- Page 1 ECLIPSE SERIES ECLIPSE25 WM | ECLIPSE25 WMS ECLIPSE25 BOLLARD OWNER’S MANUAL...
- Page 2 See additional connection options in this manual to achieve the best performance for your application. If you have any questions about the Eclipse Series, please contact us directly. www.osdaudio.com email: support@osdaudio.com...
-
Page 3: Model Description
MODEL DESCRIPTION Eclipse25 Bollard 2.5” 70V/8Ohm Bollard Omni Speaker w/LED Light • Uniform Dispersion Array • 1 x 2.5” Full Range Driver • 8-Ohm Power: 10Watts RMS • 70V/100V Tap: 10Watt audio • Dispersion: Horizontal: 360° ,Vertical: 120° • Frequency Response: 90-18KHz •... - Page 4 MODEL DESCRIPTION Eclipse25 WM 2.5” 70V/8Ohm Surface Mount Omni Speaker w/ LED Light • Uniform Dispersion Array • 1 x 2.5” Full Range Driver • 8-Ohm Power: 10Watts RMS • 70V/100V Tap: 10Watt audio • Dispersion: Horizontal: 360° ,Vertical: 120° •...
-
Page 5: Installation
INSTALLATION LED Lighting Considerations Note: We do not provide the low voltage transformer. The choice of transformer should be decided by the landscape lighting designer, or if you are installing it yourself, it can be sourced directly online from sites such as Amazon. - Page 6 INSTALLATION What Gauge Wire for Landscape Lighting and Sound? There are a couple different options here when it comes to landscape wiring. Luckily, we have some of the most popular choices (White or Black Jacket Option) in stock to help you. The most popular gauge sizes are 12/2 AWG landscape wire, 14/2 AWG landscape wire, and 16/2 AWG.
- Page 7 INSTALLATION 8-Ohm Connection W/12V Light Connect the Yellow(+) and Blue(-) wires to 8-Ohm Amp Single Channel(+/-) Output Connect Red(+) and Black wires to 12Volt Transformer(+/-) Output for the Light Cut/Tape Off Orange (70V Loop), Brown (70V +) and Green (100V +) wires 12V Transformer For Lights Amplifier...
- Page 8 INSTALLATION 70V Connection W/12V Light Connect the Brown (70V+) and Blue(-) wires to 70V AMP(+) and Com(-) Connections Connect Red(+) and Black wires to 12Volt Transformer(+/-) Output for the Light Connect the Yellow(+) and Orange (100V loop) wires together Cut/Tape Off Green (100V+) wire not used 12V Transformer For Lights 70V Amplifier...
- Page 9 INSTALLATION 100V Connection W/12V Light Connect the Green (100V+) and Blue H wires to 100V AMP(+) and Com H Connections Connect Red(+) and Black wires to 12Vott Transformer(+/-) Output for the Light Connect the Yellow(+) and Orange (100V Loop) wires together Cut/Tape Off Brown (70V+) wire not used 12V Transformer For Lights 70/100 V Amplifier...
-
Page 10: Sample Systems
SAMPLE SYSTEMS Eclipse25 Bollard - 70 Volt, 10Watts x 4 Speakers + 40W of 50W Sample System Diagram 3W Light 3W Light 3W Light 3W Light 12V Transformer For Lights 120 Watts Available: 96 Watts (80% of 120W) Speaker Speaker Speaker Speaker Lights Wired Parallel... - Page 11 SAMPLE SYSTEMS Eclipse25 WM - Right and Left 8-Ohm Stereo X 2pr = 4-ohm pair Sample System Diagram 3W Light 3W Light Speakers A 12V Transformer For Lights 120 Watts Available: 96 Watts (80% of 120W) Lights Wired Parallel 3W Light 3W Light Speakers B Amplifier...
-
Page 12: Warranty Info
For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs must be performed by OSD AUDIO. The unit must be returned to OSD AUDIO at the owner’s expense and with prior written permission.
