Summary of Contents for Spotsee MaxiLog

  • Page 1 Initializating the SpotSee MaxiLog Temperature Data Loggers ®...
  • Page 2 Initializating the SpotSee MaxiLog Temperature Data Loggers ® Initializating the Logger: 1) Start the MDAS-Pro software by double clicking on the icon. On the menu select Logger and click on Logger Initialization in the drop down menu 2) The Logger Initialization screen will appear.

  • Page 3: Setup Tab

    Initializating the SpotSee MaxiLog Temperature Data Loggers ® Setup Tab: • Description: Enter alpha-numeric information, such as the location of the unit. • Tracking Number: Enter numeric information, such as a record number for shipping or receiving. • Logger Clock: Set the time manually in the window, or set the logger time based on the time on your PC.

  • Page 4: Setting The Duration

    Initializating the SpotSee MaxiLog Temperature Data Loggers ® Setting the Duration: Setting the Duration of Recording will automatically calculate the Interval Between Measurements. Conversely, setting the Interval Between Measurements, will automatically calculate the Duration of Recording. For example, if you set the Duration of Recording to 3 Days, it will automatically calculate the Interval Between Measurements as 34 seconds.

  • Page 5: Alarms Tab

    Initializating the SpotSee MaxiLog Temperature Data Loggers ® Alarms Tab: • Temperature GREATER Than: Set the maximum temperature for an alarm condition to be triggered. • Temperature LESS Than: Set the minimum temperature for an alarm condition to be triggered.

  • Page 6: Properties Tab

    Initializating the SpotSee MaxiLog Temperature Data Loggers ® Properties Tab: • Stop Condition: The Push Start button on the logger may be enabled as a Stop button mechanism. Check the Enable Stop box if you want to be able to stop recording. Note that the device cannot be restarted after pushing the Stop button.
  • Page 7 Initializating the SpotSee MaxiLog Temperature Data Loggers ® You are now ready to begin recording! Simply detach the unit from the machine and press the start button to start the unit. To confirm that the logger has been started the Green LED will flash quickly and then begin a 2 second cadence. The unit is now ready to be placed in the location that should be monitored.
