Assembly Instructions & User's Manual
for
Member's Mark Lowell 3-Piece Sectional
Item Number: 990308203
Model Number: SHF-MM02-GS-DI
Customer Assistance
: 1-888-406-0838
(spare/replacement parts)
or Email: samsclub@abbysonliving.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark Lowell SHF-MM02-GS-DI
Summary of Contents for Member's Mark Lowell SHF-MM02-GS-DI
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Lowell 3-Piece Sectional Item Number: 990308203 Model Number: SHF-MM02-GS-DI Customer Assistance : 1-888-406-0838 (spare/replacement parts) or Email: samsclub@abbysonliving.com THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ..........................3 Important Safety Information ......................3 Before Assembly ..........................3 Care & Use ............................3 Package Contents ..........................4 Product Information .......................... 5 Components ............................5 Hardware .............................. 6 Step 1 ..............................6 Step 2 ..............................6 Step 3 .............................. -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
• Stress to the fabric may result in tears and when stretched, upholstery may not completely return to its original shape. • Avoid sitting in one area and use the seating areas evenly for even wear. • Fabric is not resistant to animals. Allowing pes on your upholstered furniture is not recommended. -
Page 5: Product Information
Product Information Overall Product Dimensions – 114"x114”x32.5" (289.5cm x 289.5cm x 82.6cm) Product Weight Capacity – Supports up to 300 lbs. per seat (136.08 kg.) Components LAF Loveseat (A) Corner (B) RAF Loveseat (C) Part No. Part No. Part No. Qty: 1 Qty: 1 Qty: 1... -
Page 6: Hardware
Hardware Leg (K) Bolt M6x50mm (L) Washer (M) part No. part No. part No. Qty: 24 Qty: 24 Qty:12 Flat Washer - Plastic (N) Leg Support (O) part No. part No. Qty: 2 Qty: 2 Step 1 Unpack the Legs (K), Leg Support (O), Bolt M6x50mm (L), Flat Washer - Plastic (N) washers (M) from small package LAF Loveseat and RAF Loveseat Step 2 Fit the wood feet into the bottom of Product. -
Page 7: Step 3
Step 3 Unpack the legs (K), Bolt M6x50mm (L) and washers (M) from small package Corner. Step 4 Fit the wood feet into the bottom of Product (Corner). Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 8: Step 5
Step 5 Put the back cushion (F, G, H), seat cushion (D, E) and pillow (I, J) on the product. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... - Page 9 Step 6 Connect the sectionals together by locking the alligator snap brackets on the sides of the sectionals into place. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
-
Page 10: Warning
Warning • Do not use the product unless all screws and bolts are securely tightened. • Check that all screws and bolts are secure every three months or as needed. • Dispose of packing material properly. Do not use plastic cover as head covering as it may cause suffocation. -
Page 11: Warranty Information
Warranty Information Warranty This product is covered by the Sam's Club Member Satisfaction Guarantee. Please visit samsclub.com for more information. This product’s components have a 1-year guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free samsclub@abbysonliving.com number 1-888-406-0838 or email us at NOTE: Please consider recycling all applicable packaging material.
