TERASAKI TemBreak PRO T2HP40 Instruction Manual

Panel-Mounted
External Operating Handle
Instruction Manual
Type: T2HP40
This device allows the breaker installed in comparatively deep motor control center or
switchboard to be operated manually without the need for opening the panel of the motor control
center or switchboard.
Please retain this manual for future reference. The Manufacturer assumes no responsibility for
damages resulting from non-application or incorrect application of the instructions provided herein.
6-13-47 Kamihigashi, Hiranoku, Osaka
〒547-0002
547-0002, Japan
大阪市平野区加美東6–13–47
TEL 06–6791–2756 TEL +81-6-6791-2763
FAX 06–6791–2732 FAX +81-6-6791-2732
http://www.terasaki.co.jp http://www.terasaki.co.jp
kiki-info@terasaki.co.jp int-sales@terasaki.co.jp
2G0461SAH KRB-0410h
The Handle Depth/ The Mounting Direction Changing Procedure
B
C
A
C
B
A B C
mm mm mm
Applicable breaker types Applicable shaft types Shaft support
E400-□□, ZAE400-□□, T2PS401
270 310
NE400-□□, S400-□□, A-258
311 340
ZAS400-□□, NS400-□□,
T2PS402
ZE400-□□, ZS400-□□,
A-162.5
341 410
ZNE400-□□, ZNS400-□□,
NAE400-□□, NAS400-□□, 411 510 A-330
T2PS403
E630-NE, S630-CE, S630-GE,
511 610 T2PS404
ZS400□
307 347 T2PS401
A-295
348 377
T2PS402
H400-□□, L400-□□,
378 447 A-199.5
B400□
448 547 A-367 T2PS403
548 647 T2PS404
Perform the anti-rust treatment to the metal section.
Packaged Items
Handle unit Mounting plate Gasket for dust protection optional
Square shaft Mounting plate (optional, for specification of IP65)
Rigid tube
M4 14- 4pcs. M5 16- 2pcs. , M5 45- 2pcs.
Flat head screws black Pan head screws
Operation unit Key optional
M4 12- 4pcs.
No.2
remarks
and in the Remarks column mean without shaft support.
Then must be followed the steps and as shown in the figures above.
Applicable Breaker Types
Handle type
E400-□□, ZAE400-□□, NE400-□□, S400-□□, ZAS400-□□, NS400-□□,
T2HP40
ZE400-□□, ZS400-□□, ZNE400-□□, ZNS400-□□, NAE400-□□,
NAS400-□□, H400-□□, L400-□□, E630-NE, S630-CE, S630-GE,
B400□, ZS400□
＊1 ：□□=SFは除く
Assembly Tools
4.5 50
IP65
Safety Notices
Be sure to read these Instructions and other associated documents accompanying the product
thoro- ughly to be familiarize yourself with the product handling, safety information, and all other
precautions before mounting, using, servicing, or inspecting the product. In these Instructions,
safety notices are divided into " Warning" and " Caution" according to the hazard level:
Warning : A warning notice with this symbol indicates that neglecting the suggested procedure
or practice could be fatal or result in serious personal injury.
Caution : A caution notice with this symbol indicates that neglecting the suggested procedure or
practice could result in moderate or slight personal injury and/or property damage.
Shaft support
Note that failing to observe caution notices could result in serious injury/damage in some situations.
Because safety notices contain important information, be sure to read and observe them.
Applicable breaker types
Never touch live terminals. Doing so may result in electric shock.
Electrical work should only be undertaken by suitably qualified persons.
No.2
Prior to commencing any work on the product, open an upstream circuit breaker or isolator
to ensure that no voltage is applied to the product. Otherwise, electrical shock may result.
To remain the switchboard panel closed securely, use appropriate hardware in addition to
the panel lock of the handle. Using the panel lock only may result in damage to the
switchboard panel.
When the breaker trips open automatically, remove the cause, then return the handle to
the |(ON) position. Should a fault be interrupted, the breaker must be inspected.
Otherwise, a fire may result.
Do not apply excessive force to the operating knob. Otherwise, damage may occur.
Referring to the table below, install the square shaft in the position matched to the
change in breaker mounting direction.
Mounting
direction
Square shaft
installation
positions
3.6 - 4.4 N m
Warning
Operation Precautions
Caution
Installation Precautions
OFF
Operation Precautions
ON
Square shaft installation positions
Upper power supply type Left power supply Right power supply
type type
Default
3.6 - 4.4 N m
