SERVICE MANUAL
EN
ITEM PART
NO.
NO.
DESCRIPTION
1
20-221-1
HEX NUT,
2
20-263-1
FLAT WASHER,
3
20-301-1
HEX NUT,
4
20-336-1
SQ. HD. MACH. BOLT...................... 1
1/2-13 x 2" LONG
5
86-563
STREET ELBOW,
6
—
HEX CAP SCREW,
7
20-1076
SOC. HD. SET SCREW..................... 4
5/16-18 x 5/16" LONG
8
31-7
PROPELLER SHAFT ......................... 1
9
—
CLAMP SCREW ............................... 1
See page 3 for Model 37-384 Air Motor.
77-1617-R5.1 (11/2017)
BINKS MODEL 31-120
HEAVY DUTY AGITATOR
17
18
5
19
PARTS LIST
When ordering, please specify Part No.
.............................. 1
1/2-13
.......................... 4
1/4
.............................. 4
1/4-20
.................. 1
1/4 NPT
..... 4
1/4-20 x 1" LONG
16
6
2
3
14
7
13
7
11
10
12
8
9
7
15
7
15
ITEM PART
QTY.
NO.
NO.
10
—
11
31-17
12
31-18
13
31-19
14
31-81
15
31-82
16
37-384
17
57-13-1
18
73-159
19
83-1527
1 / 4
1
4
DESCRIPTION
CLAMP ........................................... 1
BUTTON......................................... 1
CLAMP ASSEMBLY........................... 1
SLEEVE .......................................... 1
BASE ............................................. 1
PROPELLER .................................... 2
AIR MOTOR ASSEMBLY ................... 1
D.M. NIPPLE .................................. 1
AIR ADJUSTING VALVE ................... 1
MUFFLER ASSEMBLY ....................... 1
www.carlisleft.com
QTY.
