Summary of Contents for LAMBORGHINI HURACAN EVO
- Page 1 HURACÁN HURACÁN EVO Quick guide Quick guide...
- Page 3 This quick guide aims to familiarise you with the instructions for the main controls of your Lamborghini so that you can identify them rapidly. Please note that this guide supplements and does not replace the Owner's handbook. The information inside this booklet refers to the full-options version of the vehicle, so some controls may...
- Page 4 A u t o m a t i c l i g h t s sw i t c h Start & Stop (depending on ambient light conditions) Power windows, right side Parking lights switch Lamborghini Infotainment System Dipped headlights switch controls/Air conditioning controls Front storage compartment in the Rear fog light switch centre console/ashtray...
- Page 5 Reverse gear engagement lever PARKING mode engagement button Parking brake engagement lever Door opening lever Sun visors Ceiling light Operating mode selector button for light connected to door opening/closing Left/right reading light button Left/right reading light HomeLink buttons ® Speech dialogue system audio system Inside rear view mirror Telemetry camera Glove compartment on passenger side with lock...
-
Page 6: Opening And Closing Doors
Locking and unlocking the vehicle with remote control Locking and unlocking the vehicle Locking the vehicle Press the button for about 1 second Unlocking the vehicle Press the button for about 1 second Opening the luggage compartment lid Press the button for about 1 second Opening and closing doors When opening a door, the window will lower by a few... -
Page 7: Starting The Engine
Starting the engine On starting the vehicle, the driving mode selected is always AUTOMATIC STRADA mode by default with the START & STOP system active START ENGINE STOP button The START ENGINE STOP button allows you to turn the instrument cluster and the engine on and off: Starting •... -
Page 8: Start & Stop System
Start & Stop system The Start & Stop system helps to reduce fuel consumption and consequent CO2 emissions. In Start & Stop mode, the engine turns off automatically when the vehicle is still, for example at a traffic light. The instrument cluster remains on in this situation. - Page 9 Seats Unlocking the seatback Unlock the seatback to gain access to the rear Correct seating position area of the passenger compartment. To tilt the seatback forward, lift the lever Adjust the seatback so that your back is straight and you are at a sufficient the side of the head restraint.
-
Page 10: Steering Wheel Controls
Steering wheel controls Windscreen washer/wiper system buttons Turn signals and full-beam headlights buttons When the instrument cluster is turned on, the windscreen wipers are off. Activating turn signals It is possible to set automatic windscreen Move the selector to the left or right. wiping, regulated on the basis of the rain sensor, via the multimedia system. - Page 11 Using the gearshift in Selecting reverse AUTOMATIC and MANUAL mode With the vehicle stationary, depress the brake pedal When the vehicle is switched and at the same time pull the lever on the on it goes by default into centre console. AUTOMATIC STRADA mode With the gearshift in AUTOMATIC mode, it is possible to change to MANUAL mode and vice...
- Page 12 Operating modes Safety STRADA, SPORT, CORSA Always fasten seat belts before driving! Use the button to select the operating mode of the vehicle, which is shown on the indicator and Seat belt tongue on the instrument cluster. in the buckle STRADA and SPORT modes can be used with both AUTOMATIC and MANUAL gearshifting.
-
Page 13: Instrument Cluster
Instrument cluster The instrument cluster features three different displays depending on the driving mode, STRADA, SPORT or CORSA. The STRADA and SPORT modes differ from each other only by colour of the indicators, blue for STRADA and yellow for SPORT. The CORSA mode has a dedicated display. STRADA/SPORT Analogue rev counter Digital speedometer... -
Page 14: Instrument Cluster Warning Lights
Instrument cluster warning lights For further information on the warning lights, see your vehicle’s instruction manual. Lifting System - Front-end lifting system malfunction Airbag system Gearbox in neutral warning Seatbelt not fastened warning ESC CORSA - Electronic Stability Control system in Electromechanical parking brake light CORSA mode NO ESC - Electronic stability control system disabled in... - Page 15 Power steering malfunction warning Low washer fluid Rear-wheel steering system fault Low external temperature warning Dynamic steering initialisation Full-beam headlights Significant drop in tyre pressure TPMS Parking lights/dipped headlights Turn indicators Fault (MIL) OBD (CHECK ENGINE) Speed warning 1 Lifting System - Front End Lifting System active Speed warning 2 Battery charge level Speed warning 1 reset...
- Page 16 Lamborghini Infotainment System (LIS) Components Multimedia system interface Touchscreen which allows the driver to manage the multimedia system. USB sockets 1 and 2 • Play back multimedia content stored on USB media • Import/export telemetry data (routes/sessions/video) • Recharge/connect multimedia devices •...
- Page 17 Switching ON/OFF and Restarting With the instrument cluster on, press and hold the Home button on the lower bar to shut down the multimedia system without switching it off completely: it will only be possible to interact with the climate control system in a limited manner. To reactivate the multimedia system, simply press on any point of the screen to bring back the last screen.
- Page 18 This button activates voice commands for the Bluetooth ® procedure. connected phone or Apple CarPlay /Android Auto. CONNECTED SERVICES: opens During a phone call, the phone button opens the main • the Lamborghini Connect general call screen. settings menu. Infotainment...
- Page 19 Bluetooth connection for mobile phone ® Requirements: The vehicle is stopped, the parking brake is engaged, the transmission is in neutral (N) or park (P) position and the multimedia system and mobile phone are on. Bluetooth function activated and displayed in the multimedia system settings and on the mobile phone. ®...
- Page 20 Setting a navigation destination Playing back multimedia content In order to search for a destination, fill out the search field ; while you are filling it in, the search field will display a list When the media player is of the possible destinations from which you can choose, opened for the first time, filtered on the basis of the selected settings.
-
Page 21: Air Conditioning System
Air conditioning system The functions are switched on and off by pressing the buttons (the instrument cluster must be on). When a function is active, a light will turn on under its button. Some buttons have different functions which are activated by pressing them repeatedly. Defrost The windscreen and side windows are defrosted or demisted in the shortest time possible. -
Page 22: Further Information
Luggage compartment Fuel filler hatch Press the button below the Tyre Pressure instrument panel on the driver's side to The fuel filler hatch is locked and unlocked automatically when the central locking system on the vehicle is release the luggage compartment lid. The correct pressure for the tyres is activated. - Page 23 Emergency opening of doors from the outside If necessary, a simple procedure can be followed to open the vehicle door without using the remote control. • Remove the emergency key by pressing the button • Remove the door lock protection plate •...
- Page 26 Copyright 2020 Automobili Lamborghini S.p.A. All rights reserved © Email customercare@lamborghini.com p/n: 4T8012720HC VER. 01.20 Graphic design by the Technical Publications Office – Automobili Lamborghini S.p.A. “Lamborghini”, “Lambo” and the Lamborghini logo are registered trademarks of Automobili Lamborghini S.p.A.
