- Page 1 DOMINO COOKING HOBS INSTALLATION ADVICES - INSTRUCTIONS FOR THE USE • CHW32X LPG • CHW23PX LPG CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) Italy...
- Page 2 Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
-
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 • Do not attempt to modify the technical characteristics of the appliance as this may become dangerous to use. The manufacturer declines all responsibility for any inconvenience resulting from the inobservance of this condition. • CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations.
- Page 5 • The manufacturer declines all liability for injury to persons or damage to property caused by incorrect or improper use of the appliance. • WARNING: During use the appliance and its accessible parts become hot; they remain hot for some time after use. Care should be taken to avoid touching heating elements on –...
- Page 6 • WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
- Page 7 Advice for the installer IMPORTANT : • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have.
-
Page 8: Installation
INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 1.2 has to be made, bearing in mind the following: • A 30 mm ventilation gap must be provided between the bottom of the appliance and any cabinetry, draw unit, thermal protection barrier or... - Page 9 FASTENING THE INSTALLATION BRACKETS (figs. 1.3a, 1.3b, 1.3c) Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 20 to 40mm thick. The kit includes 4 tabs “A” and 4 selfthreading screws “B”. •...
-
Page 10: Ventilation Requirements
VENTILATION REQUIREMENTS The appliance must be installed in compliance with applicable local regulations concerning ventilation and the evacuation of exhaust gases. Intensive and prolonged use may require extra ventilation, e.g. opening a window, or more efficient ventilation increasing the mechanical suction power if this is fitted. CHOOSING SUITABLE SURROUNDINGS The room where the gas appliance is to be installed must have a natural flow of air so that the gas can burn (in compliance with applicable local regulations). -
Page 11: Gas Section
GAS SECTION GAS INSTALLATION REQUIREMENTS Important ! • This appliance must be installed and serviced only by a suitably qualified, registered installer. The installer shall refer to the local standards in force. Failure to install the appliance correctly could invalidate any manufacturer’s •... -
Page 12: Connecting The Cooktop To The Gas Supply
CONNECTING THE COOKTOP TO THE GAS SUPPLY The gas connection fitting (fig. 2.1) is made up of: • the floating nut; • the elbow; • the gaskets; The gas connection must be carried out by an authorised person according to the relevant local standards. - Page 13 ADDITIONAL GAS CONNECTION REQUIREMENTS When connecting the cooktop to the gas supply with rigid pipes or a flexible hose, make sure that: • You use rigid pipes or a flexible hose compliant with applicable local regulations. The flexible hose shall be of the correct construction for the type of gas being used and of the correct size to maintain the heat output of the appliance.
-
Page 14: Lubrication Of The Gas Taps
GAS MAINTENANCE Some models - for the gas category check the data label attached on the appliance TABLE FOR THE CHOICE OF THE INJECTORS G30/G31 Cat: I 3+ 28-30/37 mbar Nominal Reduced Ø injector BURNERS Power [kW] Power [kW] [1/100 mm] Semi-rapid (SR) 1,75 0,45... -
Page 15: Adjusting Of The Minimum Of The Top Burners
REPLACEMENT OF THE INJECTORS Semi-rapid Select the injectors to be replaced and rapid according to the “Table for the choice of the burners injectors”. nozzle diameters, expressed hundredths of a millimetre, are marked on the body of each injector. If the injectors are not supplied they can be obtained from the “Service Centre”. -
Page 16: Electrical Section
ELECTRICAL SECTION – connect the blue wire to the IMPORTANT: The appliance must be terminal marked with the letter “N” installed by a qualified technician or coloured black; according with the current local – connect the brown wire to the regulations and in compliance with terminal marked with the letter “L”... - Page 17 REPLACING THER POWER SUPPLY CABLE WARNING: If the power supply cable is damaged, it must be replaced only by an authorized service agent in order to avoid a hazard. Use the same type of power supply cable. This cable must be connected to the terminal block following the diagram in fig. 3.1. NOTE: The earth conductor must be left about 3 cm longer than the others.
- Page 19 Advice for the users...
- Page 20 FEATURES Fig. 1.1b Fig. 1.1a Fig. 1.2a Fig. 1.2b Caution! NOTE: Do not cover the hob with aluminium The knobs and symbols may vary. foils.
-
Page 21: Control Panel Description
COOKING POINTS Semirapid burner (SR) 1,75 kW Rapid burner (R) 3,00 kW Double-ring burner (DC) 3,80 kW CONTROL PANEL DESCRIPTION Rapid burner control knob (2) Semirapid burner control knob (1) Double-ring burner control knob (3) NOTE: • The electric ignition is incorporated in the knobs. •... -
Page 22: Gas Burners
GAS BURNERS GAS BURNERS NOTE: The knob and symbols may vary. Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1) which control the safety valves. Turning the knob, so that the indicator line points to the symbols printed on the panel, achieves the following functions: –... -
Page 23: Choice Of The Burner
LIGHTING GAS BURNERS CHOICE OF THE BURNER FITTED WITH SAFETY VALVE On the control panel, near every knob DEVICE there is a diagram that indicates which burner is controlled by that knob. ignite burner, following The suitable burner must be chosen instructions are to be followed: according to the diameter and the capacity Press in the corresponding knob and... - Page 24 AUXILIARY GRATE FOR SMALL PANS (Optional) This grate is to be placed on top of the (smaller) auxiliary burner when using small diameter pans, in order to prevent them from tipping over. Fig. 2.4 CORRECT USE OF DOUBLE-RING BURNER- OPTIONAL (models with double-ring burner only) •...
-
Page 25: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE • Before you begin cleaning you must ensure that the hob is switched off. • It is advisable to clean when the appliance is cold and especially when cleaning the enamelled parts. • All enamelled surfaces have to be washed with soapy water or some other non- abrasive product with a sponge and are to be dried preferably with a soft cloth. - Page 26 PAINTED PARTS AND SILKSCREEN PRINTED SURFACES Clean using an appropriate product. Always dry thoroughly. IMPORTANT: these parts must be cleaned very carefully to avoid scratching and abrasion. You are advised to use a soft cloth and neutral soap. CAUTION: Do not use abrasive substances or non-neutral detergents as these will irreparably damage the surface.
- Page 27 Fig. 3.1 Fig. 3.2 Fig. 3.3 Fig. 3.5 Fig. 3.4...
- Page 28 The manufacturer will not be responsible for any inaccuracy resulting from printing or transcript errors contained in this brochure. We reserve the right to carry out modifications to products as required, including the interests of consumption, without prejudice to the characteristics relating to safety or function.
