- Page 1 DOMINO COOKING HOBS INSTALLATION ADVICES - INSTRUCTIONS FOR THE USE • CHW23PX SASO CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) Italy...
- Page 3 Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
-
Page 4: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 5 • CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations. • Do not carry out cleaning or maintenance operations on the appliance without having previously disconnected it from the electric power supply. •...
- Page 6 • WARNING: During use the appliance and its accessible parts become hot; they remain hot for some time after use. Care should be taken to avoid touching heating elements on – the hob. To avoid burns and scalds, young children should be kept –...
- Page 7 • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents.
- Page 8 ADVICE ADVICE for the for the INSTALLER INSTALLER...
- Page 9 IMPORTANT : • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have.
-
Page 10: Installation
INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 1.2 has to be made, bearing in mind the following: • A 30 mm ventilation gap must be provided between the bottom of the appliance and any cabinetry, draw unit, thermal protection barrier or... - Page 11 FASTENING THE INSTALLATION BRACKETS (figs. 1.3a, 1.3b, 1.3c) Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 20 to 40mm thick. The kit includes 4 tabs “A” and 4 selfthreading screws “B”. •...
-
Page 12: Ventilation Requirements
VENTILATION REQUIREMENTS The appliance must be installed in compliance with applicable local regulations concerning ventilation and the evacuation of exhaust gases. Intensive and prolonged use may require extra ventilation, e.g. opening a window, or more efficient ventilation increasing the mechanical suction power if this is fitted. CHOOSING SUITABLE SURROUNDINGS The room where the gas appliance is to be installed must have a natural flow of air so that the gas can burn (in compliance with applicable local regulations). -
Page 13: Gas Section
GAS SECTION GAS INSTALLATION REQUIREMENTS Important! • This appliance must be installed and serviced only by a suitably qualified, registered installer. The installer shall refer to the local standards in force. • Failure to install the appliance correctly could invalidate any manufacturer’s warranty. - Page 14 Fig. 2.1 8-1 (female) ISO 228-1 (male) cylindrical IS O 228-1 (male) 1/2” G cylindrical 1/2” cylindrical Gasket Floating nut G as ket Floating nut Elbow E lbow IS O 7-1 (male) 1/2” G conical Appliance IMP OR TANT ! Appliance ISO 228-1 (male) inlet pipe...
- Page 15 TABLE FOR THE CHOICE OF THE INJECTORS LPG (PROPANE/ Nominal Power Reduced Power BUTANE) 5 kPa BURNERS Ø injector [g/h] [kW] [g/h] [kW] [1/100 mm] Auxiliary (AUX) 1,00 0,34 Rapid (R) 3,00 1,00 AIR VENT NECESSARY FOR GAS COMBUSTION = (2 m /h x kW) BURNERS Air necessary for combustion [m...
-
Page 16: Adjusting Of The Minimum Of The Top Burners
REPLACEMENT OF THE INJECTORS Semi-rapid Select the injectors to be replaced and rapid according to the “Table for the choice of the burners injectors”. nozzle diameters, expressed hundredths of a millimetre, are marked on the body of each injector. If the injectors are not supplied they can be obtained from the “Service Centre”. -
Page 17: Electrical Section
ELECTRICAL SECTION – connect the blue wire to the IMPORTANT: The appliance must be terminal marked with the letter “N” installed by a qualified technician or coloured black; according with the current local – connect the brown wire to the regulations and in compliance with terminal marked with the letter “L”... - Page 18 REPLACING THER POWER SUPPLY CABLE The operations must be executed by a qualified technician. WARNING: If the power supply cable is damaged, it must be replaced only by an authorized service agent in order to avoid a hazard. Use the same type of power supply cable. This cable must be connected to the terminal block following the diagram in fig.
- Page 19 ADVICE ADVICE for the for the USERS USERS...
- Page 20 FEATURES Fig. 1.1b Fig. 1.1a Caution! NOTE: Do not cover the hob with aluminium The knobs and symbols may vary. foils.
-
Page 21: Control Panel Description
COOKING POINTS Auxiliary (AUX) 1,00 kW (73 g/h) Rapid burner (R) 3,00 kW (219 g/h) CONTROL PANEL DESCRIPTION Rapid burner control knob (2) Semirapid burner control knob (1) NOTE: • The electric ignition is incorporated in the knobs. • The appliance has a safety valve system fitted, the flow of gas will be stopped if and when the flame should accidentally go out. -
Page 22: Gas Burners
GAS BURNERS GAS BURNERS NOTE: The knob and symbols may vary. Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1) which control the safety valves. Turning the knob, so that the indicator line points to the symbols printed on the panel, achieves the following functions: –... -
Page 23: Choice Of The Burner
LIGHTING GAS BURNERS CHOICE OF THE BURNER FITTED WITH SAFETY VALVE On the control panel, near every knob DEVICE there is a diagram that indicates which burner is controlled by that knob. ignite burner, following The suitable burner must be chosen instructions are to be followed: according to the diameter and the capacity Press in the corresponding knob and... -
Page 24: Cleaning And Maintenance
CLEANING AND MAINTENANCE GENERAL ADVICE COOKING HOBS WITH • Before you begin cleaning you must GLASS LID (optional) ensure that the hob is switched off. • It is advisable to clean when the appliance is cold and especially when cleaning the enamelled parts. - Page 25 STAINLESS STEEL ELEMENTS flame spreader and the cap have been correctly positioned. Failure to do so can Stainless steel parts must be rinsed with cause serious problems. water and dried with a soft and clean cloth. In the models with safety device, check that For persistent dirt, use specific non- the probe “T”...
- Page 26 Fig. 3.1 Fig. 3.2...
- Page 28 The manufacturer will not be responsible for any inaccuracy resulting from printing or transcript errors contained in this brochure. We reserve the right to carry out modifications to products as required, including the interests of consumption, without prejudice to the characteristics relating to safety or function.
