- Page 1 Manual Version December 2019 ANDRENA SERIES 12V2.5Ah | 5Ah | 7.5Ah | 10Ah 15Ah(SC) | 20Ah(SC) | 25Ah...
- Page 2 We kindly ask you to read this manual carefully before using the product. In this manual, the Super B Andrena Li-ion power batteries will be referred to as the Li-ion battery. This manual is meant for the installer and the user of the Li-ion battery. Only qualified and/or certified personnel may install and perform maintenance on the Li-ion battery.
-
Page 3: Table Of Contents
Connecting power cables with automotive type terminal 4.3.4. Connecting a charger to the Li-ion battery 4.4. Disconnecting a Li-ion battery 5. Battery use 5.1. General information 5.2. Charging 5.2.1. Charging rate 6. Inspection and cleaning 6.1. General information 6.2. Inspection Be in charge. Super B. - Page 4 6.3. Cleaning 7. Storage 8. Transportation 9. Disposal and recycling 10. Troubleshooting 11. Warranty and liability...
-
Page 5: Safety Guidelines And Measures
Batteries may be returned to the manufacturer. Li-ion WARNING: Must be disposed of properly. Do not mix with other (industrial) waste. May explode if damaged or disposed of in fire. Do not short circuit. Be in charge. Super B. -
Page 6: Safety Symbols And Markings On Product
1.3. Safety symbols and markings on product Several safety symbols and markings can be found on the product. These markings are displayed below. Never remove these markings! The meanings of the symbols: 14340_067_id_SUPB_Labels_Safety_30x70.indd 1 26-04-17 09:27 Wear eye protection Refer to instruction manual/booklet Warning, corrosive substance Warning, explosive material No open flame, ignition source and smoking prohibited... -
Page 7: Introduction
Super B uses this information in the warranty process. 2.2. Intented use The Andrena series Li-ion battery serves as a voltage source for starting combustion engines, which use a 12V board net. Also stationary applications which require a short and high peak current can benefit from using this Li-ion battery. -
Page 8: Used Symbols
2.4. Used symbols The following icons will be used throughout the manual: Warning! A warning indicates severe damage to the user and/or product may occur when a procedure is not carried out as described. Caution! A caution sign indicates problems may occur if a procedure is not carried out as described. -
Page 9: Charge And Discharge Specifications
(45C) (47C) (45C) (42C) (1 sec) Table 4. Charge and discharge specifications 3.1.4. Temperature specifications Andrena Series Charge temperature 0°C to 45°C / 32°F to 113°F Discharge temperature -20°C to 55°C / -4°F to 131°F Storage temperature short -20°C to 45°C / -4°F to 113°F term (<1 month) -
Page 10: General Product Specifications
3.1.6. General product specifications Andrena Andrena Andrena Andrena Andrena Andrena Andrena Andrena Andrena 12V15Ah- 12V20Ah- 12V2.5Ah 12V5Ah 12V7.5Ah 12V10Ah 12V15Ah 12V20Ah 12V25Ah Battery 4IFpR27/ 4IFpR27/ 4IFpR27/ 4IFpR27/ 4IFpR27/ 4IFpR27/ 4IFpR27/ 4IFpR27/ 4IFpR27/ designation 66-2 66-3 66-4 66-6 66-8 66-6 66-8 66-10 Cycle life >1000 (10C discharge, 100% DoD)) -
Page 11: Connections
5425006143905 A/14.4V EU plug Optimate charger 5.0 5.0A Lithium Charger 5425006143905 A/14.4V UK plug Optimate charger 5.0 5.0A Lithium Charger 5425006143936 A/14.4V US plug External under and overvoltage protector SB-BDB-250 8718531361034 Table 8. Optional components Be in charge. Super B. -
Page 12: Installation
Installation 4.1. General information Warning! Never install or use a damaged Li-ion battery. Warning! Never short circuit the Li-ion battery. Warning! Connect to 12V systems only. Never install multiple Li-ion batteries in series. Warning! Do not reverse connect the power cables (polarity). 4.2. -
Page 13: Placement Of The Li-Ion Battery
3. Ensure both contacts are tightened (M6 = 10Nm). Warning! Avoid short circuit when using a wrench. 4. Place the terminal covers over the terminals. (Figure 5). Figure 4. Connecting power cables to the Li-ion battery. Be in charge. Super B. -
Page 14: Connecting A Charger To The Li-Ion Battery
Figure 5. Place terminal covers over the terminals. 4.3.4. Connecting a charger to the Li-ion battery Warning! Ensure you have completed all the previous steps described in chapter 4 before connecting the Li-ion battery to the charger. Battery Charger Main Switch Plus (+) Minus (-) Figure 6. -
Page 15: Battery Use
Caution! Disconnect the charger from the Li-ion battery if it is not used for a long time. Caution! To charge the Li-ion battery, use a Super B charger or charger which is suitable for charging Lithium Iron Phosphate batteries. -
Page 16: Inspection And Cleaning
Inspection and cleaning 6.1. General information Warning! Never attempt to open or dismantle the Li-ion battery! The inside of the Li-ion battery does not contain serviceable parts. 1. Disconnect the Li-ion battery from all loads and charging devices before performing cleaning and maintenance activities (see paragraph 4.4). -
Page 17: Transportation
Li-ion battery is worn out. The capacity of The cells within the Li-ion battery are Consult support Super B. the Li-ion battery damaged or the Li-ion battery is worn has decreased. out. Table 10. Troubleshooting Be in charge. Super B. -
Page 18: Warranty And Liability
In the event that any such damage has arisen, the customer must notify Super B thereof as soon as possible, in any event no later than three (3) days of delivery, by means of accurate, written statement, stating the damage and where possible a photograph. - Page 19 These policies contain a usual limitation of insurance payment to be paid out to Super B if, and to the extent that, the event is a covered event.
- Page 20 For more information please contact: Super B Lithium Power B.V. Demmersweg 3 7556 BN Hengelo (Ov) The Netherlands Tel: +31 (0)88 0076 000 E-mail: info@super-b.com www: www.super-b.com Manual December 2019...
