Summary of Contents for Zenith P50W26
- Page 1 Installation and Operating Guide Model Number | P50W26 | PLASMA DISPLAY PANEL © Copyright 2002, Zenith Electronics Corporation.
-
Page 2: Warning
WARNING WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. - Page 4 SAFETY INSTRUCTIONS (Continued from previous page) 15. Lightning For added protection for this product (receiver) during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the anten- na or cable system.
-
Page 5: Table Of Contents
Contents Warning 2 Safety Instructions ......3~4 Step 1. Hook Up Monitor Controls of the Monitor ....6 Watching External Equipments . -
Page 6: Controls Of The Monitor
Controls of the Monitor VOL. MENU Power standby indicator MENU button Illuminates red in standby mode, Illuminates green VOLUME ( when the Monitor is turned buttons AUDIO (MONO) ( ) R AUDIO EXTERNAL SPEAKER (8 ) AC INPUT AV INPUT S-VIDEO INPUT 1. -
Page 7: Watching External Equipments
Watching External Equipments Connection Ports AUDIO (MONO) ( ) R AUDIO COMPONENT EXTERNAL SPEAKER (8 ) AC INPUT AV INPUT S-VIDEO (DVD/DTV INPUT) INPUT S-VIDEO INPUT AUDIO INPUT COMPONENT AV INPUT (DVD/DTV INPUT) Connection to AV equipment AUDIO AUDIO REMOTE REMOTE RGB1 OUTPUT AUDIO... - Page 8 Cable - After subscribing to a cable TV service from a local provider and installing a converter, you can watch cable TV pro- gramming. This monitor cannot display TV programming without a TV tuner device or cable TV converter box connected to the monitor.
- Page 9 atching DTV atching DTV - To watch digitally broadcast programs, purchase.connect a digital SET-TOP BOX. How to connect a user-supplied Digital Set-Top Box • Connect DTV set-top ox video output to monitor COMPONENT (DVD/DTV INPUT) or to the monitor RGB1 (PC/DTV INPUT) connector.
- Page 10 Displayable Monitor Specification Displayable Monitor Specification < RGB1 mode > Horizontal Resolution Frequency(KHz) Frequency(Hz) 31.468 640x350 37.861 31.469 720x400 37.927 31.469 35.000 37.861 37.500 640x480 43.269 45.913 53.011 64.062 35.156 37.879 800x600 48.077 46.875 53.674 < RGB2 mode > Horizontal Resolution Frequency(KHz) Frequency(Hz)
-
Page 11: Controls Of The Remote Control
Switches the sound on or off. D / E Selects a menu item. F / G (Volume button) Increase/decrease the sound level. Adjusts menu settings. To recall the current TV mode POWER STOP P/STILL PLAY VCR BUTTONS Controls a LG video cassette recorder. -
Page 12: Monitor Overview
Monitor overview Accessories Owner’s Manual Alkaline batteries D-sub 15 pin cable Monitor Installation • The Monitor can be installed in various ways such as wall mounting type, desktop type, etc.. • Install this monitor only in a location where adequate ventilation is available. To install as wall mounting type Wall mount minimum allowable clearances for adequate ventilation... -
Page 13: Turning On The Monitor
Turning on the Monitor - When using the remote control, aim it at its sensor on the Monitor. Turning on the Monitor just after installation 1. Connect power cord correctly. 2. Press the ON/OFF button on the Monitor. At this moment, the Monitor is switched to standby mode. -
Page 14: Video Menu
Video Menu APC (Auto Picture Control) APC (Auto Picture Control) - This function adjusts the PDP to the best picture appearance 1.Press the APC button to select the picture appearance setup. • Each press APC button changes the screen display as shown below. CLEAR •... -
Page 15: Audio Menu
Audio Menu DASP (Digital Auto Sound Processing) DASP (Digital Auto Sound Processing) - This function lets you enjoy the best sound without any special adjustment because the Monitor automatically selects the appropriate sound option based on the program content. 1.Press the DASP button to select the picture appearance setup. FLAT SPORTS •... -
Page 16: Time Menu
Time Menu Setting the Clock Setting the Clock - If current time setting is erased by a power failure or if TV is unplugged, reset the clock. 1. Press the MENU button and then D / E button to select CLOCK. -
Page 17: Special Menu
Special Menu Key Lock Key Lock - The monitor can be set up so that it can only be used with the remote control. - This feature can be used to prevent unauthorized viewing. 1. Press the MENU button and then D / E 2. -
Page 18: Screen Menu
Screen Menu Auto Adjustment (RGB1[PC] mode only) Auto Adjustment (RGB1[PC] mode only) - Automatically adjusts picture position and minimizes image shaking. 1. Press the MENU button and then D / E 2. Press the button and then button to select D / E 3. -
Page 19: Screen Position
Screen Position Screen Position - This function works in the following mode: RGB1-PC, RGB1-DTV 480p,720p,1080i, COMPONENT 480p,720p,1080i. 1. Press the MENU button and then D / E 2. Press the button and then D / E button to select 3. Press the button and then D / E button to adjust the position. -
Page 20: Pip (Picture In Picture) Function
PIP Function - PIP lets you view 2 different inputs (sources) on your monitor screen at the same time. One source will be large, and the other source will show a smaller inset image. - When you select PC or DTV for main picture in PIP, you can watch video, S-video or DVD for sub picture. atching PIP atching PIP Press the PIP button to switch on the sub pictures. -
Page 21: Twin Picture
Twin Picture Main Picture Size Adjustment Main Picture Size Adjustment Press the TWIN PICTURE button. • Each press of TWIN PICTURE button changes the screen display as shown below. DW 1 Sub Picture Size Adjustment Sub Picture Size Adjustment Press the WIN.SIZE button. F / G •... -
Page 22: External Control Device Setup
External Control Device Setup - Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system) and control the Monitor’s functions externally. - Connect the serial port of the control device to the RS-232C jack on the Monitor back panel. - RS-232C connection cables are not supplied with the Monitor. - Page 23 Command Reference List Command Reference List COMMAND 1 COMMAND 2 01. Power 02. Input Select 03. Aspect Ratio 04. Screen mute 05. Volume mute 06. Volume control 07. Contrast 08. Brightness 09. Color 10. Tint 11. Sharpness 12. OSD select 13.
- Page 24 03. Aspect Ratio (Command:c) (Main picture format) G To adjust the screen format. You can also adjust the screen format using the ARC (Aspect Ratio Control) button on remote control or in the Special menu. Transmission [k][c][ ][Set ID][ ][Data][Cr] Data 0 : Wide screen (16:9) 1 : Normal screen (4:3) 2 : Full screen (Zoom)
- Page 25 11. Sharpness (Command:k) G To adjust the screen sharpness. You can also adjust sharpness in the video menu Transmission [k][k][ ][Set ID][ ][Data][Cr] Data Min : 0 ~ Max : 64 * Refer to ‘Real data mapping1’. Acknowledgement [k][ ][Set ID][ ][OK][Data][x] Data Min : 0 ~ Max : 64 12.
- Page 26 20. Color temperature (Command:u) G To adjust color temperature. You can also adjust ACC in the video menu. Transmission [k][u][ ][Set ID][ ][Data][Cr] Data o: Normal 1: Cold 2: Warm 3: User Acknowledgement [u][ ][Set ID][ ][OK][Data][x] Data o: Normal 1: Cold 2: Warm 3: User...
-
Page 27: Ir Code (Nec Format)
IR Code (NEC Format) How to connect How to connect G Connect your wired remote control to remote control jack of the monitor. Set the CONTROL LOCK ‘ON’ on the monitor back panel to work wired remote control. Remote Control IR Code (NEC Format) Remote Control IR Code (NEC Format) G Output waveform Single pulse, modulated with 37.917KHz signal at 455KHz... - Page 28 Code (Hexa) Function UP ( DOWN ( VOL+ ( VOL- ( POWER On/Off POWER ON POWER OFF MUTE Number Key 0 Number Key 1 Number Key 2 Number Key 3 Number Key 4 Number Key 5 Number Key 6 Number Key 7 Number Key 8 Number Key 9 AII INPUT SELECT...
-
Page 29: Maintenance
Maintenance - Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have your new Monitor. Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen Cleaning the Screen 1. -
Page 30: Troubleshooting Check List
Troubleshooting check list • Check whether the Monitor is turned on. No picture & • Power cord inserted into wall outlet? No sound • Plug another product’s power cord into the wall outlet where the Monitor’s power cord was plugged in. •... -
Page 31: Product Specification
Power requirement Resolution Color Temperature (In operation) Humidity (In operation) • The specifications shown above may be changed without notice for quality improvement. P50W26 48.2 / 1223 28.9 / 734 4.1 / 105 99.2 / 45 AC120V, 60Hz 1280 x 720 (Dot) 16,770,000 (256 steps of each R, G and B) 0 ~ 40°C... - Page 32 P/N : 3828VA0352A (RF02CA) 206-3786...
