Safety Notes
Gloves should be worn during installation to prevent crushing and cutting
injuries.
The product may only be used for bathing, hygienic and body cleaning
purposes.
Children as well as adults with physical, mental and/or sensoric impairments
must not use this product without proper supervision. Persons under the influence
of alcohol or drugs are prohibited from using this product.
Do not allow the streams of the shower touch sensitive body parts (such as your
eyes). An adequate distance must be kept between the shower and you.
The product may not be used as a holding handle. A separate handle must be
installed.
The hot and cold supplies must be of equal pressures.
Installation Instructions
• Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
• The pipes and the fixture must be installed, flushed and tested as per the
applicable standards.
• The plumbing codes applicable in the respective countries must be observed.
• The mesh washer must be insert to protect the shower against incoming dirt by
pipework. Incoming dirt leads to defects or/and can damage parts of the
shower; such caused faults voids all liability and guarantee claims.
Technical Data
Operating pressure:
Recommended operating pressure:
Test pressure:
Hot water temperature:
Thermal disinfection:
The product is exclusively designed for drinking water!
Fault
Insufficient water
Mixer stiff
Mixer dripping
Spout temperature does not correspond with tempera-
ture set
Instantaneous heater didn't work
2
English
Symbol description
To adjust the hot water limiter. Using a hot water limiter in combination with a
continuous flow water heater is not recommended.
The check valves must be checked regularly according to EN 806-5 in accordance
with national or regional regulations (at least once a year).
max. 1 MPa
Special accessories (order as an extra)
0,1 - 0,5 MPa
1,6 MPa
(1 MPa = 10 bar = 147 PSI)
max. 60°C
70°C / 4 min
Cause
- Aerator calcified, dirty
- Shower filter seal dirty
- Cartridge defective, calcified
- Cartridge defective
- Hot and cold supplies are reversed
- Shower filter seal dirty
- Flow limiter in handshower isn't removed
Assembly (see page 4)
Do not use silicone containing acetic acid!
Adjustment (see page 5)
Hot and cold supplies are reversed (see page 6)
Dimensions (see page 9)
Maintenance (see page 12)
Flow diagram (see page 9)
Hand shower
Bath Spout
Spare parts (see page 10)
XX = Colors
00 = Chrome Plated
14 = Brushed Bronze
67 = Matt Black
82 = Brushed Nickel
extension 60 mm #93882000 (see page 10)
Cleaning (see page 8)
Operation (see page 12)
Remedy
- Clean aerator, replace as necessary
- Clean filter seal between shower and hose
- Exchange cartridge
- Exchange cartridge
- Install function block turned through 180°
(see page 6)
- Clean filter seal between shower and hose
- Remove flow limiter
