ORLEY
EQUIPMENT CO
M35
OWNERS
SERIAL #:
ENGINE #:
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MORLEY M35

  • Page 1 ORLEY EQUIPMENT CO OWNERS SERIAL #: ENGINE #: MANUAL...
  • Page 2 WARNING If operated improperly, this machine may cause serious injury or death. • Do not wear loose clothing when operating this machine, as it may become • entangled in the equipment. Stay clear of all moving parts when the machine is running. •...
  • Page 3: Limited Warranty

    WARRANTY ADJUSTMENTS: Morley Equipment Company agrees to repair or furnish any faulty component within 30- days from date of purchase, provided the machine is operated and maintained in accordance with Morley Equipment Company owner's and engine manuals and operating instructions.
  • Page 4: Optional Equipment

    SAW INFORMATION This Manual provides the basic instructions for the operation and maintenance of the M35 concrete saw. All saw manuals are also available for download on our website at www.morleysaws.com. An engine manual is also provided with each saw.
  • Page 5: Water Supply

    Belt Replacement/Adjustment 5. To adjust or replace the belts, loosen the 3/8” “pinch” bolts, one on either side at the front of the motor base plate, and the two 1/2" bolts that run vertical at the front of the motor plate. This allows the motor to be raised or lowered, loosening the belts for replacement or tensioning.
  • Page 6 QUESTIONS AND CONCERNS: Should you have any questions relative to the operation or servicing your equipment, do not hesitate to contact Morley Equipment Company at (951) 894-5558 or email us at morleyequipco@gmail.com. A Parts List for the saw is also available on-line at www.morleysaws.com.
  • Page 7 M35 PARTS LIST Briggs & Stratton Vanguard Big Block V-Twin PARTS# REQUIRED DESCRIPTION SPINDLESHAFT ASSEMBLY 1100-35 Spindleshaft 1101-35 Pillow Block Bearing 1115-35 4 1/2" Inner Collar 1116-35 4 1/2" Outer Collar 1104-35 Left-hand Nut Right-hand Nut 1105-35 Sheave – 5 Groove...
  • Page 8: Pointer Assembly

    PART# REQUIRED DESCRIPTION HYDROSTATIC DRIVE ASSEMBLY 4100-35 Hydraulic Pump 4101-35 Wheel Motor 4103-35 Wheel Hub 3001-35 Rear Wheel - 10" x 3” 4105-35 Filter Assembly 4106-35 Filter 4107-35 Reservoir - Plastic 4201-35 Forward/Reverse Lever Assembly 4109-35 Drive Cable 4110-35 Cable End - Balljoint 4111-35 Hydraulic Pump Belt 4L370 or A-35 4112-35...
  • Page 9: Bladeguard Assembly

    PART# REQUIRED DESCRIPTION ENGINE 7106-35 Briggs & Stratton Vanguard Big Block - 4 Stroke VTwin, Gas Air Filter 7103-35 Air Filter Elements 7104-35 Throttle Cable 48" 3031-35 Choke Cable 7201-35 Sheave – 6-groove 7113-35 BLADEGUARD ASSEMBLY 8100-35 Water Distribution Block w/Hose Fittings 8181-35 Outlet Water Hose - 1/4”...
