vpacket 6100 Quick Start Manual
Voice/data router ethernet wan model
Hide thumbs
Also See for 6100:
- Reference manual (186 pages) ,
- Installer's manual (98 pages) ,
- Web interface manual (92 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Reference Manual
Advertisement
Table of Contents
Related Manuals for vpacket 6100
Summary of Contents for vpacket 6100
-
Page 1: Quick Start Guide
Quick Start Guide Vpacket 5100/6100 Voice/Data Router Ethernet WAN model Release 2.1.1 Vpacket Communications, Inc. 1390 McCarthy Blvd., Milpitas, CA 95035... -
Page 2: Trademarks And Copyrights
Trademarks and copyrights All trademarks and registered trademarks listed belong to their respective owners. Vpacket, Vpacket Communications, and the Vpacket 5100/6100 Series Voice/Data Router are registered trademarks of Vpacket Communications, Inc., Milpitas, California. Vpacket Communications, Inc. does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose. -
Page 3: About This Guide
Vpacket 5100/6100 Voice/Data Router (VDR). For detailed installation information, refer to the Vpacket 5100/6100 Voice/Data Router Installer’s Guide (P/N 750-0024-001, Rev A) or the Vpacket 5100/6100 Voice/Data Router Reference Manual, which is divided into the following sections: •... -
Page 4: Installation Site
• grounding wire Installation site Vpacket 5100/6100 VDRs are designed to be installed on a wall, within a standard 19-inch (48.26 cm) rack, or on a desktop. You should observe these guidelines: • Ensure that the side of the unit with the fans (right-hand side panel if you are facing the unit from head-on) is not placed in the top-most position;... -
Page 5: User Interface
After making the physical port connections, you can connect the power supply cord into the Power receptacle on the back panel of the 5100/6100 VDR and connect the 3-pronged end of the power cord into an AC power outlet. The unit powers on automatically when enough power is available. -
Page 6: Initial Configuration
User name writedata Access Level : Setting unit information set systemInfo systemname Seahorse_north VPacket# Seahorse_north# Setting the time set time 15:48:30 VPacket# Setting the date set date 06/13/2002 VPacket# sea_blue456 sea_blue456 seaweed_987 seaweed_987 Vpacket 5100/6100 Series QuickStart Guide Ethernet... -
Page 7: Network Diagram
The WAN IP address is a public address and connects the 6100 VDR (via an Ethernet connection) to the gateway (205.176.94.12) that connects the network to the Internet. For voice services, the 6100 VDR communicates with the switch with IP address 38.170.77.11. -
Page 8: Mgcp Configuration
“Preconfiguration steps for SIP or H.323” on page 10. MGCP configuration To configure the 5100/6100 VDR to support MGCP, you need to set each voice port, set the ports to point to a softswitch (or group of softswitches), set the coding type for each TCID, and set the coding profile usage for each coding profile. - Page 9 0 coding_type tx g711_mu telephony# set coding 1 coding_type tx g711_mu telephony# (continue to set the coding type for TCIDs 2-22) set coding 23 coding_type tx g711_mu telephony# activate telephony# commit telephony# Vpacket 5100/6100 Series QuickStart Guide Ethernet Voice over IP configuration...
- Page 10 Preconfiguration steps for SIP or H.323 The 5100/6100 VDR automatically generates a default dial plan upon boot up. This dial plan needs to be removed along with any existing telephony configuration. Next, you need to create a custom dial plan and add a hunt group (for H.323 or SIP). View commands for hunt groups and the dial plan are included in this section.
- Page 11 25 1 25 Ending an ATPM session telephony# atpm done telephony# 01/25/2002:13:18:19 - NMM: ATPM Update database done Saving the configuration changes to Flash telephony# atpm store Vpacket 5100/6100 Series QuickStart Guide Ethernet atpm hadd <hunt_group_id> <hunt_type> Voice over IP configuration...
- Page 12 1, Member ids = 2 1, Member ids = 3 1, Member ids = 22 1, Member ids = 23 1, Member ids = 24 1, Member ids = 25 Vpacket 5100/6100 Series QuickStart Guide Ethernet Prefx Prefix None None None None...
-
Page 13: Sip Configuration
Dest id = 23, Mode = TSGM, TCID = 23 Dest id = 24, Mode = TSGM, TCID = 24 Dest id = 25, Mode = SSMU, Ctl dst = +&@2.1.1.1 Vpacket 5100/6100 Series QuickStart Guide Ethernet Voice over IP configuration call_opt=0x0000... - Page 14 H.323 configuration To configure the 5100/6100 VDR to support H.323, you need to set the H.323 gatekeeper mode, set the gatekeeper, set gatekeeper alias, set the coding type for each TCID, and set the coding profile usage for each TCID.
- Page 15 1 usage voice on telephony# set coding 0 usage fax on telephony# (continue to set the usage for TCIDs 2-22) set coding 23 usage voice on telephony# activate telephony# commit telephony# Vpacket 5100/6100 Series QuickStart Guide Ethernet Voice over IP configuration...
-
Page 16: Saving Configuration Changes
For telephony changes first you need to issue the activate command and then commit command (from within the telephony shell). LEDs The 5100/6100 VDR has LEDs that indicate real-time conditions. The following table lists the front panel LED status and management functions Power... - Page 17 VPacket# d. Set the FTP path by issuing the set ftp path command and entering the path. Example: VPacket# set ftp path C:\ VPacket# Vpacket 5100/6100 Series QuickStart Guide Ethernet : guest : guest : C:\ : newCODE.BIN Upgrading the software image...
- Page 18 <filename> requestactive command. 7. Issue dir to verify that the code is now downloaded in \maincode. 8. Reboot the VDR by issuing the reset command from the CLI. <DIR> <DIR> 1262450 OLD_CODE.BIN 1262450 bytes Vpacket 5100/6100 Series QuickStart Guide Ethernet...
