see Language selection in the system menu languages [} 39]. User Manual – JetViewMobile 306... -
Page 23: Updating The Firmware And System Menu Via Usb
Copy file 43434445 .EDC onto a USB stick. Insert the USB stick in the USB A socket of the device. Turn on the device. Open the system settings: Select option Update via USB: ð The firmware and system menu are updated. User Manual – JetViewMobile 306... -
Page 24: Updating The Firmware And System Menu Via Can Bus
ð The device-specific firmware file (43434445_EDC_x_x_x_x.hex) is loaded in the control unit via CAN. Restart the control unit. To do this, either turn on the ignition or press the On/Off key on the control unit. ð The firmware and system menu are updated. User Manual – JetViewMobile 306... -
Page 25: Programming
The system menu contains the general functions of the control unit. It is written by a customer-specific IOP file that is transferred to the control unit together with the firmware. The script for linking the two files is provided by Bucher Automation together with the file package. -
Page 26: Tab. 23 Fillattributes Objects
Object ID Description Editor field Tab. 24: Rectangular objects String variables Object ID Description 65000 Content of the editor field. 65001 Original value of the edited object. 65002 Serial number 65003 Manufacturing date 65004 Software version User Manual – JetViewMobile 306... -
Page 27: Tab. 26 Numeric Variables
System units of measure (0 = metric, 1 = imperial) 65114 Decimal separator (0 = comma, 1 = dot) 65115 Ground speed 65116 Wheel speed 65117 Pulse counter for ground speed. 65118 Pulse counter for wheel speed. User Manual – JetViewMobile 306... - Page 28 Pull-up resistance for hitch digital input. 65145 Value on the hitch analog input: Adjustment range: 0 % … 100 %, equivalent to 0 … 250. 65146 Operating principle of the ignition: 0 = input, 1 = output 65164 Activate key tone. User Manual – JetViewMobile 306...
-
Page 29: Tab. 27 Object Pointer
Edited list object elements +2 65203 Edited list object elements +3 65204 Edited list object elements +4 65205 Edited list object elements +5 65206 Edited list object elements -1 65207 Edited list object elements -2 User Manual – JetViewMobile 306... -
Page 30: Tab. 28 Key Objects
Internal AUX designator object pointer – Multiple AUX assignments (bitmap [++]). 3039 No attachment device selected. 3040 No function of an attachment device (ECU function) selected. 3050 .. 3058 Causes of AUX alarm For details see AUX alarm function [} 37] Tab. 29: Container objects User Manual – JetViewMobile 306... -
Page 31: Physical Keys
Exits editing mode; changes are NOT saved . Switches the inputs off when activated. Press and hold for 1 s. EDIT Opens the system menu and device settings. (screwdriver) SK_1 … SK_n Keys for free assignment with functions. User Manual – JetViewMobile 306... -
Page 32: Key Codes
Selects edited list object: current element -3. Selects edited list object: current element -4. Selects edited list object: current element -5. Opens the KEY TEST data mask. Opens the TECU settings. TECU: Starts calibration (wheel speed). User Manual – JetViewMobile 306... - Page 33 Transfers the ID (- 256) of the key that was pressed to the editor as an ASCII key code. Forwards the ID of the key that was pressed (ID % 100) + 3100 to the value of object pointer 65300. Shows the download mask if a download is active. User Manual – JetViewMobile 306...
-
Page 34: Aux Assignment
65510 65515 10520 10510 10515 65511 65516 10521 10511 10516 65512 65517 10522 10512 10517 65513 65518 10523 10513 10518 65514 65519 10523 10514 10519 Tab. 31: Example of object mapping in ISO Designer User Manual – JetViewMobile 306... -
Page 35: Fig. 8 Editor Data Mask: Representation Of Mapped Objects On The Control Unit
No ECU function is assigned. Not connected No ECU function is assigned. Only a 1:1 assignment is permitted. Connected The connection has been established. Connected The connection has been established. Only a 1:1 assignment is permitted. User Manual – JetViewMobile 306... -
Page 36: Navigation In The Aux Assignment List
Delete all: removes all assignments √ No function Tab. 33: Navigation keys in the AUX assignment list 8.2.3 Filter AUX assignments Access to the filter is available via numeric variable 65174. Fig. 9: Configuration of filter options for AUX assignments User Manual – JetViewMobile 306... -
Page 37: Remove Aux Assignments
The AUX function is working with no malfunctions. 3051 AUX alarm function is active. This is not an error message. It indicates that an alarm is pending. 3052 Connection to the AUX input device lost. User Manual – JetViewMobile 306... -
Page 38: Character Set Types Of The System Menu
Character formats bold, italic and underlined are not supported. Type Character set ISO8859-1 (ISO Latin-1, West European) ISO8859-15 (ISO Latin-9, West European) ISO8859-2 (ISO Latin-2, Central European) ISO8859-4 (ISO Latin-4, North European) ISO8859-5 (Cyrillic) ISO8859-7 (Greek) Tab. 36: Supported character set types User Manual – JetViewMobile 306... -
Page 39: Language Selection In The System Menu
The language abbreviation is forwarded via the ISOBUS. The selected index is stored in variable ID 65112. Index Language ab- Language breviation English Dutch French German Italian Spanish Danish Swedish Czech Croatian Hungarian Norwegian User Manual – JetViewMobile 306... -
Page 40: Programming Examples
Each connected ECU has an individual key code that opens the ECU pool. In the ex- ample below, softkey 5001 has key code 30. Key codes 90 … 99 call the relevant ECUs 1 … 10 of the ECU pool. Fig. 13: ECU-specific key code for opening the ECU pool User Manual – JetViewMobile 306... -
Page 41: Programming Example For Numeric Editor
Navigation by ±5 lines is possible. The scrollbar consists of two linear bar graphs with one superimposed on the other. Keys (key code 36) and (key code 35) are defined as buttons. Fig. 15: Programming example for list editor User Manual – JetViewMobile 306... -
Page 42: Programming Example For String Editor
– Keys that link to the next keyboard set: Key code: 202 Object ID: 61 xx Where xx stands for the last two places of the object ID of the targeted container. In the next example, ID 6102 replaces this container with 3102. User Manual – JetViewMobile 306... -
Page 43: Programming Example For Error Messages
A.23.3). The numeric variable (object ID 65180) is used to selected the desired date format (values 0 … 5). Value Date format Container ddmmyyyy 3030 ddyyymm 3031 mmyyyydd 3032 mmddyyyy 3033 yyyymmdd 3034 yyyyddmm 3035 Tab. 38: Available date formats User Manual – JetViewMobile 306... -
Page 44: Fig. 20 Container Ids Of The Date Components
The format is defined with variable 65180. The output strings named here contain the date format; for example, the value of the first string is DD-MM-YYYY. The object IDs of the strings are random. Only the positions in the input list are perma- nent (1 … 6). User Manual – JetViewMobile 306... -
Page 45: Maintenance
If the device is damaged or has been dropped, it is strictly forbidden to use it. 9.3 Return and disposal Option for Return a Bucher Automation AG product to us for proper disposal. For more detailed disposal information and the required return delivery certificate, please visit our Homepage. - Page 46 Bucher Automation AG Maintenance | 9 Personal data As a customer, you are responsible yourself for deleting personal data and disposing of obsolete equipment. User Manual – JetViewMobile 306...
-
Page 47: Service
To contact them, please call our technical hotline or use the contact form on our homepage: Technical hotline | Bucher Automation - We automate your success. You are also welcome to send an e-mail to our technical hotline: hotline@bucherautomation.com... -
Page 48: Spare Parts And Accessories
Inadequate accessories might cause damage to the product Parts and equipment from other manufacturers might impede the function of the device and cause damage to the product. ► Only use accessories recommended by Bucher Automation 11.1 Accessories Component Item number JVM-306 connection cable to InCab, length 1.5 m... -
Page 49: Glossary
ISO 11783: "virtual terminal". Input device A device used as the input unit of a computer, for ex- ample a joystick in the driver's cab. In the context of ISOBUS 11783: "auxiliary input device". User Manual – JetViewMobile 306... - Page 50 Object pointer for changing the keyboard set..................43 Fig. 19 Programming example for error messages ..................43 Fig. 20 Container IDs of the date components ....................44 Fig. 21 Container for date format........................44 Fig. 22 Icon "Crossed out waste bin"........................ 45 User Manual – JetViewMobile 306...
- Page 51 Tab. 34 Filter options for AUX assignments .................... Tab. 35 Containers for AUX alarm objects ....................Tab. 36 Supported character set types....................Tab. 37 Assignment of index and language abbreviation................ Tab. 38 Available date formats ........................ User Manual – JetViewMobile 306...
- Page 52 Bucher Automation AG Thomas-Alva-Edison-Ring 10 71672 Marbach/Neckar, Germany T +49 7141 2550-0 info@bucherautomation.com www.bucherautomation.com...
